Techno CNC Systems HDS Series User Manual

Cnc router
Hide thumbs

Advertisement

Quick Links

WARNING: DO NOT OPERATE THIS MACHINE WITHOUT PROPER
TRAINING! Improper or unsafe operation of the machine will
result in personal injury and/or damage to the equipment.
This manual will provide unpacking, maintenance, and user guide for running the Techno HDS Series
It is suggested that the operator keep this manual by the machine. This will provide the most important
1 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481
Series CNC Router
User Manual
and HDS Plus Series CNC Routers.
information pertaining to the operation of this machine.
HDS Series

Advertisement

loading
Need help?

Need help?

Do you have a question about the HDS Series and is the answer not in the manual?

Questions and answers

Related Manuals for Techno CNC Systems HDS Series

Summary of Contents for Techno CNC Systems HDS Series

  • Page 1 TRAINING! Improper or unsafe operation of the machine will result in personal injury and/or damage to the equipment. This manual will provide unpacking, maintenance, and user guide for running the Techno HDS Series and HDS Plus Series CNC Routers. It is suggested that the operator keep this manual by the machine. This will provide the most important information pertaining to the operation of this machine.

  • Page 2: Table Of Contents

    HDS Series TABLE OF CONTENTS I..General Installation Instructions. 1.1 Forklift guide and unpacking instructions......Page 3 1.2 Safety Instructions......Page 4 1.3 Correct Colleting......Page 5 1.3.5 Toolstand 1.3.6 Spindle Warmup ......Page 6 1.4 Electrical and Pneumatic connections.
  • Page 3 For safety and to prevent damage to the machine, Lift Machine Using The Frame ONLY ** Some HDS Series CNC Routers do NOT have forklift tubes. ** If so, make sure forklift blades enter through the frame of the machine only. Use blocks when lifting machine to prevent damage to the vacuum table plumbing ** 3 For Support Visit·...

  • Page 4: Safety Instructions

    HDS Series 1.2 SAFETY INFORMATION! Read these instructions thoroughly before operating machine. DO NOT operate machine if you are unfamiliar with these safe operating instructions. DO NOT operate machine without knowing where the emergency stop switch is located. Keep fingers, hands, and all other objects away from 11. Use machine only in clean, well-lit areas free from machine while power is on.

  • Page 5: Correct Colleting

    HDS Series 1.3 Correct Colleting: Read these instructions thoroughly BEFORE operating machine. WARNING! THE SPINDLE WILL BE DAMAGED IF UNBALANCED EQUIPMENT IS USED. AIR SUPPLY MUST BE FILTERED AND DRY. 5 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...

  • Page 6: Toolstand

    HDS Series 1.3.5 Tool Stand Diagram - Proper Placement Read these instructions thoroughly BEFORE operating machine. 1.3.6 — HSD Spindle Warmup Spindle Warm-up: Read these instructions thoroughly BEFORE operating machine. USE AND ADJUSTMENT PREHEATING HSD S.p.A. uses high-precision angular contact bearing pairs, pre-loaded and lubricated for life with special grease for high speeds.

  • Page 7: Electrical And Pneumatic Connections

    HDS Series WARNING: Ensure that all electrical connections are carried out by a qualified electrician. Improper electrical connections can result in damage to the equipment, fire and death. 1.4 Electrical and Pneumatic connections. The Techno HDS series machine is powered by three phase 220 volts. The amperage requirements for this machine are 40 amps. 1.4.1 When the machine has been unpacked, it will be necessary to attach the keyboard shelf to the Hole for mouse and front of the machine.
  • Page 8 HDS Series WARNING: Ensure that all electrical connections are carried out by a qualified electrician. Improper electrical connections can result in damage to the equipment, fire and death. 1.4.4 Fig 1.4.4a. Attach the three phases and the ground to the connections shown in fig 1.4.4a or 1.4.4b Your machine may come with a terminal block (shown in 1.4.4a) or you machine may come with no terminal block and must be wired to the power switch shown in figure 1.4.4b 3 phase 220V in...

  • Page 9: Vacuum Pump Connections

    HDS Series WARNING: Direction of Rotation is critical. Briefly start motion and check rotation (arrow on casing). Exchange phases if rotation is incorrect. IF YOU RUN THE PUMP/BLOWER CONTINUOUSLY IN THE WRONG DIRECTION, THE VANES WILL BE DAMAGED 1.5 Vacuum Pump connections...
  • Page 10 HDS Series 10 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...

