Summary of Contents for Austria Email WPA 233 ECO
- Page 1 Operating and Installation Instructions Heat pump with air duct for heating hot water WPA 233 ECO WPA 303 ECO Please forward this on to the user!
- Page 2 © Austria Email AG Installation and Operating Instructions - Version 08 - as of 06.2016 Printed in Austria, Copyright by Austria Email AG Protected by copyright. Any use outside of the boundaries of the copyright without the consent of Austria Email AG is prohibited and punishable.
-
Page 3: Table Of Contents
© Austria Email AG 1. Table of Contents Table of Contents Introduction Symbols General 2.2.1 Responsibility of the manufacturer 2.2.2 Customer Services 2.2.3 Responsibility of the installer 2.2.4 Responsibility of the user Compliance 2.3.1 Directives 2.3.2 Standards 2.3.3 Testing Safety instructions and recommendations... -
Page 4: Introduction
© Austria Email AG 2. Introduction We would like to thank you for the confidence you have shown in us by purchasing our heat pump. We are We would like to thank you for the confidence you have shown in us by purchasing our heat pump. We are We would like to thank you for the confidence you have shown in us by purchasing our heat pump. -
Page 5: General
2.2.2 Customer Services Servicing and the remedy of defects during the guarantee period are carried out by Austria Email AG. Servicing and the remedy of defects during the guarantee period are carried out by Austria Email AG. -
Page 6: Responsibility Of The User
© Austria Email AG All maintenance work must be indicated in the maintenance notes at the end of this manual. All of the documents included with the equipment must be given to the user. 2.2.4 Responsibility of the user To ensure uninterrupted and effective functioning of the system, the user must take the following instructions into account: The operating and assembly instructions included with the equipment must be read thoroughly. -
Page 7: Recommendations
© Austria Email AG Recommendations The device must only be operated by experts and trained personnel who can guarantee safe operation and The device must only be operated by experts and trained personnel who can guarantee safe operation and The device must only be operated by experts and trained personnel who can guarantee safe operation and maintenance using these operating instructions. -
Page 8: Composition
© Austria Email AG 3.3.3 Composition 1. Chemical composition: C – Tetrafluoroethane R – 134a Name of the ingredient Concentration CAS Number CE Number 1, 1, 1, 2 - Tetrafluoroethane R-134a 100% 811-97-2 212-377-0 1300 3.3.4 First Aid REMARK Important information 1. -
Page 9: Protection Of Persons
© Austria Email AG 3.3.8 Protection of persons 1. Protection of the respiratory organs: Protection of the respiratory organs: In the event of insufficient ventilation: the type AX protecti In the event of insufficient ventilation: the type AX protection mask Indoor use: full face mask with the oxygen pipe. -
Page 10: Technical Description
© Austria Email AG 4. Technical Description General This facility is a thermal pump which is designed for generating hot water in residential properties and other premises in which the daily hot water requirement does not exceed 700 litres. With the heating of domestic water, the heat pump simultaneously cools down the area in which it is installed. -
Page 11: Structure
© Austria Email AG 4.2 Structure Heat pump housing Heat pump housing Ventilator Evaporator Compressor Control Hot water storage tank Hot water storage tank Sensor duct external duct external Sensor dip rod Mg. Anode El. heating rod Hot water heat exchanger... -
Page 12: Functional Description
© Austria Email AG 4.3 Functional Description Compressor Mg. Anode Liquefier El. heating rod - safety thermostat-sensor Filter-drier High pressure switch Expansion valve Sensor - heat pump Evaporator Hot water heat exchanger Ventilator Hot water storage tank Solenoid valve Sensor - expansion valve El. - Page 13 © Austria Email AG Frost protection sensor The thermal pump regulator has an air temperature sensor which measures the temperature of the air which The thermal pump regulator has an air temperature sensor which measures the temperature of the air which...
-
Page 14: Technical Data
© Austria Email AG Technical Data Heat pump with air duct for heating hot water Heat pump with air duct for heating hot water product Model WPA 233 ECO WPA 303 ECO 1850 W (3350 W)* 1850 W (3350 W)* Max. -
Page 15: Installation Location Of The Hp
© Austria Email AG Installation location of the HP the HP The heat pump must on no account be set up in locations in which there may be pollutants or toxic The heat pump must on no account be set up in locations in which there may be pollutants or toxic The heat pump must on no account be set up in locations in which there may be pollutants or toxic substances in the air (stables, storage rooms for hazardous substances, outdoors etc.). - Page 16 © Austria Email AG Image 3: Suctioning from the adjoining room : Suctioning from the adjoining room - blowing out into the same adjoining room (drying washing) ng out into the same adjoining room (drying washing) Image 4: Suctioning from the room - blowing out into the surroundings...
