PullRite Super 5th SuperRail Mounting Instructions page 3

Figure 1
Figure 2
SuperRail Installation Inst. Rev. 2/23/2003
20,500 PARTS LIST
Ref.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15,500 PARTS LIST
Ref.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Part # Part Name
3601 Plate
98410111 Clevis Pin
98410127 Clevis Pin Clip
0802 Rocker Arm
0803 Crossmember
98200142 1/2" Lock Washer
98150153 1/2"-13 Hex Nut
98010147 Rocker Arm Pivot Bolt
98010167 1/2"-13 x 1 1/2" HHCS
0804 Base
98410127 Clevis Pin Clip
08060001 Base Rail Hinge Pin
98200124 3/4" Split Lock Washer
98150131 3/4"-10 Hex Nut
Part # Part Name
3601 Plate
98410111 Clevis Pin
98410127 Clevis Pin Clip
0802 Rocker Arm
1202 Crossmember
98200142 1/2" Lock Washer
98150153 1/2"-13 Hex Nut
98010147 Rocker Arm Pivot Bolt
98010167 1/2"-13 x 1 1/2" HHCS
1203 Base Sides (set)
98410560 Plastic Barbed Fastener
120302 Cover Assembly
98410127 Clevis Pin Clip
08060001 Base Rail Hinge Pin
98200124 3/4" Split Lock Washer
98150131 3/4"-10 Hex Nut
Page 3
Table 1
Table 2