  • Page 11: Start Up Procedure

    HDS Series Section II: Machine Start-Up | Screen Functionality 2.1- Start up Procedure. 2.1.1 Turn the Main power switch to the ON Fig 2.1.2 Position. 220 Volts should have been ran to the machine by an electrician. 220V is going to be attached to the back of the switch...
  • Page 12 HDS Series 2.1.4 Software start up. Once the PC has started, the Boot Controller software will start automatically. If it does not, double click on the Boot Controller Icon (It looks like a rocket ship) on the desktop. If no text appears in the box, after 30 seconds, check that the light for the controller is on and that the network cable from PC to Osai controller is connected. If no connection occurs, see the Fault Finding section in the Appendix. Boot controller loaded and connecting to 192.168.0.1 machine If the machine is starting from a fresh PC boot, then Normal mode will automatically be selected. If the Boot Controller does not start after a minute and the message CNC is waiting for a BOOT mode directive appears on the screen, then normal mode needs to be selected. Controller is waiting 192.168.0.1 for a mode. Otherwise, it will automatically go into normal mode after a few seconds. 12 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 13 HDS Series 2.1.5 Interface Starts: The Techno interface screen will now open. There will be a warning message saying Emergency Stop Active. Click on the E-stop Reset Button to remove this warning. The Axis not referenced error will appear. Click on “Home All” and all the axes will move to their home position. If any errors remain on the screen (i.e. Low Air Pressure,) rectify the problem and click on “Reset Errors” or “RESET” to remove the message. The machine is now ready to be jogged. Note: Pressing Home All will move the machine to the front left corner of the table. This must be done every time the machine boots up. Once the machine is in the Home position, it has a reference point from which it can pick up tools and locate offsets. Home All Reset Errors 13 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...

