- Page 1 Adam Equipment AE 504 Software rev: V 1.00 & above © Adam Equipment Company 2019...
- Page 2 Easy Reference: Model name of the indicator/scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place: © Adam Equipment Company 2019...
-
Page 3: Table Of Contents
BATTERY AND BACKLIGHT OPERATION .................. 28 11.1 BATTERY ............................ 28 11.2 CHARGING..........................29 11.3 BACKLIGHT FOR LCD ........................ 29 12.0 ERROR CODES ..........................30 13.0 REPLACEMENT PARTS AND ACCESSORIES ................31 14.0 SERVICE INFORMATION ....................... 32 WARRANTY INFORMATION ......................... 33 © Adam Equipment Company 2019... -
Page 4: Introduction
INTRODUCTION The AE 504 series provides a versatile check counting and weighing application perfect for general warehouse and production. The indicators can be set to verify counts up to 60000 divisions All indicators are supplied with a RS-232 bi-directional interface and real time clock (RTC). -
Page 5: Specifications
Operating 0°C to +40°C / +32°F to +104°F Temperature Power supply AC 12V/3A; DC inside rechargeable 6V/10AH battery Battery Internal rechargeable battery Calibration Manual calibration Display 667 digits LCD Indicator ABS Plastic Housing © Adam Equipment Company 2019... - Page 6 Interface RS-232 bi-directional interface English, German, French, Spanish selectable text Date/Time Real Time Clock (RTC), To print date and time information (Dates in Year/month/day, Day/month/year or Month/day/year formats- Battery backed) © Adam Equipment Company 2019...
-
Page 7: Installation
Avoid air movement such as from fans or opening doors. Do not place near open windows or air- conditioning vents. Keep the indicator clean. Do not stack material on the indicator when they are not in use. © Adam Equipment Company 2019... -
Page 8: Connection
Insert the holder into the bracket of the indicator. Fix the load cell connector. Adjust the holder for right position, and then fasten the plastic screw on the display. © Adam Equipment Company 2019... -
Page 9: Key Descriptions
Used to access any stored PLU weight values [CE/ Used to clear numeric totals on the display. BACKLIGHT] Secondary function: Allows the backlight to be configured to ON/ OFF/ AUTO [U 1-6] Fetch a stored PLU value directly © Adam Equipment Company 2019... -
Page 10: Displays
Lo-bat: When battery power lower than 5.6V, it will show. Kg / Lb / g / ct /dr / oz / : Symbols shown for the units lb:oz / mm / T / Ton Net: Net weight- The scale has been tared © Adam Equipment Company 2019... -
Page 11: Unit Weight Display
It may be necessary to re-zero the scale over a period of time to account for minor drifting. © Adam Equipment Company 2019... -
Page 12: Taring
When the pan is empty, press [Tare] key, the display will show “P - TARE”. Input the weight of the container, press [Tare] key, Pre-tare complete. User can set follow function ON or OFF in F5 PTE: © Adam Equipment Company 2019... -
Page 13: Checkweighing
The beep is on when the weighing H - L - mass is in between the set limits and below the set low limit. © Adam Equipment Company 2019... -
Page 14: Parts Counting
The user can turn this function ON/OFF by pressing the AVG key. 6.4.4 Accumulation/ Totalising The totalising function can be used up to a maximum of 99 times before it must be reset. The totalising display is limited to seven digits maximum. © Adam Equipment Company 2019... -
Page 15: Setting The Plu Data
SKU ID can include letters, please check the step 6.5.2 for details on how to input. After inputting ID, press [PLU] to store. When finished, press [CE] to exit. © Adam Equipment Company 2019... -
Page 16: Input Letter
Connect the scale with PC by RS232, open ScaleSetPlu.exe, and choose the right port. INGLE SETTING Press , software will show Input the serial number, unit weight, SKU ID, name as follow picture. if need scale increase the serial number automatically, please choose “Auto inc”. © Adam Equipment Company 2019... - Page 17 DOWNLOAD MULTIPLE PLU BY TABLE (RECOMMEND) Use table edit software (such as Excel, WPS, Numbers) to new built a file, then input PLU data by follow format: Then save as xls file . © Adam Equipment Company 2019...
-
Page 18: User Parameters
Communication mode: Continuous transfer mode, stable transfer mode and response. T2 Add Communication address, effective in multi- 1-20 machine communication. T3 Bps Communication baud rate 2400, 4800, 9600, 19200, 38400, 56000, 115200 Parameter Definition Options © Adam Equipment Company 2019... - Page 19 To set if the scale can alarm when weight is 0. F9 FAL On means full alarm mode. OFF means simple alarm mode. To set if the Hi-Lo relay runs after stable. F10 BC Press ‘’ID’’ to escape and return to normal weighing mode. © Adam Equipment Company 2019...
