UGO BASILE 7025 Series Instruction Manual

Rodent ventilator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
instruction manual
Rodent Ventilator
Cat. No. 7025 / 7125
UGO BASILE S.R.L.
sales@ugobasile.com / service@ugobasile.com www.
.com
ugobasile

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7025 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for UGO BASILE 7025 Series

  • Page 1 Rodent Ventilator Cat. No. 7025 / 7125 UGO BASILE S.R.L. sales@ugobasile.com / service@ugobasile.com www. .com ugobasile...
  • Page 2 THE INSTRUMENT IN SAFE CONDITIONS. SERVICE AND ADJUSTMENTS SHOULD BE CARRIED OUT BY QUALIFIED PERSON- NEL, AUTHORIZED BY UGO BASILE ORGANIZATION. ANY ADJUSTMENT, MAINTENANCE AND REPAIR OF THE OPENED INSTRUMENT UN- DER VOLTAGE SHOULD BE AVOIDED AS MUCH AS POSSIBLE AND, WHEN INEVITA- BLE, SHOULD BE CARRIED OUT BY A SKILLED PERSON WHO IS AWARE OF THE HAZARD INVOLVED.

  • Page 3: Main Features

    Dr. Nicholas Price, Monash University Main Features Interchangeable cylinder/piston assemblies (5, 10, 30ml) Quiet operation, both acustically and electrically (negligible R.F. broadcasting) Reliable mechanics and impeccable finishing: lifelong lasting Synchronised START/STOP function available as optional Ugo Basile: more than 10,000 citations...
  • Page 4 CHECK-LIST 7025 Rodent Ventilator, 10 ml 7025-30 Rodent Ventilator, 30 ml 7025-5 Rodent Ventilator, 5 ml 7025-1 Rodent Ventilator, 5 ml 7125 Rodent Ventilator, Start/Stop, 10 ml 7125-30 Rodent Ventilator, Start/Stop, 30 ml 7125-5 Rodent Ventilator, Start/Stop, 5 ml 7125-1 Rodent Ventilator, Start/Stop, 1 ml CLIENTE / CUSTOMER______________________________________________ Ordine No.

  • Page 5: Table Of Contents

    Page i 7025 Instruction Manual (Rev.2) C O N T E N T S GENERAL ......................1     START/STOP 7125 ............ 1     YNCHRONIZED ON MODEL INSTRUMENT DESCRIPTION ................1     ......................1     INEMATICS & V ...................
  • Page 6 Page ii 7025 Instruction Manual (Rev. 2) ....................... 14     REQUENCY SERVICING ..................... 15     ..................... 15     EAKAGE ............16     CCESS TO THE NSIDE OF THE NSTRUMENT .................... 16     ALIBRATION INSTRUMENT SPECIFICATIONS ..............

  • Page 7: General

    Page 1 7025 Instruction Manual (Rev. 2) Rodent Ventilator Cat. 7 0 2 5 / 7 1 2 5 GENERAL The 7025 Rodent Ventilator is a mechanically unique positive pressure pump, according to Starling’s ventilation method, designed for use with guinea pigs, rats, mice and small birds, which features: Mechanically, a unique valve gear with negligible dead space...

  • Page 8: Cylinder/Piston & Valve

    Page 2 7025 Instruction Manual (Rev. 2)  The piston almost touches the cylinder end at each stroke, regardless of the pre-set volume. This ensures that all air taken into the pump is expelled with each stroke. Figure 1 “Linkage” ...

  • Page 9: Pump Frame

    Page 3 7025 Instruction Manual (Rev. 2) Particular care has been taken in finishing the cylinder inside surface (diamond lapping), to minimize the O-ring wear. The piston fits snugly inside the cylinder and is made airtight by two conveniently spaced O-rings. The slide valve is placed perpendicular to the cylinder to minimize dead space, and is operated by a crank-link mechanism (4-8, see Figure 1 “Linkage”).

  • Page 10: Notes On The Instruction Manual

    Page 4 7025 Instruction Manual (Rev. 2) Notes on the Instruction Manual The 7025 Instruction Manual included in the package (on the USB drive) is necessary for the correct installation and operation of the instrument. We recommend reading the manual with attention, as it is essential for the correct instal- lation and operation of the instrument.

  • Page 11: Additional Safety Consideration

    Do not spray any liquid on the connectors. Use only acceptable, commercially available anaesthetic agents with this ven- tilator. UGO BASILE DOES NOT ACCEPT ANY RESPONSIBILITY FOR PROB-LEMS OR HARM CAUSED TO THINGS OR PERSONS ARISING FROM:  incorrect electrical supply.

  • Page 12: Rate

    Page 6 7025 Instruction Manual (Rev. 2) Rate The speed control potentiometer adjusts the geared motor to the desired speed, which is indicated on the 3-digit LED display labelled STROKE P.M. (see Figure 3 “Front Panel”). The speed is unaffected by either mains voltage variations or changes of torque load brought about by different stroke volumes, different cylinder/piston combinations, airway alterations, status of the lubrication, etc.

  • Page 13: Ventilation Standards For Small Mammals

    Page 7 7025 Instruction Manual (Rev. 2) Ventilation Standards for Small Mammals For a deeper evaluation of all the parameters involved in the artificial ventilation of exper- imental animals, we suggest the operator to read the basic paper on this subject: L.I. Kleinman &...

  • Page 14: Connection To Animal

    Room air or any anaesthetic gas mixture can be used to feed the pump intake. MAINTENANCE While any service of the instrument ought to be carried out by Ugo Basile personnel or by qualified personnel authorized by UGO BASILE organization, this section of the instruc- tion manuals describes normal maintenance procedures which can be carried out at your facility.

