Optional Beauty Dish Adapter Insert Ring; Specifications - GLOW EZ Lock Octa Quick Softbox Manual

Optional Beauty Dish Adapter Insert Ring

Speedring Mount Adapter Insert
The EZ Lock octa quick softbox includes an installed 130mm Bowens mount
insert for use on Bowens mount strobes.
To change the insert ring to fit onto a different flash mount:
1. Stretch the fabric in the rear of the softbox to reveal one of the
tab screws.
2. Unscrew that one entirely and set it aside. You only need to loosen the
two adjoining screws enough for the insert to slip out of the tabs.
3. Remove it and replace the insert with your mount version.
4. Put to removed screw back into place and tighten all the screws.

SPECIFICATIONS

Materials Reinforced Fabric, Aluminum Rods, Aluminum Ring
Finish Silver interior, black matte exterior, custom trim
Mount
Interchangeable Bowens speedring supplied (Insert Size 130mm)
Sections 8
Removable Front Diffusor
Removable Interior Baffle
Accepts Grids
Speedring 130mm insert
Specifications
Diameter open
Depth open
Weight
Dimensions closed
No accessories are included in the weights or measurements
7
Yes
Yes
Yes (included)
GLSBEZ25OCTA
25" / 63.5cm
11.75" / 30cm
1lb 3.5oz / 552g
15x6"/38x15.3cm
GLSBEZ36OCTA
36" / 91.5cm
19.25" / 49cm
2lb 1.5oz / 952g
25x6"/63.5x15.3cm
GlowLightControl.com
130mm
GLSBEZ48OCTA
44" / 112cm
26" / 66cm
2lb 12oz / 1.25kg
34x6"/86.4x15.3cm
