  • Page 1 Operator’s Manual For the DM100-2014 VDR Document Number DBS11011 Version Number Date June 2014 P/N (hard copy) 9302721-12...

  • Page 2: Revision Record

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S Revision record Version Date Description April 2014 Original issue of document May 2014 Minor revision June 2014 Minor revision DBS11011-12 Page 2/27...

  • Page 3: Table Of Contents

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S Contents REVISION RECORD ......................2 SCOPE AND PURPOSE ..................5 References ........................ 5 Terms and Abbreviations ..................5 SYSTEM OVERVIEW ....................6 2.1.1 Data Acquisition Unit (DAU) ................6 2.1.2 VDR Bridge Control Panel (BCP) ...............
  • Page 4 Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 6.1.3 AC breaker ....................... 15 6.1.4 LEDs in the Ethernet connector ............... 16 6.1.5 Allocation of system labels for digital interfaces ..........16 6.1.6 MR address ...................... 16 OPERATION OF STANDARD RVI 02-004 AND RVI 02-004D (POE) ....17 Operation of RVI with AC power supply ..............

  • Page 5: Scope And Purpose

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 1 Scope and purpose Operator's Manual for the DM100-2014 VDR. The DM100-2014 complies with IEC 61996-1 Ed.2 which applies to VDRs installed from 1 of July 2014. 1.1 References DBS10704 Installation Manual for DM100/DM400 VDR compact Sensor Interface Unit...

  • Page 6: System Overview

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 2 System overview Ethernet PoE Fixed STP CAT5 Capsule Float-free Ethernet PoE capsule Ethernet PoE STP CAT5 STP CAT5 Ethernet STP Images from CAT5/CAT6 RADAR and ECDIS Ethernet PoE STP CAT5...

  • Page 7: Fixed Capsule

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 2.1.4 Fixed capsule The fixed data capsule (“the orange box”) must be installed on an “external deck close to the vessels center line” - typically on the external deck above the bridge.

  • Page 8: Maximum Number Of Supported Interfaces

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 2.2 Maximum number of supported interfaces If needed, additional equipment may be used to make larger or non-standard configurations. The maximum number of supported interfaces for a VDR is listed below:...

  • Page 9: Operation

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S Operation 3.1 Bridge Control Panel The BCP is the primary user interface for an installed operational VDR. It serves two purposes: • Alarm (caution) display • Interface for initiating VDR self-test (Operational Performance Test) 3.1.1 Alarm display...

  • Page 10: Operation Of The Dm100 Dau

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 4 Operation of the DM100 DAU The door to the DAU must be locked after the VDR has been installed and is operating normally. This section of the manual is only relevant during installation and service.

  • Page 11: Data Processing Unit (Dpu)

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 4.1 Data Processing Unit (DPU) The DPU is the main computer in the system. It is basically a PC, but it has been designed from scratch in a completely different manner in order to withstand environmental stress which far exceeds what an ordinary industrial PC can tolerate.

  • Page 12: Battery Switch

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 4.1.4 Battery switch The battery switch indirectly controls a relay between the DPU and the battery pack. When switching the VDR off; do the following: Pop out the AC breaker and briefly move the battery switch to its “OFF”...

  • Page 13: Operation Of The Non-Modular Compact Siu

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 5 Operation of the non-modular compact SIU Ethernet port Uni Rack Ethernet link AC LED AC Breaker AC inlet and activity UR address indicators Serial I/F Analog I/F Digital I/F Uni-rack with 16 analog interfaces 5.1 LEDs on the Uni-rack...

  • Page 14: Ethernet Link And Activity Indicators

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 5.1.3 Ethernet link and activity indicators The LINK LED (right) will be illuminated (yellow) when a communication link is established to the DAU. The ACT LED (left) will flicker (green) depending on the traffic load.

  • Page 15: Operation Of The Modular Siu

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 6 Operation of the modular SIU Module Rack MR address Ethernet Link indications AC LED AC Breaker AC inlet ports for slots Serial I/F Analog I/F Digital I/F module module...

  • Page 16: Leds In The Ethernet Connector

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 6.1.4 LEDs in the Ethernet connector Two LEDs are integrated into each Ethernet connect. The right LED (yellow) will be illuminated when a communication link is established to the DAU. The LED will flicker depending on the traffic load.

  • Page 17: Operation Of Standard Rvi 02-004 And Rvi 02-004D (Poe)

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 7 Operation of standard RVI 02-004 and RVI 02-004D (PoE) The DM100 will normally use an RVI 02-004 and RVI 02-004D for image capture. Another type exists (see section 7.1) which may be used if the “Power over Ethernet” ports on the DPU are used for other purposes.

  • Page 18: Operation Of Rvi With Ac Power Supply

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 7.1 Operation of RVI with AC power supply This type is only used if the “Power over Ethernet” ports on the DPU are being used for other purposes. RVI address...

  • Page 19: Error Codes

    Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S 8 Error codes Error codes and messages will be displayed by the BCP. 8.1 Error codes SYSTEM The VDR has encountered an unrecoverable system error. Reboot FATAL ERROR the system. If the error persists, the most probable cause is a...
  • Page 20 Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S NETWORK IMAGE More than one source (e.g. an ECDIS) is sending images with the Duplicate Location same Location ID. Inspecting the received images using the monitor tool in the VDR configurator may help. Check the setup of...
  • Page 21 Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S If AC power is present (and the AC fuse/breaker is pushed) while this error is displayed, the DPU must be repaired. AUDIO module 2 This will only happen if audio module 2 (the Remote Audio Missing (AUD6) Interface) is enabled in the VDR configuration.
  • Page 22 Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S BAM comm. timeout been interrupted. The primary fan in the DPU has failed. The secondary fan in DPU CPU fan failed will serve as a backup until the problem is rectified. The VDR will be able to operate normally unless the secondary fan also fails (error 191).
  • Page 23 Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S connected to the DAU, with the same address. VIDEO Recording of radar images to the FRM has been disabled which is Illegal settings unacceptable for a VDR installation. The system configuration must be changed, consult the Installation Manual.
  • Page 24 Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S CAPSULE The VDR is unable to detect a fixed capsule. Check that the fixed Cannot find capsule is connected correctly. If the error persists, the fixed capsule is probably defective.
  • Page 25 Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S probably defective. FLOAT-FREE, too many Too many write-errors (writing to the float-free capsule) have been write errors detected by the DPU over a period of time. The most likely cause is communication problems.
  • Page 26 Operator's Manual for the DM100-2014 VDR Copyright Danelec Marine A/S a defective VDR data disk (i.e. the SDD inside the DPU). If the error persists, the DPU must be repaired. LONG-TERM, too many Too many read-errors (reading back data from the VDR data disk) read errors have been detected by the over a period of time.

  • Page 27: Service And Maintenance

    9 Service and maintenance The VDR requires an annual performance test carried out by a certified service organization. Please refer to “Installation Manual for DM100-2014 VDR” for further details. 9.1 Verification of the VDR functionality following service on any sensor It is a requirement of the VDR standard that the functionality of the VDR is verified following service on any sensor (e.g.