  • Page 15: Mechanical

    Page 9 7025 Instruction Manual (Rev. 2) Mechanical 5.2.1 Changing Cylinder/Piston Assembly To replace the cylinder/piston assembly proceed as follows: Run the pump until the piston is at a rearward position, that is, away from the valve block. Using the 3 mm Allen wrench provided, remove the two screws (18, see Figure 6 “Cylinder/Piston Assembly”), accessible from the air port side, which fasten the cylinder to the valve block.

  • Page 16: Lubricating Linkage

    Page 10 7025 Instruction Manual (Rev. 2) Remove the 4mm Allen screw (19) from the shaft of the triple joint (2), then lift the cylinder and piston link assembly in one piece, to disengage the link from the precision triple joint shaft (20). Once you have removed the combination cylinder/piston, drive out the piston.

  • Page 17: Lubricating Cylinder/Piston

    Page 11 7025 Instruction Manual (Rev. 2) The eccentric (3) and the valve link pin (4) are provided with sealed bearings which are permanently lubricated and protected from dust: they may require attention after several thousand hours of operation, at which time a major overhaul of the entire mechanism is recommended.

  • Page 18: Long Inactivity

    Page 12 7025 Instruction Manual (Rev. 2) Both mechanisms may require inspection during major overhaul, after several thousand hours of operation, just as the previously mentioned (see paragraph 5.2.2-Lubricating Linkage) valve link pin and eccentric ball bearing. A large-size fine-pitch (MB12) set screw (25) presses a nylon pad against the bottom sur- face of the disk.

  • Page 19: Customer Support

    (or our local distributor) either directly of via the support page on our website http://www.ugobasile.com/support.html UGO BASILE s.r.l. Via G. Di Vittorio 2 21036 GEMONIO – Varese, ITALY Phone : +39 0332 744574 service@ugobasile.com...

  • Page 20: Figure 8 "Checking Stroke Volume

    Page 14 7025 Instruction Manual (Rev. 2) Attach a clean, freely moving 10ml (or 30ml) glass syringe via a short (5cm) length of tubing to the stem of a “Y” connector. Adjust the plunger so that 1-2 ml (or 3-6 ml) of air is in the syringe, before attaching the tube. Figure 8 “Checking Stroke Volume”...
  • Page 21 Page 15 7025 Instruction Manual (Rev. 2) Elapsed time should be 10 seconds. A more precise measure would involve (if you have the patience to count!) counting more strokes, e.g., 20-30. In this way, the reaction time of the operator affects the precision to a lesser degree. Repeat the measure at different speeds;...

  • Page 22: Figure 10 "Access To The Inside Of The Instrument

    Page 16 7025 Instruction Manual (Rev. 2) In case you need to remove the valve block, please refer to paragraph 7.2-Access to the Inside of the Instrument. The block is fastened by two M5 screws, whose heads are easi- ly located on the back of the supporting plate. Access to the Inside of the Instrument Access to the inside of the instrument is immediate.
  • Page 23 Page 17 7025 Instruction Manual (Rev. 2) P.C.B. handling, e.g., to replace a component, may in the long run combine to produce a shifting of the rated speed values. Proceed as follows: Open the instrument (see paragraph 7.2-Access to the Inside of the Instru- ment).

  • Page 24: Vailable C Onfigurations

    Page 18 7025 Instruction Manual (Rev. 2) Operating Temperature 5° to 30° C Sound Level < 70 dB Physical Total Weight 9.5 Kg Shipping Weight 16 Kg approx. Dimensions 27x26x19cm Packing Dimensions 67x42x53cm Warranty 7025 is covered by a 24-month warranty ORDERING INFORMATION 7025 Rodent Ventilator,...

  • Page 25: Vailable C Ylinder /P Iston & A Ccessories

    Page 19 7025 Instruction Manual (Rev. 2) 7125-1 Rodent Ventilator, provided with START/STOP circuit, complete with 1 ml cylinder/piston & standard accessories Other Available Cylinder/Piston & Accessories 7025-150 Connection Kit for Anesthesia System to Ventilator 7025 7131 1 ml Cylinder/Piston Assembly, complete with suitable link 7128 5 ml Cylinder/Piston Assembly, complete with suitable link 7026...
  • Page 26 Page 20 7025 Instruction Manual (Rev. 2) 28025 Mouse Ventilator, complete with 1 ml cylinder/piston assembly & standard accessories. 6025 Cat/Rabbit Ventilator, complete with 50ml cylinder/piston assembly and standard accessories. Universal input 85-264 VAC, 50-60Hz 5025 Dog Ventilator, complete with 700ml cylinder/piston assembly and standard accessories For each model, different configurations are available We also offer a complete line of Anesthesia Systems and accessories, series 21100, the ideal match to our Ventilators!
  • Page 27 Page 21 7025 Instruction Manual (Rev. 2) BIBLIOGRAPHY  T.T. Troelsen et alia: “ Impaired NO-mediated vasodilatation in rat coronary arter- ” Acta Anaesthesiologica Scandinavica 59(5): ies after asphyxial cardiac arrest 654–667, 2015  J. K. Marshall et alia: “Intra-Operative Tissue Oxygen Tension Is Increased by Local Insufflation of Humidified-Warm CO2 during Open Abdominal Surgery in a Rat Model”...
  • Page 28 N o t e s _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
  • Page 29 N o t e s _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
  • Page 30 N o t e s _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
  • Page 31 CE CONFORMITY STATEMENT Manufacturer UGO BASILE srl Address Via G. di Vittorio, 2 – 21036 Gemonio, VA, ITALY Phone n. +39 0332 744574 Fax n. +39 0332 745488 We hereby declare that Instrument. RODENT VENTILATOR Catalog number 7025, 7125 It is manufactured in compliance with the following European Union Directives and relevant harmonized standards ...
