Page 1: Installation And Operation Manual
INSTALLATION AND OPERATION MANUAL AUDIO CONTRACTOR TOOLS LET’S SPLIT (L) • LET’S SPLIT (M) GET DOWN • GET UP DROP ME • MULTI CAN JUICED UP • BUZZ OFF PRE ME • MIXED UP THE INJECTOR • GET OUT ZONED OUT... -
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION PRÉCAUTIONS DURANT UTILISATION LISEZ ces instructions. Read these instructions. Tenez ces instructions. Keep these instructions. Notez tous les avertissements. Heed all warnings. Suivez toutes les avertissements. Follow all instructions. N’utilisez pas ce produit près de l’eau (la piscine, la plage, le lac, etc.). Do not use this apparatus near water. -
Page 3: Introduction And Contents
INTRODUCTION AND CONTENTS AUDIO CONTRACTOR TOOLS INTRODUCTION Since their introduction the contractor tool range has proved LET’S SPLIT (L) & LET’S SPLIT (M) immensely popular with AV installers all around the world. GET DOWN AND GET UP The entire range of audio contractor tools has been redesigned & expanded to provide even more useful solutions for audio contractors DROP ME AND MULTI CAN the world over. - Page 4 LET’S SPLIT (L) & LET’S SPLIT (M) LINE SPLITTER The LETS SPLIT (L) is a balanced line level splitter with a balanced XLR line level input which provides both a transformer balanced XLR output & a thru (direct) XLR output of the input signal. The LETS SPLIT (L) also provides a ground lift switch to eliminate ground loop hum. REAR PANEL BALANCED XLR INPUT CONNECTOR BALANCED XLR THRU OUTPUT CONNECTOR...
- Page 5 GET DOWN AND GET UP STEREO CONVERTER The GET DOWN stereo converter converts a professional line level balanced audio signal to an unbalanced domestic level signal. Inputs are balanced XLRs & outputs are stereo RCA connectors. The GET DOWN also features a front panel level control for achieving the optimal output level. REAR PANEL STEREO BALANCED LINE LEVEL XLR input connectors...
- Page 6 DROP ME AND MULTI CAN 100 VOLT LINE CONVERTER The DROP ME allows you to convert a 100 volt line amplifier speaker output signal to a balanced line level signal. The 100 volt line signal input is via phoenix connector &...
- Page 7 JUICED UP AND BUZZ OFF DUAL PHANTOM POWER SUPPLY The JUICED UP is a 2 channel phantom power supply that features balanced XLR inputs & outputs per channel. The JUICED UP can operate via the supplied external power supply or via two on board 9 volt batteries, selectable via a rear panel slider switch. The Juiced up will supply 15VDC phantom power via battery power & 42VDC off external power supply REAR PANEL BALANCED XLR INPUT CONNECTOR...
- Page 8 PRE ME MICROPHONE PRE AMPLIFIER The PRE ME is a compact yet highly featured microphone pre amplifier. The PRE ME features dual RCA line input & a balanced XLR input switchable between microphone & line level. The PRE ME also offers +40VDC phantom power, switchable High pass filter (rolling off at dB per octave at 100 Hz & balanced XLR output. A front panel gain control &...
- Page 9 MIXED UP AND THE INJECTOR 4 CHANNEL PASSIVE MIXER The MIXED UP is a passive 4 channel mixer which features 2 balanced XLR microphone inputs & 2 dual RCA line inputs & a single microphone level balanced XLR output. The MIXED UP also offers individual front panel level controls per input. REAR PANEL BALANCED MICROPHONE LEVEL XLR INPUT CONNECTORS...
- Page 10 GET OUT AND ZONED OUT USB TO STEREO CONVERTER The GET OUT is a USB Audio Interface with transformer balanced stereo outputs to avoid hum, noise and earth loops. The computer connection is via a USB “Type B” connector located on the rear panel and the supplied USB cable. The GET OUT is powered by the USB computer connection.
-
Page 11: Specifications
SPECIFICATIONS ALL AUDIO CONTRACTOR TOOLS DIMENSIONS WEIGHT PRE ME 0.5kg Maximun Frequency Response 80Hz - 30kHz SHIPPING DIMENSIONS 246mm x 126mm x 62mm <0.3% (9.7” x 5” x 2.4”) Noise + Hum <-86dBu Mic Max Input -10dBu Line Max Input +16dBu SHIPPING WEIGHT 0.8kg Maximum... - Page 12 ENGINEERED BY AUSTRALIAN MONITOR Address: Level 7, 130 Pitt Street, Sydney NSW 2000 Australia. Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au...
