HomeVision® Pro
User Manual
HomeVision®
Pro
© Corroventa Avfuktning AB
Rev A
1 (37)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HomeVision Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CorroVenta HomeVision Pro

  • Page 1 HomeVision® Pro User Manual HomeVision® © Corroventa Avfuktning AB Rev A 1 (37)
  • Page 2: Table Of Contents

    System status ..........................24 Diagnostics – Radio connection test ..................... 25 Diagnostics – Dehumidifier test ....................26 See configuration overview ......................27 Reconfigure unit ..........................28 Reset all settings ..........................29 Remove unit ..........................30 © Corroventa Avfuktning AB Rev A 2 (37)
  • Page 3 HomeVision® Pro Alarms and service reminders, ......................31 How to read the log, PRO ......................33 Service and maintenance ........................35 Fault finding ............................36 Technical data ........................... 37 © Corroventa Avfuktning AB Rev A 3 (37)
  • Page 4: Intended Use

    User Manual HomeVision® Intended use HomeVision® is developed and intended for wireless control and supervision of Corroventa CTR STD- TT and CTR 300TT2 crawl space dehumidifiers and it consists of aControl Unit and a Control Panel. Through use of the Control Panel mounted in the in the aparent the system can be monitored and its settings adjusted.
  • Page 5: Safety Information

    10. HomeVision® must not be used with any other accessories than those presented in this manual or that are explicitly approved by Corroventa Avfuktning AB. For further advice on product safety and use, please contact the supplier. © Corroventa Avfuktning AB...
  • Page 6: Relative Humidity And Its Effect On Substances

    Control Panel. The diagram is not to scale but only intended as an illustration of the principle presented and its different parameters. % - RH Dehumidification On Alarm level Alarm +%RH Hysteresis Upper Setpoint Hysteresis Lower Dehumidification Off Temperature © Corroventa Avfuktning AB Rev A 6 (37)
  • Page 7 A too narrow span results in many starts and stops of the dehumidifier with increased wear on the equipment. A too wide span normally results in the system drying the crawls space to unnecessarily low levels which consumes more energy than necessary. © Corroventa Avfuktning AB Rev A 7 (37)
  • Page 8: Mould Growth Index Rh Control

    The RH safety margin does thus not constitute a maximum level. As for Hysteresis and the Alarm, these function the same way with MGI as with Fixed. © Corroventa Avfuktning AB Rev A 8 (37)
  • Page 9: Delivery Inspection

    The batteries are intended for use during installation of the equipment. For normal use, the Control Panel shall be powered through the power adaptor. © Corroventa Avfuktning AB Rev A 9 (37)
  • Page 10: Product Overview

    The battery comparent is opened by pushing by the arrow symbol and simultaneously sliding the lid in the arrow direction as shown in the picture below. Control Unit Control unit is mounted with sensor downwards. Cable for connection to Temperature and humidity sensor dehumidifier © Corroventa Avfuktning AB Rev A 10 (37)
  • Page 11: Installation

    The Control Unit is mounted in bracket, part of the installation kit (Monteringskit TT Multi) with the sensor downwards. The bracket is preferably fixed as depicted below. 2. Connect the Control Unit cable to the dehumidifier. © Corroventa Avfuktning AB Rev A 11 (37)
  • Page 12 Control Unit. Step to this unit in the list with use of Escape Cancel arrow button and then push OK. © Corroventa Avfuktning AB Rev A 12 (37)
  • Page 13 A1. The Control Panel can ▼ View Setup connect up to eight Control Units, and when more than one unit is connected the default presentation toggles between the different units every five seconds.. © Corroventa Avfuktning AB Rev A 13 (37)
  • Page 14: Installation Of Control Panel

    Panel, if correctly paired, will automatically reconnect the Control Unit after power down.) 4. Mount the Control Panel on the wall bracket by holding it over the bracket and pulling it downwards. Connect the power adaptor to the power outlet. © Corroventa Avfuktning AB Rev A 14 (37)
  • Page 15: To Use Homevision® Pro

    Control Unit . control mode A1 RH Control mode - Fixed Fixed % RH setpoint ∆% RH upper / lower 4% / -4% Alarm limit, +% RH ▼ Exit Change © Corroventa Avfuktning AB Rev A 15 (37)
  • Page 16: Default View

    Standard paired systems automatically reconnect after power reset. When the Control Unit has been powered down it takes approximately three minutes for the system to reestablish communication. © Corroventa Avfuktning AB Rev A 16 (37)
  • Page 17: Overview

    The user can also choose to change setup parameters in the Control Units, reset them to their factory default configuration as well as to delete them from the system. © Corroventa Avfuktning AB Rev A 17 (37)
  • Page 18: Statistics

    12 months. months. First bar to the right months. First bar to the right First bar to the right margin. is current month. is current month.. is current month. margin. © Corroventa Avfuktning AB Rev A 18 (37)
  • Page 19: Set Time And Date

