GAS VALVE
THESE INSTRUCTIONS SUPERCEDE
THE GAS VALVE SETTING PROCEDURE CONTAINED
WITHIN THE ORIGINAL APPLIANCE LITERATURE.
MODEL
Ecosy SB 28E
Ecosy 28E
KIT Pt. No. 05632900
incl.
1 off "O" ring
4 off screws
MODEL
Ecosy 24E
Ecosy SB 24E
KIT Pt. No. 05617100
IMPORTANT NOTE
(HONEYWELL)
Advertisement
Related Manuals for Saunier Duval Bulex Ecosy SB 28E
Summary of Contents for Saunier Duval Bulex Ecosy SB 28E
- Page 1 GAS VALVE (HONEYWELL) IMPORTANT NOTE THESE INSTRUCTIONS SUPERCEDE THE GAS VALVE SETTING PROCEDURE CONTAINED WITHIN THE ORIGINAL APPLIANCE LITERATURE. MODEL Ecosy SB 28E Ecosy 28E KIT Pt. No. 05632900 incl. 1 off “O” ring 4 off screws MODEL Ecosy 24E Ecosy SB 24E KIT Pt.
- Page 2 Do not use reconditioned or copy parts that have not been clearly authorised by Saunier Duval. After electrical connections have been made, checks to the earth continuity, polarity, short circuit and resistance to earth must be repeated using a suitable multimeter.
- Page 3 CO/CO2 ratio is acceptable. Advice can be sought from Check the Gas Inlet Pressure and Gas Rate the Saunier Duval Technical Helpline 01773 828400. On completion, test the gas installation for tightness using the pressure drop method and suitable leak detection fluid, purge in accordance with the above standard.
- Page 4 Models SETTING - OUTPUT SETTING - OUTPUT MAX. GAS RATES Nat. Gas G20 - Case Off Nat. Gas G20 - Case On CO/CO2 Nat. Gas G20 Ratio OUTPUT MIN. 8.3 kW MAX. 28.0kW MIN. 8.3 kW MAX. 28.0kW MAXIMUM Ecosy SB 28E 9.0 - 9.4%CO2 9.2 - 9.6%CO2 0.004...