  • Page 14: Screen Callouts

    HDS Series 2.2 Screen Callouts Above is the main screen of the Techno HDS interface. To help understand the functions of the buttons they will be broken down into the following categories: A- Jogging functions. B-Homing Functions and Clearance Position C-Pneumatic and Electrical Controls. D-Menu Systems. E-Coordinate Systems. F-Origin Functions. G-Save Origin Menu H-Spindle and Coolant control. I-Load G-code File. J-Program Functions. K-Tool Menu L-Offset Menu. 14 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 15 HDS Series A-Jogging Functions The machine will not move unless a jog mode is selected. Click on the button beside the text to select a mode. A - Handwheel: In this mode, the machine will operate via the MPG/Handwheel. Please see Handwheel operation for more information. All other functions are disabled when this is active. B - Continuous: Also, known as Jog Mode. The machine will move smoothly and continuously when the user clicks on the directional arrow associated with each axis. Speed is controlled by Jog speed and is a percentage of the max jog speed (800 ipm) for manual jog mode. (Ex: [50% of 800=400 IPM]) C - Step: Also, known as Incremental Jog Mode. The machine will move by an exact amount, as specified by Jog Step variable when the arrow button is held down with left click. [Example: if jog step is set to .05 and I click X+. machine moves .05 to right] D - MDI: Manual Data Input, this feature allows the user to manually enter and execute a line of G-code. [Ex: (M3 S1800: spindle turns on at 18,000 rpm)] E - Jogging Arrows: By left clicking on these arrows the machine will move in the corresponding direction. These arrows are only functional if Continuous or Step mode is active. F - Reset Errors: This will remove any warning/error messages that appear on the screen. 15 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 16 HDS Series B-Homing Functions A - Home All: Sends the machine to the home position. (Absolute XYZ = 0). The Z axis will first move up to its limit, then the X and Y axes will move simultaneously. B - SINGLE AXIS HOME: When this button is left clicked, each axis can be homed separately. When the button is active, the user then clicks on the arrow key for the axis to be homed to enable the operation. [Ex: click single axis home, click X-, machine will home the x-axis only] C- CLEARANCE POSITION: When this button is left clicked, the machine will run towards the back, in order to load and unload work 16 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 17 HDS Series C-Pneumatic and Electrical Controls The sections highlighted below are the buttons that control the pneumatic and electrical outputs for the controller. A - Shroud Up/ Down: This button will raise or lower the dust shroud on the spindle. B - Pins Up / Down: Down This button will raise or lower the pop-up pins on the sides of the table. C - Vacuum 1 On/Off: This button will turn Vacuum 1 on and off, if it is connected. D - Vacuum 2 On/Off: This button will turn Vacuum 2 on and off, if it is connected. Down Shroud Up / Down and Pins Up / Down will only function if 90 lbs. of compressed air connected to the machine Vacuum 1 on/off and Vacuum 2 on/off send 220 volts to the starter coil of the vacuum pump, thus activating the pump. 17 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 18 HDS Series D-Menu Screens The sections highlighted below are the Menu Screen options of the interface. The user can switch to these screens by clicking on the corresponding button. A - Offsets: Opens the Offset Menu. In this menu the user can save multiple offsets/origins and apply them to the coordinate system. B - I/O: Opens the Input and Output screen diagnostics. These screens will show the states of the inputs and outputs. C - Tool: Opens the Tool Menu. In this menu the user can store tool lengths and change tool numbers. 18 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 19 HDS Series E-Coordinate System A - XYZ Coordinates: This displays the location of the machine. If the Origin No is zero,the numbers displayed are the distance from the Home position (Absolute XYZ = 0). If there is an Origin Number active, the numbers displayed are the distance from that origins zero position. B - Tool: This displays the tool that is currently in the spindle. If the number reads a single digit then there is no offset applied to that tool at this time. When the Tool displays 1.1, or 2.2, or 5.5 etc then the Z-offset is active. The Z-offset needs to be active when setting the origin. C - Origin No: This displays the active origin/ coordinate system. When it reads 0, no origin is active and the coordinate system displayed is the from the Home position. The system is setup to accommodate 8 origins, but many more can be made available. D - Z Offset: This is the amount of Z-offset being applied to the tool. Z-offset is the distance from the home position and it is set in the Tool menu using the tool calibration block. 19 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 20 HDS Series F-Origin Functions A - APPLY ORI 1: Left clicking on this button activates Origin 1 for the coordinate system. B - GO TO XY0 ORI 1: Left clicking on this button moves the Z axis to the home position and the XY axes to the X-zero, Y-zero for Origin 1. (XY=0) C - Save Origin: Origin can also Left clicking on this button opens the Save Origin Screen Safe Mode be called the XYZ Option. In this screen the user can save the position of the machine zero point. as the Origin. This is where the user sets XYZ zero. This Safe Mode Option will provide additional warnings and opportunities for the user to ensure that the origin is saved correctly. 20 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 21 HDS Series G-Save Origin Menu When the Save Origin button is clicked on the main screen, this screen will open. This screen provides a reminder to identify the tool in the tool holder before saving an origin. This screen A - Warning Message: This gives the user instructions on how to save an origin correctly. gives the user an B - Coordinate System: opportunity to This displays the coordinate system, as explained in Section E. identify the tool in C - Jog Functions: the holder. This is a minimized version of the jog functions, as explained in Section A. D - Tool: This displays the Tool Number. It should read 1.1, or 2.2, or 6.6 etc, indicating that an offset is applied. E - Identify Tool: Left clicking on one of these buttons will apply the offset to the Tool number, or rename / reidentify a tool. F - Ori Set: Will open the Origin Preset Screen where the user will enter the Origin number to be saved and set XYZ to zero. G - Menu Screen: Changes the screen. H - Return to Main Screen: Once the Origin has been set, left clicking on this button will return to the main screen. 