Warmer Drawer
Models WD-20, WD-21A, & WD-35
owner's manual
Manufacturing Numbers:
9400100, 9400101, 9400102, 9400103, 9400104,
9400106, 9400110, 9400111, 9400112, 9400113,
9400114, 9400120, 9400121, 9400122, 9400123,
and 9400124,
www.antunes.com
P/N 1010612 Rev.. D 08/17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WD-20 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Antunes WD-20 Series

Summary of Contents for Antunes WD-20 Series

  • Page 1 Warmer Drawer Models WD-20, WD-21A, & WD-35 owner’s manual Manufacturing Numbers: 9400100, 9400101, 9400102, 9400103, 9400104, 9400106, 9400110, 9400111, 9400112, 9400113, 9400114, 9400120, 9400121, 9400122, 9400123, and 9400124, www.antunes.com P/N 1010612 Rev.. D 08/17...

  • Page 2: Table Of Contents

    WARMER DRAWER TABLE OF CONTENTS Table of Contents ............2 Operation ..............7 Owner Information .............2 Operating Instructions ..........7 General ..............2 Hi-Limit Reset ............7 Warranty Information ..........2 Maintenance ..............8 Service/Technical Assistance ........3 Cleaning ..............8 Important Safety Information ........3 Replacing Components ..........8 Specifications .............5 Troubleshooting ............10 Wiring Diagram ............10 Electrical Ratings and Plug Configuration ....5...

  • Page 3: Service/Technical Assistance

    WARMER DRAWER OWNER INFORMATION (continued) Service/Technical Assistance Use only genuine Antunes replacement parts in this unit. Use of replacement parts other than those sup- If you experience any problems with the installation plied by the manufacturer will void the warranty.
  • Page 4 - Electrical ground is required on this appli- ance. • This equipment should be serviced by quali- fied personnel only. Contact Antunes Technical - Do not modify the power supply cord plug. Service adjustment or repair. If it does not fit the outlet, have a proper outlet installed by a qualified electrician.

  • Page 5: Specifications

    WARMER DRAWER SPECIFICATIONS Electrical Ratings and Plug Configuration Capacity Model & Volts Watts Amps Hertz Plug WD-20 Holds up to 40 standard hot dog buns. Mfg. No. Description WD-21A One 4” (100 mm) deep full size steam WD-20 50/60 NEMA 5-15P table pan.

  • Page 6: Installation

    4. Install parts into unit. NOTE: If any parts are missing or damaged, con- Drawer Water Tray tact Antunes Customer Service IMMEDIATELY at +1-877-392-7856 (toll free) Figure 1. Warmer Drawer–WD-20 Equipment Setup Trivet When placing the unit into service, pay attention to the following guidelines.

  • Page 7: Operation

    2. Remove the base plate and push in the reset switch located on the bottom of the thermostat (Figure 4). If hi-limit thermostat continually trips, contact Antunes Figure 4. Hi-Limit Reset Technical Service to determine the reason for overheat- ing.

  • Page 8: Maintenance

    WARMER DRAWER MAINTENANCE Replacing Components WARNING Turn the unit off, disconnect the power source NOTE: It is recommended that all service procedures and allow the unit to cool down before performing be performed by a qualified authorized service techni- any service or maintenance on the unit. cian.
  • Page 9 WARMER DRAWER MAINTENANCE (continued) THERMOSTAT CONTROL REPLACEMENT ROCKER SWITCH (POWER ON/OFF) REPLACE- MENT 1. Turn off rocker switch (power on/off), unplug the power cord and allow the unit to cool down 1. Turn off rocker switch (power on/off), unplug the before proceeding.

  • Page 10: Troubleshooting

    WARMER DRAWER TROUBLESHOOTING WARNING To avoid possible personal injury and/or damage to the unit, inspection, test and repair of electrical equipment should be performed by qualified service personnel. The unit should be unplugged when servicing. Problem Possible Cause Corrective Action Unit will not heat up.

  • Page 11: Replacement Parts - Wd-20

    WARMER DRAWER REPLACEMENT PARTS - WD-20 17 31 P/N 1010612 Rev. D 08/17...
  • Page 12 WARMER DRAWER REPLACEMENT PARTS – WD-20 (continued) Item Part Description Qty. Item Part Description Qty. 0010439 Housing, Outer 4060203 Indicator Light, Heater ON, 0021010 Housing, Inner 120 Volt 0502937 Base Plate 4060229 Indicator Light, Heater ON, 0502897 Front Panel 230 Volt 210K230 Bumper Leg Kit 0020610...

  • Page 13: Replacement Parts - Wd-21A & 35A

    WARMER DRAWER REPLACEMENT PARTS – WD-21A & 35A P/N 1010612 Rev. D 08/17...
  • Page 14 WARMER DRAWER REPLACEMENT PARTS – WD-21A & 35A (continued) Item Part Description Qty. Item Part Description Qty. 0501894 Cover (WD-21A) 4060323 Indicator Light, Heater ON, 0501199 Cover (WD-35A) 120 Volt 0021011 Housing, Inner (WD-21A) 4060229 Indicator Light, Heater ON, 0021012 Housing, Inner (WD-35A) 230 Volt 0501841...

  • Page 15: Notes

    WARMER DRAWER NOTES P/N 1010612 Rev. D 08/17...

  • Page 16: Limited Warranty

    2 hours (100 miles/160 km) round trip from the nearest authorized service agency. 2. Antunes reserves the right to make changes in design or add any improvements on any product. The right is always reserved to modify equipment because of factors beyond our control and government regulations.

This manual is also suitable for:

Wd-21a seriesWd-35 seriesWd-20 9400101Wd-20 9400100Wd-20 9400102Wd-20 9400103 ... Show all

Table of Contents
