Graham-Patten Avenue 6010 Manual

Four channel 20-bit audio adc data pack
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Four Channel
20-Bit Audio ADC
This data pack provides detailed installation, configuration and operation information for
the Model 6010 Four Channel 20-bit Audio Analog to Digital Converter (ADC)
module as part of the Avenue Signal Integration System.
The module information in this data pack is organized into the following sections:
• Module Overview
• Applications
• Installation
• Cabling
• Module Configuration and Control
Front Panel Controls and Indicators
°
Avenue PC Remote Control
°
Avenue Touch Screen Remote Control
°
• Troubleshooting
• Software Updating
• Warranty and Factory Service
• Specifications
Model 6010
Data Pack
Revision 3.1 SW v1.0.0
6010-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Avenue 6010 and is the answer not in the manual?

Questions and answers

Related Manuals for Graham-Patten Avenue 6010

Summary of Contents for Graham-Patten Avenue 6010

  • Page 1 Model 6010 Four Channel 20-Bit Audio ADC Data Pack Revision 3.1 SW v1.0.0 This data pack provides detailed installation, configuration and operation information for the Model 6010 Four Channel 20-bit Audio Analog to Digital Converter (ADC) module as part of the Avenue Signal Integration System. The module information in this data pack is organized into the following sections: •...

  • Page 2: Module Overview

    Model 6010 Four Channel 20-bit Audio ADC MODULE OVERVIEW The 6010 Four Channel 20-bit Analog to Digital Converter (ADC) converts four channels of analog audio to two AES digital audio streams. Analog to digital conversion is performed with 20-bit precision. As shown in the block diagram below, four high impedance balanced analog audio inputs enter the module on a high density 15-pin connector.
  • Page 3 Model 6010 Four Channel 20-bit Audio ADC APPLICATIONS Converting Analog VTR Audio Output to Digital In the application shown below, a 6010 module converts the audio outputs of an analog VTR to digital. Note that a 6030 Video Referenced AES/Word Clock Generator module provides an AES clock reference for the 6010 module.
  • Page 4 Model 6010 Four Channel 20-bit Audio ADC Converting Audio Outputs of Two Independent 2-Track Analog Tape Recorders Even though it is a four channel device, the 6010 utilizes two separate 2-channel A/D con- verters. In this application, a 6010 module converts the audio outputs of two independent 2-track analog audio tape recorders to digital.

  • Page 5: Installation

    Model 6010 Four Channel 20-bit Audio ADC INSTALLATION Plug the 6010 module into any one of the ten slots in the frame and install the plastic overlay provided onto the corresponding group of rear BNC connectors associated with the module location. Note that the plastic overlay has an optional adhesive backing for securing it to the frame.

  • Page 6: Module Configuration And Control

    Model 6010 Four Channel 20-bit Audio ADC MODULE CONFIGURATION AND CONTROL The parameters for each Avenue module must be configured after installation. This can be done remotely using one of the Avenue remote control options or locally using the module front panel controls.
  • Page 7 Model 6010 Four Channel 20-bit Audio ADC Front Panel Controls and Indicators Each front edge indicator and switch setting is explained in the diagram below: EXT REF green LED: ON indicates valid external reference signal is present. OFF indicates the external reference is missing or invalid.
  • Page 8 Model 6010 Four Channel 20-bit Audio ADC Avenue PC Remote Configuration The Avenue PC remote control menus for this module are illustrated and explained in this section. Refer to the 6010 Parameter Table shown earlier for a summary of available parameters that can be set remotely through the menus illustrated.
  • Page 9 Model 6010 Four Channel 20-bit Audio ADC In the Ch 1/2 Menu shown below, set the following parameters: • Ch 1/2 Mode - set the operating modes for Channels 1 and 2. Choose from 2-Channel (Ch 1 and 2 will be independent), Stereo (Ch 1/2 will be a stereo pair) or Quad Tracking (Ch 1-4 will track together).
  • Page 10 Model 6010 Four Channel 20-bit Audio ADC In the Ch 3/4 Menu shown below, set the following parameters: • Ch 3/4 Mode - set the operating modes for Channels 3 and 4. Choose from 2-Channel (Ch 3 and 4 will be independent), Stereo (Ch 3/4 will be a stereo pair) or Quad Tracking (Ch 1-4 will track together).
  • Page 11 Model 6010 Four Channel 20-bit Audio ADC The Quad Menu shown below has been provided to allow adjusting and monitoring all four channels at the same time when in Quad Tracking mode. Set the parameters as follows: • Channel Mode - Click in the Quad On box to enable quad tracking simultane- ously for all four channels.
  • Page 12 Model 6010 Four Channel 20-bit Audio ADC Avenue Touch Screen Remote Configuration Avenue Touch Screen remote control menus for this module are illustrated and explained below. Refer to the 6010 Parameter Table shown previously for a summary of available parameters that can be set remotely through the menus illustrated. For more information on using Avenue Touch Screen, refer to the Avenue Touch Screen data pack that came with the option.
  • Page 13 Model 6010 Four Channel 20-bit Audio ADC In the Ch 2 Menu shown below, set the following parameters: • Ch 1/2 Mode - set the operating modes for Channels 1 and 2. Choose from 2-Channel (Ch 1 and 2 will be independent), Stereo (Ch 1/2 will be a stereo pair) or Quad Tracking (Ch 1-4 will track together).
  • Page 14 Model 6010 Four Channel 20-bit Audio ADC In the Ch 3 Menu shown below, set the following parameters: • Ch 3/4 Mode - set the operating modes for Channels 3 and 4. Choose from 2-Channel (Ch 3 and 4 will be independent), Stereo (Ch 3/4 will be a stereo pair) or Quad Tracking (Ch 1-4 will track together).
  • Page 15 Model 6010 Four Channel 20-bit Audio ADC In the Ch 4 Menu shown below, set the following parameters: • Ch 3/4 Mode - set the operating modes for Channels 3 and 4. Choose from 2-Channel (Ch 3 and 4 will be independent), Stereo (Ch 3/4 will be a stereo pair) or Quad Tracking (Ch 1-4 will track together).
  • Page 16 Model 6010 Four Channel 20-bit Audio ADC The Quad Menu shown below has been provided to allow adjusting and monitoring all four channels at the same time when in Quad Tracking mode. Set the parameters as follows: • Channel Mode - Click in the Quad On box to enable quad tracking simultane- ously for all four channels.

  • Page 17: Troubleshooting

    • Check for presence and validity of external reference input signal if required. (6010 will default to 48kHz internally.) You may also refer to the technical support section of the Ensemble or Graham-Patten web sites for the latest information on your equipment at the URLs below: http://www.ensembledesigns.com/support...

  • Page 18: Warranty And Factory Service

    If you require service (under warranty or not), please contact Ensemble Designs or Graham-Patten Systems and ask for customer service before you return the unit. This will allow the service technician to provide any other suggestions for identifying the problem and recommend possible solutions.

  • Page 19: Specifications

    Model 6010 Four Channel 20-bit Audio ADC SPECIFICATIONS 6010 Four Channel 20-bit Audio ADC Analog Input Z: >15k ohms, balanced, tranformerless CMRR: >60dB, 20Hz - 10kHz Analog Input Reference Level: -10dBu to +8dBu Digital Output Reference Level: -16, -18, -20dBFS AES3id reference input: 1 volt p-p, terminated in 75 ohms...
