This manual and the information contained herein are provided for use as an operation and
maintenance guide. No license or rights to manufacture, reproduce, or sell either the manual or
articles described herein are given. Amron International, Inc. reserves the right to change
specifications without notice. Copyright© 2013 Amron International, Inc.
8895-UM
User Manual
for
Amron International, Inc.
Model 8895-AMP-8
Model 8895-AMP-16
S/N______________________
1380 Aspen Way, Vista California 92081-8349
United States of America
Phone: (760) 208-6500
Fax (760) 599-3857
email: sales@amronintl.com
web: www.amronintl.com
REV 1.0
Advertisement
Table of Contents
Related Manuals for Amron 8895-AMP-8
Summary of Contents for Amron 8895-AMP-8
- Page 1 This manual and the information contained herein are provided for use as an operation and maintenance guide. No license or rights to manufacture, reproduce, or sell either the manual or articles described herein are given. Amron International, Inc. reserves the right to change specifications without notice. Copyright© 2013 Amron International, Inc.
-
Page 2: Table Of Contents
OUTSIDE JUNCTION BOX DIAGRAM MODEL 8895-700 ................22 7.11 INSIDE JUNCTION BOX DIAGRAM MODEL 8895-800 ..................23 7.12 PARTS IDENTIFIER MODEL 8895-AMP-8 & -16, FRONT ................24 7.13 PARTS IDENTIFIER MODEL 8895-AMP-8, BACK .................... 25 7.14 PARTS IDENTIFIER MODEL 8895-AMP-16, BACK ..................26 7.15... - Page 3 7.18 PARTS IDENTIFIER MODEL 8895-800 ......................30 PARTS LIST GENERAL ............................ 31 MODEL 8895-AMP-8, TOP ASSEMBLY ......................32 MODEL 8895-AMP-16, TOP ASSEMBLY ......................32 MODEL 8895-005, PNEUMATIC HEADSET FOR O2 HOOD ................33 MODEL 8895-100, PATIENT ENTERTAINMENT SET ..................33 MODEL 8895-600, CABLE ASSEMBLY, 20 FOOT LENGTH ................
-
Page 4: Introduction And Specifications
8895-AMP-8 and sixteen can be driven by the 8895-AMP-16. A 110/220 volt selector switch is located on the rear of both the Model 8895-AMP-8 & 8895- AMP-16. Select the desired voltage by turning the sector switch with a small slotted screwdriver. -
Page 5: Mechanical
MODEL 8895 USER MANUAL MECHANICAL Enclosure ..................Black Anodized Aluminum Length ......................13.0 in. (33.0 cm) Width ......................17.0 in. (43.2 cm) Height ....................... 3.5 in. (8.9 cm) Weight ......................7.3 Lbs. (3.3 kg) 8895-UM REV 1.0... -
Page 6: Warranty And Service Policy
90 days from date of shipment. Amron’s obligations under this warranty are limited to the repair of, or replacement of materials at Amron’s discretion. This warranty shall not cover defects which are the result of misuse, negligence, accident, repair, or alterations. -
Page 7: Accessories
Q. D.) 8895-600 Cable Assembly connects amplifier 8895-AMP-8 to outside junction box on chamber. Handles audio and channel selection signals for up to 8 patient entertainment modules. Two cable assemblies required for the 8895-AMP-16 amplifier unit. Cable Assembly is 20 feet long, other lengths available on special order. -
Page 8: Controls And Connections
MODEL 8895 USER MANUAL CONTROLS AND CONNECTIONS Before using the Entertainment System, you should familiarize yourself with the controls and connections. Improper use of the controls and connections may deprive the user of the full benefits of the system. FRONT PANEL CONTROLS Power Switch –... -
Page 9: Operation
Once a proper level is achieved no further adjustment should be necessary. THEORY OF OPERATION The 8895-AMP-8 & 8895-AMP-16 are built in two configurations, an 8-patient and a 16- patient version. There are eight output audio amplifiers in the -8 and sixteen in the -16, each driving one patient entertainment module. - Page 10 MODEL 8895 USER MANUAL The entertainment module contains an audio transducer which produces an audio sound pressure wave to drive a pneumatic headset. The entertainment module has a diaphragm to separate the transducer from the sound tube. This prevents the possibility of the back flow of oxygen into the transducer when the headset is being used in an oxygen enriched area such as an oxygen treatment hood.
