- Page 1 ECOfit & ECOfit Plus Rolls TECHNICAL MANUAL Installation · Maintenance · Warranty Manufactured in the U.S.A. by: Revised on 07/18/2019 Supersedes all previous versions. Check website for updates.
-
Page 2: Table Of Contents
ECOfit & ECOfit Plus Rolls Technical Manual Installation Job Site Conditions Subfloors Subfloor Preparation Storage & Handling Installation Maintenance Specifier Information Cleaning Procedures ECOguard Sealer Procedures Warranty Warranty www.ecorecommercial.com... -
Page 3: Job Site Conditions
65˚ F (18˚ C) for 48 hours prior to, during, and after installation. SUBFLOORS ECOfit Plus rolls may be installed over concrete, approved Portland based self-leveling materials, and wood. Note: Gypsum based patching and leveling compounds are not acceptable. -
Page 4: Storage & Handling
ECOfit & ECOfit Plus Rolls Technical Manual HAZARDS SILICA WARNING: Concrete, floor patching compounds, toppings, and leveling compounds can contain free crystalline silica. Respirable crystalline silica (particles 1–10 micrometers) can be produced by cutting, sawing, grinding, or drilling. Respirable silica is classified by OSHA as an IA carcinogen and is known to cause silicosis and other respiratory diseases. -
Page 5: Installation
Figure 1 B. Note: Custom roll lengths eliminate the possibility of the rolls being manufactured and numbered in the customer’s desired installation sequence, and Ecore cannot be responsible for any resulting shading issues. C. Roll material is stretched slightly when it is rolled at the factory. Unroll all rolls and allow to relax for a minimum of two hours before gluing or cutting material. - Page 6 Remove tape after adhesive has developed a firm set (approximately 2-3 hours). Ecore will not be responsible for residue left behind from tape of any kind. L. Keep foot traffic off the floor for a minimum of 24 hours. Floor should be kept free from rolling loads for a minimum of 48-72 hours.
-
Page 7: Specifier Information
Ecore recommends our Environmentally Friendly Maintenance Products and Procedures for ECOfit. Proper protection and maintenance of ECOfit post-installation should be specified by the architect/designer. ECOfit products should not be subject to construction debris and potential damage caused from heavy duty construction activities. -
Page 8: Maintenance
CAUTION – A “standard” black pad should be the most aggressive pad used. A high productivity black pad such as 3M’s 7300 series will act as a sander and damage the surface of the rubber. Ecore assumes no liability in the event of damage to the rubber in the removal process. ECOguard is considered a permanent sealer and not intended to be stripped from the rubber as a standard procedure. -
Page 9: Ecoguard Sealer Procedures
ECOfit & ECOfit Plus Rolls Technical Manual Approved Cleaning / Stripping Pads Manufacturer Cleaning Stripping White 4100, Beige 4200 Black 7200, Brown 7100, Blue 5300 Taski White Black, Purple IMPORTANT MAINTENANCE TIPS Use high CFM vacuum to pick up dust. - Page 10 • Safety glasses should be worn when mixing, pouring or applying ECOguard. Apply first coating of ECOguard to the rubber surface using Ecore’s recommended • Microfiber Mop. An applicator trim pad may be used for areas around the perimeter.
- Page 11 CAUTION –DO NOT USE a high performance black pad such as 3M’s 7300 series. It will act as a • sander and will damage the surface of the rubber. Ecore assumes no liability in the event of damage to the rubber in the removal process. ECOguard is considered a permanent sealer and not intended to be stripped from the rubber as a standard procedure.
-
Page 12: Warranty
ECOfit & ECOfit Plus Rolls Technical Manual Warranty All Ecore rubber flooring is guaranteed to be free from manufacturing defects on both material and workmanship. If such a defect is discovered, the customer must notify Ecore either through the contracting installer, distributor, or directly. - Page 13 ECOfit & ECOfit Plus Rolls Technical Manual 877.258.0842 www.ecorecommercial.com Manufactured in the U.S.A. by: 715 Fountain Ave – Lancaster, PA 17601 ©2019 All designs and colors are copyrighted by Ecore Intl. ECOsurfaces is a registered trademark of Ecore Intl. www.ecorecommercial.com...
