- Page 1 User Manual Hating Mantle PCE-HMA Series User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 17 April 2018 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Contents Introduction ................... 1 Technical specifications ..............2 Safety notes ................... 4 Operation ....................6 Maintenance ..................7 Warranty ....................8 Disposal ....................8 © PCE Instruments... -
Page 3: Introduction
Introduction Thank you for choosing to purchase a heating mantle of the HMA series from PCE Instruments. The heating mantles of the PCE-HMA series are handmade. You have a heating mantle made of “crocheted” glass silk. The PCE-HMA series is exclusively intended for heating liquids in round- bottomed flasks made of glass. -
Page 4: Technical Specifications
Technical specifications PCE-HMA 25 ml round-bottomed flask Maximum temperature +450 °C Maximum capacity of round-bottomed flask 25 ml Maximum diameter of round-bottomed flask 41 mm No. of heating zones Power supply 230 V / 500 W Bottom hole RCCB protection... - Page 5 Maximum temperature +450 °C Maximum capacity of round-bottomed flask 10000 ml Maximum diameter of round-bottomed flask 279 mm No. of heating zones Power supply 230 V / 2000 W Bottom hole yes, 60 mm RCCB protection yes, external © PCE Instruments...
-
Page 6: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. Intended use The intended use of our heating mantles is heating non-explosive and non-flammable liquids in a glass flask in the laboratory and in technical applications. - Page 7 Check the RCCB protection switch Technical specifications of the RCCB protection switch Nominal voltage 230 V / 50 Hz Nominal current 16 A Fault current 30mA Protection class IP44 Response time <30 ms -25 … + 40 °C Ambient temperature © PCE Instruments...
-
Page 8: Operation
Afterwards, the heating mantle must be dried at a maximum temperature of 60 °C in a drying cabinet for at least 5 hours. No round-bottomed flasks made of metal or plastic must be heated in the heating mantle. © PCE Instruments... -
Page 9: Maintenance
Maintenance of the heating mantles must only be carried out by qualified electricians. Heating mantles may only be repaired by the manufacturer to prevent serious injury or even death by electric shock. © PCE Instruments... -
Page 10: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 11 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 SOULTZ-SOUS-FORETS 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