-
Page 11: Functional Block Diagram
MODEL 8895 USER MANUAL FUNCTIONAL BLOCK DIAGRAM 8895-UM REV 1.0... -
Page 12: Maintenance
10 PSI of air. The module should hold this pressure without loss for a period of 60 seconds. If the unit does not hold pressure, do not use this patient entertainment module/headset in an oxygen enriched environment and return to Amron for service. No other specific routine maintenance is required. -
Page 13: Drawings
The corresponding parts lists for each drawing are detailed in the parts lists section, or are included as part of the drawing. All drawings are at their current revision level as of the date of printing. Amron reserves the rights to revise the documentation without notification. 8895-UM... -
Page 14: Schematic, Model 8895-Amp-8
MODEL 8895 USER MANUAL SCHEMATIC, MODEL 8895-AMP-8 8895-UM REV 1.0... -
Page 15: Schematic, Model 8895-Amp-16
MODEL 8895 USER MANUAL SCHEMATIC, MODEL 8895-AMP-16 8895-UM REV 1.0... -
Page 16: Schematic, Audio 1 & 2 8895-200 Pc Card
MODEL 8895 USER MANUAL SCHEMATIC, AUDIO 1 & 2 8895-200 PC CARD 8895-UM REV 1.0... -
Page 17: Schematic, Audio 3 & 4 8895-200 Pc Card
MODEL 8895 USER MANUAL SCHEMATIC, AUDIO 3 & 4 8895-200 PC CARD 8895-UM REV 1.0... -
Page 18: Schematic, Audio 5 & 6 8895-200 Pc Card
MODEL 8895 USER MANUAL SCHEMATIC, AUDIO 5 & 6 8895-200 PC CARD 8895-UM REV 1.0... -
Page 19: Schematic, Audio 7 & 8 8895-200 Pc Card
MODEL 8895 USER MANUAL SCHEMATIC, AUDIO 7 & 8 8895-200 PC CARD 8895-UM REV 1.0... -
Page 20: Schematic, Input Audio & Power 8895-200 Pc Card
MODEL 8895 USER MANUAL SCHEMATIC, INPUT AUDIO & POWER 8895-200 PC CARD 8895-UM REV 1.0... -
Page 21: System Interconnect Diagram Model 8895
MODEL 8895 USER MANUAL SYSTEM INTERCONNECT DIAGRAM MODEL 8895 8895-UM REV 1.0... -
Page 22: Cable Assembly Model 8895-600
MODEL 8895 USER MANUAL CABLE ASSEMBLY MODEL 8895-600 8895-UM REV 1.0... -
Page 23: Outside Junction Box Diagram Model 8895-700
MODEL 8895 USER MANUAL 7.10 OUTSIDE JUNCTION BOX DIAGRAM MODEL 8895-700 8895-UM REV 1.0... -
Page 24: Inside Junction Box Diagram Model 8895-800
MODEL 8895 USER MANUAL 7.11 INSIDE JUNCTION BOX DIAGRAM MODEL 8895-800 8895-UM REV 1.0... -
Page 25: Parts Identifier Model 8895-Amp-8 & -16, Front
MODEL 8895 USER MANUAL 7.12 PARTS IDENTIFIER MODEL 8895-AMP-8 & -16, FRONT 8895-UM REV 1.0... -
Page 26: Parts Identifier Model 8895-Amp-8, Back
MODEL 8895 USER MANUAL 7.13 PARTS IDENTIFIER MODEL 8895-AMP-8, BACK 8895-UM REV 1.0... -
Page 27: Parts Identifier Model 8895-Amp-16, Back
MODEL 8895 USER MANUAL 7.14 PARTS IDENTIFIER MODEL 8895-AMP-16, BACK 8895-UM REV 1.0... -
Page 28: Outside Junction Box Model 8895-700
MODEL 8895 USER MANUAL 7.15 OUTSIDE JUNCTION BOX MODEL 8895-700 8895-UM REV 1.0... -
Page 29: Parts Identifier Model 8895-700
MODEL 8895 USER MANUAL 7.16 PARTS IDENTIFIER MODEL 8895-700 8895-UM REV 1.0... -
Page 30: Inside Junction Box Model 8895-800
MODEL 8895 USER MANUAL 7.17 INSIDE JUNCTION BOX MODEL 8895-800 8895-UM REV 1.0... -
Page 31: Parts Identifier Model 8895-800
MODEL 8895 USER MANUAL 7.18 PARTS IDENTIFIER MODEL 8895-800 8895-UM REV 1.0... -
Page 32: Parts List General
