VRGO Chair Instruction Manual

Please read and retain these instructions for future use

Product Overview

1.
2.
3.

Product Features

1 – Foam Seat Pad
2 – Composite Shell Structure
3 – Rubber Interfacing Ring
4 – USB Charging Port
5 – Push Button Switch and LED Indicator
2
Before First Use
Read these instructions carefully before use.
Remove both parts carefully from the packaging and inspect for any
damage.
4.
Assemble the two halves by carefully locating the rim of the upper
shell into the rubber interfacing ring in the lower shell, and pushing
firmly together.
5.
Important: The upper shell must be fully engaged in the rubber strip
prior to use! Failure to engage correctly could result in damage to the
product and injury to the user.
Connect the USB charger to the charging port (4), and charge for 30
minutes.
The button will flash yellow until the battery is fully charged. The but-
ton will flash green when fully charged and red when running low on
charge.
Important: The product should only be charged as required, and not
left permanently connected to the charger.
Using your VRGO
Ensure that all safety requirements have been taken into account.
Once the VRGO is fully charged, disconnect it from the USB charger,
and unplug the charger for later use.
Ensure that the VRGO is on a level surface, and is in its vertical orien-
tation (the system will self-calibrate after switch-on against this known
vertical).
Switch on the device by briefly pressing the button (5); the LED will
begin to flash.
3
