Lumitester PD-30
Control Software
Instruction Manual
Thank you very much for purchasing the Lumitester PD-30.
All of this Instruction Manual must be read before
operation of this product for safe and proper use. This
Instruction Manual should be kept for future reference.

Table of Contents

1
1
1
2
2
2
3
3
7
10
10
12
12
13
13
14
14
16
19
20
20
21
23
23
23
26
27
28
29
30
31
32
