- Page 1 PRODUCT INSTRUCTIONS Floats Rd, Wythenshawe, Manchester. M23 9WB Fire Door Control Panel (FDCP) T: +44 (0)161 945 4561 F: +44 (0)161 945 4566 Stock Code Description Doc No: PI-115 00133 Ellard Fire Door Control Panel Iss: 00134 Ellard Slave Repeater Unit...
- Page 3 FDCP V.1 Contents ....1) Specification and Installation ..............2) Connection and Indication ................... 2.1 Mains Power Supply - In ..................2.2 Mains Supply - Out ..................... 2.3 Battery ....................... 2.4 Fire Alarm Signals....................(2.4.1) Zone 1 (2.4.2) Zone 2 2.5 Push Button Connection ..................
- Page 4 1) Specification and Installation General Standards and Conformity Power Supply 230v - 50Hz The FDCP complies to the following EMC and Low Voltage standards and directives 6.3A @ 230v Max Motor Load Max Accessories Load 4A @ 24v d.c EMC Directive: Directive 2004/108/EC Working Temp -20 to +70°C...
- Page 5 FDCP v.1 (Software Ver 06) Multi Function Control System for Roller Shutters and Connection - TS1 Smoke curtains Zone 1 - Main Fire signal +24v d.c (+) Zone 1 - Main Fire signal +24v d.c (-) Features · Large visual warning 'FIRE SHUTTER CLOSING' and Zone 1 - Main Fire signal - N/O, N/C, 8k2 3 + 4 102 dB sounder...
- Page 6 2.4) Fire Signals (Connections and types) 2.4.1) Alarm Zone 1 - Main Fire Alarm Signal Normally Open (N/O) Triggers the panel by a N/O volt free signal which CLOSES W A R N I N G when the fire alarm is activated Note: an 8k2 resistor must be fitted across input F I R E connections...
- Page 7 2.5) Push Button (optional) 2.9) Relays Outputs Connection of a typical 3 push button station to The unit is fitted with individual relays to provide different functions as required operate the door under normal conditions All contacts are at a volt free potential (dry contact) and are rated at 230v AC STOP - Relay (1 + 2) A Normally Closed contact that will open circuit when the Stop button is pressed...
- Page 8 3.1 Typical Connection for 230v AC Tubular Motors (Use with "Power Closing" or "2 Stage Closing")
- Page 9 3.2 Typical Connection for 24v d.c Tubular motors (Use with "Power Closing" or "2 Stage Closing")
- Page 10 3.3 Connection for 'JM' series motors fitted with 24V DC brake release solenoid unit (Use with "Power Closing" , "2 Stage Closing" and Solenoid Only") JM POWER SUPPLY CONNECTION FOR 3 PHASE OPERATORS, AN INDEPENDENT SUPPLY (3PH, N, + E) MUST BE INSTALLED FOR 1 PHASE OPERATORS THE MOTOR SUPPLY CAN BE SUPPLIED...
- Page 11 3.4 Connection for other motors with built on controllers (Use with "Power Closing" , "2 Stage Closing" and Solenoid Only") VOLT FREE POTENTIAL OUT PUT TO DRIVE EXTERNAL CONTROLS OR OPERATORS FITTED WITH 'BUILT - ON' STARTERS NOTES :- OPERATOR POWER SUPPLY 3 PHASE OPERATORS MUST BE CONNECTED TO AN INDEPENDENT SUPPLY (3PH, N, + E) FITTED WITH SUITABLE FUSE PROTECTION 1 PHASE OPERATORS CAN BE CONNECTED TO AN INDEPENDENT SUPPLY...
- Page 12 RELAY BASE Stand Alone Heat and Smoke Detectors Relay Base Supplier Apollo Part No 45681-245 APO Series 65 Relay Base Ellard Stock code 04053 Smoke Detector Head Series 65 Supplier - Apollo Part No 55000-122 APO Ellard Stock code 04052...
- Page 13 Program Choice = 2 Stage Closing Main activation for 2 stage closing using a Smoke/ Heat Detector with Relay Base (Signal shown = Normally Open) RESISTOR NC com NO NC com NO AUX1 AUX2 10 11 12 9 10 (N/O) (COM) Main Fire Alarm signal - Zone 1 On activation shutter...
- Page 14 5) Programming After installation the FDCP must be programmed to operate upon receipt of a fire signal, the shutter will close by the method selected in 'ALARM DOOR TYPE' To access set up, press and hold the 'Intelligent Dial' for 3 seconds, the display will change from battery condition to USER menu BATTERY VOLTAGE To move through the features, rotate the 'Intelligent Dial'...
- Page 15 ROTATE TO ADVANCE PRESS MENU ONCE PRESS ONCE DOOR CLOSED ALARM - VISUAL AND SOUND DOOR CLOSED ALARM · With the shutter fully closed and the fire alarm signal still present, the VISUAL + SOUND ON - OFF Audio Visual warning can either continue or be switched OFF ROTATE TO CHANGE ROTATE TO...
- Page 16 6) Repeater Panel Specification General Power Supply 24v d.c. Working Temp -20 to +70°C Dimensions (mm) 236 (w) x 286 (h) x 108 (h) Weight (Kg) Mounting Mount the unit using the fixing holes provided (see Fig 1.1) Fig 1.1 Enclosure Mounting W A R N I N G F I R E...
- Page 18 FDCP V.1 7. Troubleshooting Guide Message shown in Display Cause and possible solution Input to ZONE 1 is activated - Check If Fire Alarm Signal is still present Alarm Zone 1 Input to ZONE 2 is activated - Check If Fire Alarm Signal is still present Alarm Zone 2 5v Regulator Fail Part close run time is longer than full close run time...