    Exit Select step to “Connect new unit” and push <OK>. For normal installation, select alternative ”Standard” so that the units will reestablish communication automatically, should there be for instance a power cut. © Corroventa Avfuktning AB Rev A 19 (37)
  • Page 20 A Pairing successful Pairing failed. Restart Control Unit intended followed by the lowest available number in the interval New unit named: for pairing before retry. 1 through 8. Cancel Escape Cancel Retry © Corroventa Avfuktning AB Rev A 20 (37)
  • Page 21: Remove Usb Memory Stick

    .csv file found on the stick and work with that copy rather than with the original so as to avoid loss of original data, unintended changes to it as well as corruption of the file as such. © Corroventa Avfuktning AB Rev A 21 (37)
  • Page 22: Select Language

    Connect new unit Remove USB stick now made and stored. Select Language: English ▼ Exit Select Date/Time: 10:11:15 / 07:55 Connect new unit Remove USB stick Select Language: English ▼ Exit Select © Corroventa Avfuktning AB Rev A 22 (37)
  • Page 23: Service Status - Reset Service Counter

    If this confirmation is not presented, 12 days do the reset again. Exit Reset Reset service counter: 12 days Escape Cancel Reset A1 Do you really want to reset the service counter? Escape © Corroventa Avfuktning AB Rev A 23 (37)
  • Page 24: System Status

    Service status order. System status As any and all detected alarms are automatically Diagnostics presented, the user does not normally have to access this menu. ▼ Exit Select System status: 1234567891 Online/OK Exit © Corroventa Avfuktning AB Rev A 24 (37)
  • Page 25: Diagnostics - Radio Connection Test

    Escape Cancel Select cellular phone which is a value that can change very rapidly, both up and down. Testing A1 Unit radio quality: 100% - Good Tiime left: 10 min Exit Cancel © Corroventa Avfuktning AB Rev A 25 (37)
  • Page 26: Diagnostics - Dehumidifier Test

    Dehumidifier test is only operational for 10 minutes. ▼ Escape Cancel Select Testing A1 The dehumidifier operates for 10 min to allow system check. Time left: 10 min Cancel Stop © Corroventa Avfuktning AB Rev A 26 (37)
  • Page 27: See Configuration Overview

    The second view, accessible by push of <Next>, presents alarm level and whether continuous fan is MGI -15% selected or not. MGI -15% MGI -15% ▼ Exit Next Alarm Cont. Fan +10% +10% +10% ▼ Exit Next © Corroventa Avfuktning AB Rev A 27 (37)
  • Page 28: Reconfigure Unit

    Control Unit. If this confirmation is not presented, go back to the same screen and observe what data is presented. If it is still the old data and not the new, do the change again. © Corroventa Avfuktning AB Rev A 28 (37)
  • Page 29: Reset All Settings

    Do you really want to reset accepted and stored or if it was correctly the unit to factory default? done, use the ”See configuration overview” to see what data is currently used. Escape © Corroventa Avfuktning AB Rev A 29 (37)
  • Page 30: Remove Unit

    A1 1234567891 Online/OK This way, the new unit will inherit the name of its predecessor. Escape Cancel Remove A1 Do you really want to remove the unit from the systemt? Escape © Corroventa Avfuktning AB Rev A 30 (37)
  • Page 31: Alarms And Service Reminders

    A1: Time for service. SERVICE REMINDER Please follow instructions in manual. ▲ ▼ Next No events are logged. USB stick is either full or malfunctioning. Press OK to eject USB stick. WARNING ▲ ▼ Next © Corroventa Avfuktning AB Rev A 31 (37)
  • Page 32 To isolate the problem, if possible, please try another USB stick formatted to FAT32 to see if that eliminates the issue. If not possible or if the problem remains, please contact your retailer. © Corroventa Avfuktning AB Rev A 32 (37)
  • Page 33: How To Read The Log, Pro

    NAME” is naturally the name of the parameter and ”PARAMETER VALUE” the given parameter’s value at given time. DATE/TIME UNIT ID PARAMETER PARAMETER PARAMETER NAME VALUE 2011-01-01 00:01 D RHlow In the following, all the parameters that can appear in the log are presented. © Corroventa Avfuktning AB Rev A 33 (37)
  • Page 34 RH this month the last day of each month. Logging of accumulated hours of operation. Active hrs/day Logged daily. Logging of average temperature. Mean temp/day Logging of average relative humidity. Mean RH/day © Corroventa Avfuktning AB Rev A 34 (37)
  • Page 35: Service And Maintenance

    HomeVision® to fail. If the batteries still, for any reason, needs to be replaced they shall be 1.5V AAA cells. Two such batteries are required. © Corroventa Avfuktning AB Rev A 35 (37)
  • Page 36: Fault Finding

    FAT incorrectly formated. 32 formated. If this does not work, replace the USB stick with another FAT32 formated stick. If the problem remains, please contact your retailer. © Corroventa Avfuktning AB Rev A 36 (37)
  • Page 37: Technical Data

    230VAC/50Hz Power adaptor: Connection, Primary 5VDC, 800mA Secondary voltage and max current Delivered with 1GB USB interface for memory stick memory stick Length x Width x Height (mm) Radio Frequency 868 MHz © Corroventa Avfuktning AB Rev A 37 (37)