-
Page 17: Installation
© Austria Email AG If the HP uses air from the environment in the room, the space must be at least 30 m If the HP uses air from the environment in the room, the space must be at least 30 m... -
Page 18: Air Duct Connection
© Austria Email AG 1. Shut-off valve 2. Pressure reduction valve 3. Back-flow valve 4. Safety valve 5. Expansion vessel 6. Drainage Valve 7. Circulation pump 8. Heat pump Expansion vessel dimensioning: Safety valve pressure setting [bar] Pressure in system [bar]... -
Page 19: Condensate Drain Connector
© Austria Email AG Figure 9 below shows the cover of the heat pump. The cover has two brackets, both 40 mm high, and have Figure 9 below shows the cover of the heat pump. The cover has two brackets, both 40 mm high, and have Figure 9 below shows the cover of the heat pump. - Page 20 © Austria Email AG The condensate pipe must be connected to the device and fed into the sewer system or into a collector. In case of installation of the condensate water pipe into the sewage system, we recommend that you use a siphon to prevent unwanted odours.
-
Page 21: Installation Of The Additional Heating Source
© Austria Email AG Levelling the heat pump CAUTION It is necessary to follow the instructions below in order to guarantee the correct drainage It is necessary to follow the instructions below in order to guarantee the correct drainage It is necessary to follow the instructions below in order to guarantee the correct drainage of condensate water. -
Page 22: Electrical Connection
© Austria Email AG 1. Shut-off valve 2. Pressure reduction valve Pressure reduction valve 3. Back-flow valve 4. Safety valve 5. Expansion vessel Expansion vessel 6. Drainage Valve 7. Pump 8. Heat pump 9. Boiler 5.5.5 Electrical Connection If the HP is properly connected to the water supply and properly ventilated, the electrical connection follows. - Page 23 © Austria Email AG - Pull the plug out of the wall to Pull the plug out of the wall to disconnect the power supply. disconnect the power supply. - Remove the screws as shown Remove the screws as shown in the image.
-
Page 24: Putting Into Operation
© Austria Email AG - Connect the circulating pump Connect the circulating pump cable through the cable guide cable through the cable guide (4) the circulating pump the circulating pump clamps ( clamps (1). - Connect the PV release signal... -
Page 25: Checks Before Starting
© Austria Email AG Checks before starting Before starting the device, the following must be checked: Before starting the device, the following must be checked: The hot water tank must be filled with water and ventilated. The hot water tank must be filled with water and ventilated. - Page 26 © Austria Email AG ☼ does not light up The set hot water temperature is heated only by the boiler. Lights Note: The air temperature has no effect on the function. ☼ does not The set hot water temperature is heated only by an electric heating rod.
- Page 27 © Austria Email AG 4. Quicker water heating: Programme P5 provides the function for rapid (simultaneous) water heating, with which both heat sources are operated (thermal pump and electric heating element in programme P5). This function is switched on with the HT key by holding it down for 20 seconds. The indicator of the HT flashes until the set water temperature has been reached.
-
Page 28: Uninstalling And Disposal
© Austria Email AG In order to get to the parameter description menu, press the >+< and > description menu, press the >+< and >-< keys at the same time. These keys < keys at the same time. These keys are also used to scroll through the menu (see the chapter Parameter Description). -
Page 29: Care And Maintenance
© Austria Email AG Care and maintenance 8.2.1 Care CAUTION Damage to the surface of the device! The unit surface may, as a result of using Damage to the surface of the device! The unit surface may, as a result of using... -
Page 30: Error Indication
© Austria Email AG 9.2 Error indication Error indication Cause Solution Check whether there is enough water in the reservoir Pressure in system is too high Use the + key to delete the error If the error occurs again, phone Customer Service. -
Page 31: Guarantee, Warranty And Product Liability
The warranty will be fulfilled in accordance with the current legal provisions of the Republic of Austria as well as with those of the EU. 1. A condition for the fulfilment of guarantee services by Austria Email AG (hereinafter referred to as AE AG) is the presentation of the paid invoice for the purchase of the device for which the guarantee service is being invoked, whereby the identity of the device in terms of type and serial number must be taken from the invoice and must be produced by the claimant. - Page 32 A-8720 Knittelfeld Telephone: (03512) 700-0 Fax: (03512) 700-239 Internet: www.austria-email.at E-Mail: office@austria-email.at Austria Email in your area? For addresses and telephone numbers of our subsidiaries, visit our homepage at www.austria-email.at Print errors and changes of all kinds are reserved. Reproduction prohibited.
