Operating Instructions
Thermo-hygrometer, 8 channels
Item No. 1544543

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1544543 and is the answer not in the manual?

Questions and answers

Related Manuals for Eurochron 1544543

Summary of Contents for Eurochron 1544543

  • Page 1 Operating Instructions Thermo-hygrometer, 8 channels Item No. 1544543...

  • Page 2: Table Of Contents

    Table of contents Page 1. Introduction ................4 2. Explanation of symbols ............5 3. Intended use .................5 4. Delivery content ..............6 5. Features and functions ............6 6. Safety instructions ..............7 a) General information............7 b) (Rechargeable) batteries..........9 7. Display elements ..............10 8. Inserting/changing the batteries .........11 9.
  • Page 3 12. Calibration ................15 a) Air humidity ..............15 b) Temperature ..............16 13. Positioning ................17 14. Care and cleaning ..............18 15. Declaration of conformity (DOC) ........18 16. Disposal ................19 a) Product ................19 b) (Rechargeable) batteries..........19 17. Technical data ..............20...

  • Page 4: Introduction

    1. Introduction Dear customer, Thank you for purchasing this product. This product complies with statutory national and European regulations. For safety reasons, always follow the instructions in this manual. These operating instructions are part of this product. They contain important information on setting up and using the product.

  • Page 5: Explanation Of Symbols

    2. Explanation of symbols This symbol is used to highlight important information in these operating instructions. Always read this information carefully. This symbol indicates special information and advice on how to use the product. 3. Intended use The product is used to measure and display the indoor temperature and humidity.

  • Page 6: Delivery Content

    Make this product available to third parties only together with its operating instructions. All company and product names are trademarks of their respective owners. All rights reserved. 4. Delivery content • Thermo-hygrometer • Operating instructions Up-to-date operating instructions Download the latest operating instructions at www.conrad.com/ downloads or scan the QR code on this page.

  • Page 7: Safety Instructions

    6. Safety instructions Read the operating instructions carefully and especially observe the safety information. If you do not follow the safety instructions and information on proper handling in this manual, we assume no liability for any resulting personal injury or damage to property. Such cases will invalidate the warranty/guarantee.
  • Page 8 • Protect the product from extreme temperatures, direct sunlight, strong jolts, high humidity, moisture, flammable gases, vapours and solvents. • Do not place the product under any mechanical stress. • If it is no longer possible to operate the product safely, stop using it and prevent unauthorized use.

  • Page 9: B) (Rechargeable) Batteries

    b) (Rechargeable) batteries • Correct polarity must be observed while inserting the (rechargeable) batteries. • (Rechargeable) batteries should be removed from the device if it is not used for a long period of time to avoid damage through leaking. Leaking or damaged (rechargeable) batteries might cause acid burns when in contact with skin, therefore use suitable protective gloves to handle corrupted...

  • Page 10: Display Elements

    7. Display elements Measured temperature 24hrs indicator value Battery status Temperature unit CALIBRATED indicator Temperature trend 10 Comfort level indicator CALIBRATED indicator 11 Measured humidity value Icon for radio transmission 12 Channel number Humidity trend 13 MAX MIN indicator...

  • Page 11: Inserting/Changing The Batteries

    8. Inserting/changing the batteries • Remove the battery compartment cover from the back. • Insert 2 AAA batteries, observing correct polarity. Observe polarity as indicated inside the battery compartment. As soon as the batteries are inserted, all display segments will appear briefly. The icon for wireless transmission flashes once per minute.

  • Page 12: Start-Up

    9. Start-up a) Selecting the channel If you wish to use the product as an additional sensor for a weather station, all sensors must be set to a different channel. You must follow the operating instructions of the weather station. If you use the product as a stand-alone device, you need not change the channel.

  • Page 13: C) Automatically Delete The Min/Max Values

    • Briefly press the MIN/MAX/- button to view the current measured values. c) Automatically delete the MIN/MAX values • To automatically delete the registered minimum and maximum values every day, press and hold the SET button for approx. 3 seconds until the 24hrs indicator appears. If you enable this feature at noon, for example, the values will be automatically deleted every day at noon.

  • Page 14: Comfort Level Indicator

    10. Comfort level indicator Indicator Meaning Air humidity <45 % Comfortable 45 – 65 % >65 % 11. Trend display The arrows indicate changes of temperature and humidity. • The arrow is pointing up. - The temperature rises by at least 2 °C within 30 minutes. - The humidity rises by at least 5 % within 30 minutes.

  • Page 15: Calibration

    12. Calibration Perform a calibration only if you have another reliable and calibrated measuring device at hand. Do not use measured data from the internet, radio, television or newspaper, since they may not necessarily match the current conditions for your location. We recommend using a mercury or alcohol thermometer as a reference.

  • Page 16: B) Temperature

    • If no button is pressed for 15 seconds, the product automatically returns to normal display mode. b) Temperature • Press and hold the SET and CH/+ buttons at the same time for approx. 3 seconds until the temperature value flashes. •...

  • Page 17: Positioning

    13. Positioning • You can use a nail or screw to hang the product on the wall. • You can also set up the product on a flat, stable surface. To do this, fold out the stand.

  • Page 18: Care And Cleaning

    14. Care and cleaning Never use aggressive detergents, rubbing alcohol or other chemical solutions, as these could damage the casing or cause the product to malfunction. Use a dry, lint-free cloth to clean the product. 15. Declaration of conformity (DOC) Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau hereby declares that this product conforms to the 2014/53/EU directive.

  • Page 19: Disposal

    16. Disposal a) Product Electronic devices are recyclable waste and must not be disposed of in household waste. Always dispose of the product according to the relevant statutory regulations. Remove any inserted batteries and dispose of them separately from the product. b) (Rechargeable) batteries You are required by law (Battery Directive) to return all used batteries.

  • Page 20: Technical Data

    17. Technical data Power supply ........2 x 1.5 V battery, type AAA (not included) Measurement range ....... 0 to +60 °C 10 – 99 % RH Accuracy ......... ±1 °C ±5 % RH Transmission frequency....433 MHz Transmission power......-20 dBm Range ..........100 m (open space) Transmission interval ......60 sec Operating/storage conditions ..
  • Page 21 This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
