San Jose
1885 Lundy Ave., Suite 270,
San Jose, CA 95131, USA
Tel: +1 (408) 449-5604
Hong Kong
15K International Industrial
Centre, 2-8 Kwei Tei Street,
Shatin, Hong Kong
Tel: +852 26983874
Chengdu
A1, Tianfu Software Park, 1129
Century City Road, High-tech
Zone, Chengdu, Sichuan, P.R.
China
Tel: +86 28 85231119
http://www.skspruce.com/
Indoor Access Point
WIA3300-20
User Manual
Revision: 01
Issued on 2017-06-24
SKSpruce Technologies
Advertisement
Related Manuals for SKSpruce WIA3300-20
Summary of Contents for SKSpruce WIA3300-20
-
Page 1: User Manual
San Jose 1885 Lundy Ave., Suite 270, WIA3300-20 San Jose, CA 95131, USA Tel: +1 (408) 449-5604 Indoor Access Point User Manual Hong Kong 15K International Industrial Centre, 2-8 Kwei Tei Street, Shatin, Hong Kong Tel: +852 26983874 Revision: 01... - Page 2 No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without prior, express and written permission from our company, Inc. Our company reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of our company to provide notification of such revision or changes.
- Page 3 Ethernet (P PoE+), maki ing installat ion easy. Th WIA3300-20 0 delivers o outstanding p performanc ce in dense i indoor urban setting gs, such as t transit cente ers, malls, c...
- Page 4 Easy to deploy, simple to manage PoE+ support and built-in high performance antennas Ceiling or wall mounting options Feature-rich AP with centralized optimization and management Supports innovative AP functions, such as PPPoE, Network Address Translation, and DHCP server/client, wireless SSID and encryption settings Zero-touch join and configuration Physical Specifications 802.3 at power over Ethernet (PoE)
- Page 5 3. Inst tallation Ceiling-mo ount Install lation Operation S Steps： Step 1 C Cut an open ning of 235 mm in diam meter in the e ceiling. Step 2 P Put the AP inside the c ceiling near the opening g and comp lete the netw working con...
- Page 6 Step 4 P Put the equi ipment onto o the holder r to compete e the installa ation. Wall-moun nt Installat Two slots o on the bed o f this equip pment are us sed for insta allation on t the wall.
- Page 7 Step 1 T To determine e the mount ting point, c choose a cen ntral positio on far away from interference e sources (su uch as micr rowave oven ns and cordl less phones Step 2 D Drill two hol les 128mm apart on the e selected w...
- Page 8 Step 2 (O Optional) In nsert one en nd of the pow wer adapter r (smaller on ne) on the b back of the power switc ch, and inse ert the bigge er end into p power socke Step 3 S et up wirele ess data link k: on Windo...
- Page 9 4. Tune up procedure 4.1 Network Configuration Connect the Ethernet cable to WIA3300-20 ETH2 Port （LAN Port）, the default IP address is 192.168.18.1. Telnet Login telnet 192.168.18.1 User Name: admin Password:5upS%k! Connection Equipment Default SSID(skspruce-xxxx) “skspruce-XXXX”(XXXX represent the latter 4 characters of MAC address. SSID default is WPA2-PSKencrption，password:12345678...
- Page 10 4.2 Configuration (2.4G) Working Setting Open RF uci set wireless.wifi0.disabled=0 uci commit2 wireless wifi The command is still valid after reboot. Close RF uci set wireless.wifi0.disabled=1 uci commit2 wireless wifi The command is still valid after reboot. Set Channels Set channel 6，the command below, uci set wireless.wifi0.channel=6 uci commit2 wireless...
- Page 11 4.3 Configuration (5G) 5G Working Setting Open RF uci set wireless.wifi1.disabled=0 uci set wireless.@wifi-iface[2].set11NRates=0x80808080 uci set wireless.@wifi-iface[3].set11NRates=0x80808080 uci commit2 wireless wifi The command is still valid after reboot. Close RF uci set wireless.wifi1.disabled=1 uci commit2 wireless wifi The command is still valid after reboot. Set Channels Set Channel 60，the command below, uci set wireless.wifi1.channel=60...
-
Page 12: Fcc Warning
if set other values，directly change HT20 above-mentioned，the value range：HT20、HT40、 ac80 The command is still valid after reboot. FCC Warning Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 13 FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body 12 ...
