PullRite Super 5th SuperRail Mounting Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SuperRail Mounting Kit
The following Kits fit both the 6' and the 8' truck beds.
See Specifications for . . . . . . . . . . . . . . . . 15,500 lb. Super 5th Wheel Hitch, P/N 1200
or . . . . . . . . . . . . . . . . . . . .20,500 lb. Super 5th Wheel Hitch, P/N 0800
See page 7, Truck Bed Layout Table, for hitch location ahead of axle.
Important Notes:
1. Trucks with bed liners may need a tall Mounting Post. See "NOTE" under item 4 of
"Drilling the Bed" on pg. 3 for details.
Introduction
This guide provides several pages of instructions for the installation of the SuperRail towing system
Read these instructions completely and follow them accurately. Should you have any questions, please
call the factory at (800) 443-2307 for installation assistance.
SuperRail Installation Inst. Rev. 2/23/2003
Mounting Instructions

Specifications

Pullrite/Pulliam Enterprises, Inc.
13790 E. Jefferson Blvd.
Mishawaka, IN 46545
(219) 259-1520
Fax (219) 258-0289
www.pullrite.com • info@pullrite.com
:
Page 1