21 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 22 HDS Series H-Spindle and Coolant Control The section highlighted below allows manual control on the Spindle and Coolant. A-Spindle On/Off : If you press the button beside the ON switch, you will turn the spindle on. If you press the button beside the OFF switch, you will turn the spindle off. B-AUX (Coolant) On/Off : Pressing the button beside On will turn the AUX (coolant) on, pressing the button beside Off will turn the AUX (coolant) off (it will do nothing if the system does not have a coolant). I-Load G-Code File A - G-code File: Pressing this button will open the G-code file folder, allowing the user to activate or deactivate a G-code file. 22 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 23 HDS Series J-Program Functions The section highlighted below contains the program functions A - AUTO: When this button is active, the G-code file will run in continuous mode. B - STEP MODE: When this button active, the G-code file will run in Step mode. C - Edit: Left clicking on this button will open the file directory allowing the user to edit the g-code in the text editor D - Preview: Left clicking on this button will open the file directory allowing the user to preview the G-code file in the Techno Previewer. E - CYCLE START: Pressing this button will start the active G-code file, in either Step or Auto mode. If no mode is selected then nothing will happen. Cycle start will also carry out commands in MDI mode. F - HOLD: Pressing this button will pause the operation that is in progress. Releasing hold and pressing Cycle Start will continue the operation. G - RESET: Pressing this button will abort the operation that is in progress. Reset will clear the Tool, origin and file settings. H - Mem S: This button will search the G-code file to find the point where the last Reset occurred. Then the file can be started from this point. I - BLOCK: This button will open the block window, allowing the user to select a specific block of G-code to run. (ie N400 to N1200). J - Return To Profile: If the machine is jogged off the part during Hold, it will need to return the point it was in on the G-code file if you want to continue the operation. Left clicking this button and then holding down the directional arrow for each axis will move the machine back to the correct position. Left clicking this button will pause whatever action is taking place. 23 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 24 HDS Series K-Tool Menu When Tool is clicked on the main menu, the screen below will open up. In this screen tool A - Tool Offset Preset: This section allows the user to manually enter tool offsets. B - CHANGE TOOL: Left clicking on one of these buttons will make the machine pick up the corresponding tool number. C - IDENTIFY TOOL: Left clicking on one of these buttons will change the tool number on the screen and apply the Z-Offset to that specific tool D - Jog Functions: This is a minimized version of the regular jog functions. E - Z-Offset Update: Pressing one of these buttons will cause the Tool to move down until it touches the Tool Calibration Block, and then it will store the Z-offset for that tool number. F - Pneumatic Controls: This section controls dust shroud, chuck control and pop up pins. G - HOLD: Pressing hold during a tool change will cause the operation to be aborted. H - Coordinates System: This displays the system coordinates and active origin, etc. I - SPEED: Jog speed, and speed the machine moves when changing tools can be controlled by these settings. J - Rotate Tool Carousal Anti-Clockwise: Turns the tool carousal circularly to the left. K - Rotate Tool Carousal Clockwise: Turns the tool carousal circularly to the right. 24 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 25 HDS Series L-Offset Menu When Offset is clicked on the main menu, the screen below will open. In this screen multiple offsets can be saved and recalled. A - ACTIVATE ORIGIN: Left clicking on these buttons will activate the corresponding Origin. B - ORIGIN SET/SAVE ORIGIN: Left clicking on this will open the Origin Preset screen. This will allow the user to save the current position of the spindle in a specific origin number. C - Jog Functions: This is a minimized version of the regular jog functions. D - Z-offset Update: Pressing one of these buttons will cause the Tool to move down until it touches the Tool Calibration Block, and then it will store the Z-offset for that tool number. Each tool is specified to its offset. (Ex: Identify tool 1, then press offset 1, identify tool 2, then press offset 2.) E - GO TO ORIGIN: Left clicking on one of these buttons will move the router to the XY zero position for that origin number. The Z axis will move to the home position. F - Pneumatic Controls: This section controls dust shroud, chuck control and pop up pins. G - HOLD: Pressing hold during an operation will cause the operation to be aborted. H - Coordinates System: This displays the system coordinates and active origin, etc. 25 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 26 HDS Series Section 2.3 File System | Network System The PC is connected to the OSAI controller by an ethernet cable. The Techno interface communicates in real time with the OSAI controller via the ethernet cable to allow jogging and other manual functions. In order to run G-code files to the OSAI controller, they must be copied onto the OSAI controllers hard drive. The OSAI controller is identified as a network drive called Y: OEM and X: USR G-code files must be copied into the Programs folder in order for the OSAI controller to locate and run them. For convenience there is a shortcut to this folder on the desktop of the controlling PC. This folder can be called “Programs” or “G-code Files. ” In order to run a G-code file, it should first be dragged into this folder, and then accessed through the interface. NOTE: The OSAI controller runs in a Linux type operating system, and subsequently file names can only be 8 characters long, and they are case sensitive. 26 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...

