Description:
The 61A00-1 Wireless Glassbreak Detector is an omni-directional acoustic sensor and wireless transmitter that
works with the HAI 45A00-1 Wireless Receiver. It is used for detecting the sound of breaking glass, providing
360º of coverage.
Features:
• Wall or Ceiling Mount
• 360º coverage
• Powered by a 3 Volt Lithium battery
• Low Battery condition signal transmission
• Test mode for glass break coverage and RF signal
MOUNTING
HOLE
Document Number: 61I00-1
Installation Instructions
PROGRAM
SWITCH
SENSOR
Figure 1 – Model 61A00-1 Glassbreak Detector
61A00-1
MOUNTING
LED
HOLE
Advertisement
Table of Contents
Related Manuals for HAI 61A00-1
Summary of Contents for HAI 61A00-1
- Page 1 Installation Instructions Description: The 61A00-1 Wireless Glassbreak Detector is an omni-directional acoustic sensor and wireless transmitter that works with the HAI 45A00-1 Wireless Receiver. It is used for detecting the sound of breaking glass, providing 360º of coverage. Features: • Wall or Ceiling Mount •...
- Page 2 To enroll the 61A00-1, put the 45A00-1 Wireless Receiver in to Setup mode, advance to an unused address location, and then press and HOLD the program switch located on the 61A00-1 circuit board (see Figure 1) for 1 second, and then release. The 61A00-1 will then send a series of transmissions and enroll the transmitter.
- Page 3 The ceiling and adjoining (side) walls are also good locations. Ceiling Mounting: Mount the 61A00-1 in any type ceiling within the direct line of sight of the glass to be protected. A position of 6’ – 10’ into the room provides better detection.
- Page 4 Testing the Sensor: Holding the tester near the surface of the glass to be protected, aim the tester at the 61A00-1 and press the test button. If window coverings are present, hold the tester behind the closed window covering (not recommended for use with heavy or lined drapes).
