- Page 1 Flat and Curved Glass Electric Fireplace Operating and Installation Instructions This manual is for use with Furrion FF26S15A-BL Flat Glass Electric Fireplace Furrion FF26C15A-BL Curved Glass Electric Fireplace © 2017 The Furrion Compay, Inc.
- Page 2 Welcome Furrion® FF26S15A-BL Flat Glass Electric Fireplace Furrion® FF26C15A-BL Curved Glass Electric Fireplace Thank you for purchasing a Furrion® FF26S15A-BL Flat Glass Electric Fireplace/ Furrion® FF26C15A-BL Curved Glass Electric Fireplace. SUITABLE FOR DOMESTIC HOUSEHOLD USE, RV’s & MODULAR HOMES Before installation and use, please read all instructions carefully. This will ensure...
-
Page 3: Table Of Contents
Contents IMPORTANT SAFETY INSTRUCTIONS ..........3-5 Installation ..................6-8 Operation ................... 9-10 Troubleshooting ................11-12 Care and maintenance ..............13 Warranty .....................14... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS PLEASE READ ALL OF THE INFORMATION IN THIS OPERATING MANUAL, INCLUDING ALL SAFETY, OPERATING, AND MAINTENANCE INFORMATION. TO AVOID THE POTENTIAL RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, USERS SHOULD FOLLOW THE DIRECTIONS AND WARNINGS IN THIS MANUAL. -
Page 5: Grounding Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: The fireplace This product must be grounded. If it contains hot and potentially should malfunction or breakdown, flammable components. Do proper grounding provides a not use in areas where gaso- path of least resistance for electric line, paint, or other flammable current to flow and reduces the liquids are used or stored. -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 7: Installation
Installation IMPORTANT: Failure to install the built-in electric fireplace as instructed below may result in damage to the equipment and or may expose the user to the risk of fire, serious injury, illness or death. First Time Use Remove the marketing sticker from the front glass. Marketing Sticker... - Page 8 Installation Wall-mount Installation 1. Select a suitable location that is not susceptible to moisture. 2. Mark and cut an opening in the cabinet according to the dimensions outlined in the illustration below. (Fig. A) 3. Ensure the cabinet area is free of dust and debris, remove fi replace carefully from carton and discard the plastic and foam packaging.
- Page 9 Installation Residential Installation CAUTION: When installing this fireplace in residential applications, ensure to leave 3 feet minimum from any object. RV Installation WARNING: When installing this fireplace in RV applications, ensure hot air will not directly blow onto soft furnishings or combustible materials during operation. For fireplace installation in RV slide out wall, we recommend you connect the slide out safety cut off wires to the slide out 12V DC activation system.
-
Page 10: Operation
Operation Product Specifications Rating voltage 120Vac 60Hz AMPS 12.5A WATTS 1500W Control Panel Warning: This electric fireplace must be properly installed before it is used. Note: The element retains heat after shut down. There is a built-in cool down period of 30 seconds before the blower shuts off completely. Note: To operate correctly, the remote control must be pointed toward the glass window view. - Page 11 Operation Function Icon Description POWER Turn on or turn off the fireplace. Flame Select one of four brightness levels. 1. Press once to activate the low heat setting. 2. Press the button a second time to activate the high heat setting. 3.
-
Page 12: Troubleshooting
Troubleshooting Problem Root cause Corrective action Unplug the fireplace and remove the back panel. Check that the Display shows The thermostat thermostat is plugged into the main sensor is broken circuit board. If this does not solve “ ” or disconnected. the problem, contact customer service for a replacement thermostat sensor. -
Page 13: Troubleshooting
Troubleshooting Problem Root cause Corrective action Weak or defective Replace the remote batteries. batteries Press the remote control buttons with an even motion and gentle Poor signal pressure. Repeatedly pressing Remote control is buttons in rapid succession may not working cause the remote to malfunction. -
Page 14: Care And Maintenance
Care and Maintenance • The fan and flame generator motors are pre-lubricated for extended bearing life and require no further lubrication. However, we recommend periodic cleaning/vacuuming of the fan/fireplace. • Buff the trim using a soft cloth slightly dampened with a citrus oil based product (available at supermarkets and hardware stores). -
Page 15: Warranty
Warranty FURRION WARRANTS FOR A PERIOD OF 1 YEAR FROM DATE OF RETAIL PURCHASE BY THE ORIGINAL END-USE PURCHASER, THAT THIS PRODUCT, WHEN DELIVERED TO YOU IN NEW CONDITION, IN ORIGINAL PACKAGING, FROM A FURRION AUTHORIZED RESELLER AND USED IN NORMAL CONDITIONS, IS FREE FROM ANY DEFECTS IN MANUFACTURING, MATERIALS, AND WORKMANSHIP. - Page 16 TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY BY STATE OR (WHERE APPLICABLE IN THE COUNTRIES WHERE FURRION HAS NON-US/CANADIAN AUTHORIZED DEALERS) COUNTRY. NO ACTION OR CLAIM TO ENFORCE THIS WARRANTY SHALL BE COMMENCED AFTER THE EXPIRATION OF THE WARRANTY PERIOD.
- Page 17 Furrion Innovation Center & Institute of Technology ● 52567 Independence Ct., Elkhart, IN 46514, USA ● Toll free:1-888-354-5792 ● Email: info@furrion.com ©2007-2018 Furrion Ltd. Furrion® and the Furrion logo are trademarks licensed for use by Furrion Ltd. and registered in the U.S. and other countries. FURRION.COM...