REVISIONS The parts lists in this manual are for the current model as of the printing date. To Order Replacement Parts Contact: Amron International, Inc. 1380 Aspen Way, Vista, California, 92081 U.S.A. Telephone: (760) 208-6500 Fax: (760) 599-3857 Email: sales@amronintl.com Web: www.amronintl.com... -
Page 33: Model 8895-Amp-8, Top Assembly
MODEL 8895 USER MANUAL MODEL 8895-AMP-8, TOP ASSEMBLY Reference Part Number Description 8895-001 Front panel 8895-AMP-8 & 16 8895-8-500 Chassis & Rear Panel Assembly 2825R-002 Lid Rack Mount, Top & Bottom 8895-2009 LED, Green Pin point 517-SJ-5003 Rubber Bumper (Foot) Screw, 8-32 X 3/8”... -
Page 34: Model 8895-005, Pneumatic Headset For O2 Hood
MODEL 8895 USER MANUAL MODEL 8895-005, PNEUMATIC HEADSET FOR O2 HOOD Reference Part Number Description 8895-05 Headset not modified 8895-30 Male Q.D. 1/8 X Female 10-32 Tee 1/8” Barb X Male 10-32 8895-35 Gasket, 1/16” X 3/8” X 8” GCCN1/16X3/8 2820-3006 Latex Tubing 1/8ID X 1/32W MODEL 8895-100, PATIENT ENTERTAINMENT SET... -
Page 35: Model 8895-700, Junction Box (Outside)
MODEL 8895 USER MANUAL MODEL 8895-700, JUNCTION BOX (OUTSIDE) Reference Part Number Description MP-3125GC4-001 Cover, Junction Box 3125-052 Bracket, Junction box 3127-003 Bushing, Female Penetrator, ¾” NPT Brass 28072-1-1 MS-3102A28-16S MS Connector, 20 Pin Female 568-6-140 Terminal Block, 6 Position 5-6/18-22 Ring Terminal, un-insulated 3500... -
Page 36: Model 8895-800, Junction Box (Inside)
MODEL 8895 USER MANUAL MODEL 8895-800, JUNCTION BOX (INSIDE) Reference Part Number Description MP-3125GC4-001 Cover, Junction Box 3125-052 Bracket, Junction Box 3127-003 Busing, Female Grommet, ½’’ 3219 568-6-140 Terminal Block, 6 Position 2613 Plug, Hole .312 2623-HEYCO Plug, Hole .375 10-32X1/2SSPHP Screw, 10-32 X ½... - Page 37 MODEL 8895 USER MANUAL Reference Part Number Description 09-50-7051 Connector, Housing 5 Pin 09-50-7131 Connector, Housing 13 Pin 08-56-0106 Terminal Crimp 60619-1 Contact, Socket 512-1415 4 Socket Housing 8895-2005 Cable, Ribbon 10 Conductor Shrink Tubing, 1/8’’ Black TAT-1/8 Shrink Tubing, 3/16’’ Black TAT-3/16 8/18-22 Ring Terminal, #8...
-
Page 38: Model 8895-16-500, Chassis & Rear Panel Assembly
MODEL 8895 USER MANUAL MODEL 8895-16-500, CHASSIS & REAR PANEL ASSEMBLY Reference Part Number Description 8895-015 Chassis Wrap Around 8895-007 Rail, Card Support 2825R-007 Bracket, Support Side Rail 8895-200A P. C. Card Assembly MB2085SS2W30BA Switch, Push button DPDT 51CAD-E24-A15 Potentiometer, PC Mount 10K S101125 Knob, 10 mm black C100... -
Page 39: Model 8895-200A, Pc Card Assembly
MODEL 8895 USER MANUAL Reference Part Number Description 6ISW Washer, Internal Star, #6 8ISW Washer, Internal Star, #8 60619-1 Contact Socket 20-14 AWG (AMP) 8895-2004 Cable Jumper 6 PIN .100 SWA033.4501 Switch 110-222 Vac Line 6X1/4RX1/4INNS Nylon Spacer 1/4RX1/4X NO. 6 Screw 6-32 ½”... - Page 40 MODEL 8895 USER MANUAL Designator Part Number Description C37,38,39.40,60 ME208-50V22 CAPACITOR 22UF 50V C30,29,21,20,11,10,1,2,41,33,25,24,15, 14,6,5,17 ME208-40V1.0 CAPACITOR 1UF 50V C8,9,18,19,27,28,43,44` ME208-50V10 CAPACITOR 10UF 50V T1,2,3,4 42TM017 TRANSFORMER 25K TO 600 .2W 8895-2001 RECTIFIER BRIDGE 2324A-2006 HEADER 4 PIN MAT-N-LOK AC J2,3 41661-0023 HEADERBREAKAWAY.156IN GOLD...
