___________________
1
SCALANCE W1788-x
SIMATIC NET
Industrial Wireless LAN
Approvals SCALANCE W1700
802.11ac
Reference Manual
11/2018
C79000-G8976-C487-02

Advertisement

loading

  Related Manuals for Siemens SIMATIC NET Series

  Summary of Contents for Siemens SIMATIC NET Series

  • Page 1 ___________________ SCALANCE W1788-x SIMATIC NET Industrial Wireless LAN Approvals SCALANCE W1700 802.11ac Reference Manual 11/2018 C79000-G8976-C487-02...
  • Page 2: Legal Information

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
  • Page 3: Table Of Contents

    Table of contents SCALANCE W1788-x ..........................7 Type designations ........................8 EC declaration of conformity ..................... 9 1.2.1 ATEX ............................10 1.2.2 RoHS............................11 1.2.3 RED............................11 1.2.3.1 Protection of health and safety ....................11 1.2.3.2 EMC ............................12 1.2.3.3 Efficient use of the radio spectrum ..................
  • Page 4 Table of contents Approvals SCALANCE W1700 802.11ac Reference Manual, 11/2018, C79000-G8976-C487-02...
  • Page 5 Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers’...
  • Page 6 SCALANCE W1788-x Approvals SCALANCE W1700 802.11ac Reference Manual, 11/2018, C79000-G8976-C487-02...
  • Page 7: Scalance W1788-X

    SCALANCE W1788-x Note Issued approvals on the type plate of the device The specified approvals apply only when the corresponding mark is printed on the product. You can check which of the following approvals have been granted for your product by the markings on the type plate.
  • Page 8: Type Designations

    SCALANCE W1788-x 1.1 Type designations Type designations Scope of validity The approvals listed in this section apply to the following products: Product Article number Access point SCALANCE W1788-1 M12 6GK5788-1GY01-0AA0 Dual access points SCALANCE W1788-2 M12 6GK5788-2GY01-0AA0 SCALANCE W1788-2 M12 EEC 6GK5788-2GY01-0TA0 SCALANCE W1788-2IA M12 6GK5788-2HY01-0AA0...
  • Page 9: Ec Declaration Of Conformity

    DE-76181 Karlsruhe Germany You can find the current EU declaration of conformity for these products on the Internet pages under Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/ps/15853/cert). The SIMATIC NET products described in this document meet the requirements of the following EU directives: ●...
  • Page 10: Atex

    SCALANCE W1788-x 1.2 EC declaration of conformity 1.2.1 ATEX ATEX directive (correct usage in potentially explosive atmospheres) The SIMATIC NET product meets the requirements of the EU directive 2014/34/EU "Equipment and Protective Devices for Use in Potentially Explosive Atmospheres" according to the standards listed in the section "Products (Page 13)"...
  • Page 11: Rohs

    SCALANCE W1788-x 1.2 EC declaration of conformity 1.2.2 RoHS RoHS directive (restriction of the use of certain hazardous substances) The SIMATIC NET products described in these operating instructions meet the requirements of the EC directive 2011/65/EC for the restriction of the use of certain hazardous substances in electrical and electronic equipment: Applied standard: EN 50581...
  • Page 12: Emc

    SCALANCE W1788-x 1.2 EC declaration of conformity 1.2.3.2 Art. 3 (1) b - EMC EN 50121-3-2+AC Railway applications - Electromagnetic compatibility - part 3-2: Railway Vehicles - Devices EN 50121-4+AC Railway applications - Electromagnetic compatibility - part 4: Interference emissions and immunity of signal telecommunications equipment ETSI EN 301 489-1 Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic...
  • Page 13: Efficient Use Of The Radio Spectrum

    SCALANCE W1788-x 1.2 EC declaration of conformity 1.2.3.3 Efficient use of the radio spectrum Art. 3 (2) Efficient use of the radio spectrum ETSI EN 300 328 Broadband transmission systems – Data transmission equipment operating in the 2.4 GHz ISM band and using broadband modulation techniques. Harmonized EN covering the essential requirements of article 3.2 of the EU Directive 2014/53/EU ETSI EN 300 440-2, ETSI EN 300 440 Electromagnetic compatibility and radio spectrum matters (ERM) –...
  • Page 14: General Approvals

    Area". You will find this document • on the data medium that ships with some devices. • on the Internet pages under Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/). Enter the document identification number C234 as the search term. The SIMATIC NET products meet the requirements of the EU Directive 2014/34/EU "Equipment and Protective Devices for Use in Potentially Explosive Atmospheres".
  • Page 15 SCALANCE W1788-x 1.3 General approvals Permitted types of protection The following types of protection are possible: ● nA ATEX classification: II 3G Ex nA IIC T4 Gc Certificate no.: KEMA 07ATEX0145 X The products meet the requirements of the following standards: –...
  • Page 16 SCALANCE W1788-x 1.3 General approvals IECEx The SIMATIC NET products meet the requirements of explosion protection according to IECEx. Note Type of protection of the device The devices are approved for various types of protection. You can find the type of protection of your device and the IECEx certificate number on the nameplate.
  • Page 17 SCALANCE W1788-x 1.3 General approvals Railway approval EEC variants of the device meet the requirements of the standards: ● EN 50155 "Railway applications - Electronic equipment used on rolling stock" ● EN 45545 "Railway applications - Fire protection on railway vehicles" Note When used on railway stock, a stabilized power supply must be used to comply with EN50155.
  • Page 18 SCALANCE W1788-x 1.3 General approvals Note for Australia - RCM The product meets the requirements of the RCM standard. Applied standards: ● AS/NZS CISPR11 (Industrial, scientific and medical equipment - Radio-frequency disturbance characteristics - Limits and methods of measurement). ● EN 61000-6-4 Electromagnetic compatibility (EMC) - Part 6-4: Generic standards - Emission standard for industrial environments You will find the current versions of the standards in the currently valid RCM SDoCs (Self- Declaration of Conformity).
  • Page 19: National Approvals

    The diamond symbol (♦) identifies all countries or frequency ranges for which there was no approval at the time these operating instructions were written. The current status of the approvals can be found on the Internet at the following address: Approvals (https://www.siemens.com/wireless-approvals). Column Meaning...
  • Page 20 SCALANCE W1788-x 1.4 National approvals Country Mode MaxAntGai (EIRP) Albania 11g 11n 2412 100 mW Indoor + Outdoor Andorra Belgium 2472 Bosnia and 11a 11c 11n 5180 200 mW Indoor only Herzegovina Bulgaria 5240 Denmark 11a 11c 11n 5260 200 mW Indoor only Germany DFS + TPC...
  • Page 21 SCALANCE W1788-x 1.4 National approvals Country Mode MaxAntGai (EIRP) Australia 11g 11n 2412 100 mW Indoor + Outdoor 2472 11a 11c 11n 5180 200 mW Indoor + Outdoor 5240 11a 11c 11n 5260 200 mW Indoor + Outdoor DFS + TPC 5320 11a 11c 11n 5500...
  • Page 22 SCALANCE W1788-x 1.4 National approvals Approvals SCALANCE W1700 802.11ac Reference Manual, 11/2018, C79000-G8976-C487-02...