-
Page 20: Calibration
LABEL EDITING COMPUTER SOFTWARE The AE 504 is supplied with RS-232 interface which allows for connection between computer and indicator to edit labels for the inbuilt label printer and set printing parameters. © Adam Equipment Company 2019... -
Page 21: Label Editor Software Interface
Connect the indicator to the PC using the RS 232 cable provided, this is so the customised label can be downloaded straight to the indicator after completion Start up the label editing software (3) Press the © Adam Equipment Company 2019... -
Page 22: Label Customisation
Prints: How many labels will be printed when the print button is pressed To change the parameters, left click the desired parameter and a drop-down arrow will appear with different options to select from. 9.1.3 Label customisation Once parameters have been set, the label can be customised and edited to desired preference. © Adam Equipment Company 2019... -
Page 23: Adding Text
Pictures can be added to a label design, the pictures will show as a black and white picture. To add a picture, left click the picture icon in the editing tools section. The picture will appear as a small icon before uploading the image file via the parameter settings section. © Adam Equipment Company 2019... -
Page 24: Adding Barcodes
The barcode also has customisable parameters: Height: The height of the barcode Thickness: Minimum line width Barcode type: Type of barcode (food retailers usually use EAN13) Readable: Enable or Disable the Print out of the text below the barcode Rotation: Rotation angle (0 = clockwise) Text: Can insert this variable (EAN13 barcodes must be numeric and 12 digits long. SKU must be 5 digits long, for price no dot needs to be chosen) © Adam Equipment Company 2019... -
Page 25: Adding Qr Codes
Select the item you want to delete by left clicking it and press the delete button on the keypad. A message will appear asking the user to confirm the deletion. Press ‘OK’ to confirm and the item will then be deleted from the label. © Adam Equipment Company 2019... -
Page 26: Label Download Procedure Via Rs 232 Cable
RS-232 interface, outputs the weight, unit weight and count. Specifications: RS-232 output of weighing data ASCII code Adjustable Baud rate, 600, 1200, 2400, 4800, 9600 and 19200 baud 8 data bits No Parity © Adam Equipment Company 2019... - Page 27 All lines end with line feed <lf>, and carriage return <cr>characters. Data Format‐Normal Output <lf><cr> <lf><cr> ID QTY 0 pcs U. W 123 g Kg or g for metric weights and lb for pounds. G. W 1.234 Kg Net Wt. if net weight is displayed Item: [barcode] <lf><cr> Includes 2 line feeds with carriage return <lf><cr> at beginning and end of the form DATE 12/09/2006 TIME 14:56 Data Format‐ Memory Recall Print: <lf><cr> ID <lf><cr> ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ TOTAL No. 5 Wt. 1.234 Kg Pcs 10 pcs <lf><cr> Includes 1 line feed ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ <lf><cr> 2 line feeds, carriage return <lf><cr> DATE 12/09/2006 TIME 14:56 © Adam Equipment Company 2019...
-
Page 28: Input Commands Format
Sets the zero point for all subsequent weighing. The display shows zero. Same as pressing the [Zero 0] key. P<cr><lf> Prints the weight, unit weight and totals same as pressing the [PRINT/ SAVE] key. © Adam Equipment Company 2019... -
Page 29: Real Time Clock Setup
should be charged as soon as possible. Once the “LO bAT” message is shown the scale will still operate for about 10 minutes after which it will automatically switch off to protect the battery. © Adam Equipment Company 2019... -
Page 30: Charging
Sets the backlight to be on at all times. Sets the backlight to operate automatically when a “BL Au” weight is placed on the scale or a key is pressed. “BL OFF” Sets the backlight to be off. © Adam Equipment Company 2019... -
Page 31: Error Codes
AD value exceed the pow Power on again after remove the ERR-Z er on zero range when po weights or re-calibrate wer on Low power alarm Charge battery Battery symbol flash Low power alarm Charge battery Lo-Bat © Adam Equipment Company 2019... -
Page 32: Replacement Parts And Accessories
AE504 modle label 3.10.4.0.14808 12V 3A 36W power adapter 302408705 Mains cable figure of 8, UK 302408515 Mains cable figure of 8, Europe 302408514 Mains cable figure of 8, Australia 302408516 Mains cable figure of 8, SA © Adam Equipment Company 2019... -
Page 33: Service Information
‐Contact telephone, e‐mail, fax or any other methods: B. Details of the unit purchased (This part of information should always be available for any future correspondence. We suggest you to fill in this form as soon as the unit is received and keep a print‐out in your record for ready reference.) AE 504 _____ Model name of the scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place: C. Brief description of the problem Include any recent history of the unit. For example: ‐Has it been working since it’s delivered ‐Has it been in contact with water ‐Damaged from a fire ‐Electrical Storms in the area ‐Dropped on the floor, etc. © Adam Equipment Company 2019... -
Page 34: Warranty Information
Repairs carried out under the warranty do not extend the warranty period. Components removed during warranty repairs become company property. The statutory rights of the purchaser are not affected by this warranty. The terms of this warranty is governed by the UK law. For complete details on Warranty Information, see the terms and conditions of sale available on our web‐site. © Adam Equipment Company 2019... - Page 35 As we often update adaptor products to meet changing legislation it is not possible to refer to the exact model in this manual. Please contact us if you need specifications or safety information for your particular item. Do not attempt to connect or use an adaptor not supplied by us. © Adam Equipment Company 2019...
- Page 36 Fax: +27 (0)11 392 2587 Fax + 86 (27) 59420388 Fax +61 (0) 8 9456 4462 e‐mail: e‐mail: e‐mail: sales@adamequipment.co.za info@adamequipment.com.cn sales@adamequipment.com.au © Copyright by Adam Equipment Co. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice. All information contained within this publication is to the best of our knowledge timely, complete and accurate when issued. However, we are not responsible for misinterpretations which may result from the reading of this material. The latest version of this publication can be found on our Website.www.adamequipment.com © Adam Equipment Company 2019...
