- Page 1 WOA5300-20 Operation Instruction Please read the instruction carefully before using the product and keep it properly...
- Page 2 Thank you for choosing SKSpruce out access ponint WOA5300-20. SKSpruce WOA5300-20 is a high performance, dual-band outdoor wireless access point designed to meet rapidly rising demand for high capacity and bandwidth in outdoor applications. Compliant with IEEE 802.11a/b/g/n/ac standards and supporting MU-MIMO and 2x2 MIMO, the WOA5300-20 is capable of high throughput up to 1.267 Gbps.
-
Page 3: Fcc Statement
FCC Statement FCC RF Radiation Exposure Statement General Statement This equipment has been tested and found to comply with the This equipment complies with FCC radiation exposure limits limits for a Class B digital device, pursuant to part 15 of the set forth for an uncontrolled environment and it also complies FCC Rules. -
Page 4: Product Introduction
Product Introduction Front Port Introduction POW WAN LAN 2.4G POW WAN SFP 2.4G WAN(PoE) CONSOLE CONSOLE WAN(POE) SFP/LAN Grounding POWER Power Indicator GE WAN Port SFP Port CONSOLE Port WAN Port Indicator Back SFP Port Indicator 2.4G WLAN Indicator 5G WLAN Indicator... -
Page 5: Specifications
Specifications Item Description Item Description Power input 802.3at power over Ethernet (PoE) 802.11n/ac Automatic channel scanning 20 MHz/40 MHz channel bandwidth Overall power consumption < 25 W (802.11.ac supports 80 MHz) Dimensions (W x D x H) 9.41" x 7.68" x 3.35" A-MPDU, A-MSDU (239 mm x 195 mm x 83 mm) Dynamic power scaling... -
Page 6: Preparing Installation
Preparing Installation Tools and Evironment Requirements To ensure the outdoor AP set is in good condition for a long Item Requirement time, the system shall work under the specified operating Operating temperature: -30℃ ~65℃ environment. Avoid strong vibrations or noises and keep Relative humidity: 0%~95% noncondensing away from step-down transformer substations and traction Environment... -
Page 7: Installation Kit
Installation Kit All-aluminum bracket kit Before installing the equipment, first select the standard or custom-sized mounting kit according to the thickness of the pole. According to the different customer needs, the installation kit is divided into all-aluminum bracket kit and aluminum alloy bracket + steel band clamp kit: •... -
Page 8: Installing The Equipment
Installing the Equipment Assembling Pole-mount Kit ① Before installing the equipment, assemble the kit as is shown ② All-aluminum bracket kit installation is as shown below: below: Pole Equipment Pole-mount kit... -
Page 9: Wall Mount Installation
Wall-mount Installation The expansion bolts will be used when installing the AP onto the wall. Please prepare the flat washers, play washers, nuts and 2 expansion bolts (M6 x 60 or M6 x 80). Draw 2 bolt hole locations with the relative distance of 121 mm in the horizontal direction. - Page 10 Debugging If you need to adjust the angle of the equipment, you can use the wrench to adjust the 2 bolts as is shown below: Customer Service: 4000367800 Manufacturer: SKSpruce Technologies Official Website: www.skspruce.com...
-
Page 11: Warranty Instructions
Warranty Instructions Hardware damage caused by any behavior that does not Thank you for choosing SKSpruce Technologies products. For comply with the operating instructions will take the normal your interests, please read the instructions carefully. maintenance procedure and will charge the customer for maintenance and shipping. -
Page 12: Warranty Card
□ Dissatisfied Product: Model: Item: Serial number: After sale: Signature: Date of purchase: □ Satisfied □ Dissatisfied Manufacturer stamp:（Take effect after being stamped） Item: After sale: Signature: Customer Service: 4000367800 □ Satisfied □ Dissatisfied Manufacturer: SKSpruce Technologies Official Website: www.skspruce.com...