  • Page 27: Jogging The Machine

    HDS Series Section III: Operating Tutorials 3.1 Jogging the machine The machine has three jog modes: Click on the first • Handwheel: box to enable In which the machine is controlled by the handwheel / manual pulse Handwheel generator on the side of the machine. Control. • Continuous: In which though fluid and smooth continuous movement the machine is controlled. Speed is controlled by the Jog Speed Bar. Note: • Step: You cannot Similar to continuous, however with every mouse click the machine change tools or moves a distance determined by the Jog Step Bar. save origins while in Handwheel Jog A mode MUST be selected in order for the machine to move. The selection Mode. box to the left of the text indicates what mode is selected. Click on the box beside the mode name to select it. Increase (+) or decrease (-) the Jog Speed by pressing Increase or decrease the Jog Step by the (+) or (-) box. Speed is shown in % of maximum speed.
  • Page 28 HDS Series MDI mode stands for Manual Data Input. Activate this mode by clicking the icon in the Jog box. MDI. When this mode is selected a Test box will appear. G-code commands can be entered in this box, then clicking Cycle Start will run the command. Eg, G0 X10Y10 in the box then Cycle start will move the machine to X10 Y10 M3 S18000 will turn on the spindle at a speed of 18000rpm M5 will turn off the spindle. (UAO,03) will activate Origin 3 M6 T4 will pick up tool 4 28 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...

  • Page 29: Learning Tool Lengths

    HDS Series 3.2 Learning Tool Lengths Tool lengths will record how long the tool is in the holder and record the offset value. This will allow multiple tools to be used in a single file. Tool Stand Locations should be pre-learned from the factory. If the Tool locations are incorrect, see Learning Tool Locations section of the appendix. To learn tool lengths. Click on Tool in the main screen of the Techno interface. Warning take note of the T.OFFSET number. If it tries to return a tool to an occupied tool location, it can cause damage to the tool stands. Place the router bits in the tool holders, ensuring that they are secure. Place the tool holder in the chuck. This can be done manually by pressing the -Click Reset to remove any offsets. green button on the side of -Click OFST # . Where # is the number of the Tool you have in the spindle, then placing the the chuck. tool holder in the spindle and releasing the button. If the tool The machine will go to Top of the Z travel, then slowly move is in the tool stand, press the down to the pad. It will touch the brass colored section of the corresponding button under the pad, retract, and then move down again to confirm the value. Manual Tool Change bar in the Tool Screen.
  • Page 30 HDS Series 3.2 Learning Tool Lengths (Continued) Tool lengths will record how long the tool is in the holder and record the offset value. This will allow multiple tools to be used in a single file. Identify or Change Tools by pressing these buttons. 0 is an empty chuck. If jogging the machine make sure This displays the Tool that is in one of these buttons the chuck. is clicked, otherwise it 1 means no offset is applied. will not move. 1.1 means offset is applied. 30 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...

  • Page 31: Saving An Origin | Setting Xyz Zero Position ............................. Page 31 - 32

    HDS Series 3.3 Saving An Origin | Setting XYZ zero position When setting an origin, make sure the correct tool is in the chuck and this tool has been identified. The T.OFFSET box in the top right hand side of the screen should be 1.1 or 2.2, etc ,for whatever tool is in the chuck. If the T.OFFSET box only reads one digit, the tool must be identified in the Tool screen. XYZ zero position is the location point on To set the Origin: a drawing in a CAD/CAM package where Move the machine to the location on the X,Y and Z all equal zero. Generally, XY table you want to set as XYZ. Use the zero is on the bottom left corner and Z handwheel for precision. zero is the top of the part. The letters to be cut are located away from the XY zero. Continuous must be active to save origin. Once in position switch to Continuous Jog mode. Note: You cannot save an origin with the handwheel active. 31 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 32 HDS Series The Save Origin screen will open, and a reminder to load the tool number will appear. Click the number of the tool that is in the spindle, then click ORI SET. Enter the Origin Number on top and zero in the XYZ boxes. - Click OK. - Click Return to Main Screen, when done. The coordinates displayed will still be the Home Coordinates. That is the coordinate system from the home position. To display the Origin just saved. Click on Apply ORI 1. The coordinate system will now switch to the origin you saved. The data (UAO,01) in the G-code file will also switch coordinate systems. So if you hit reset and the coordinate system returns to the The origin is now set. If you click reset, the coordinate Work/Home Coordinates when the system will switch back to home coordinates, and the tool G-code file is started, the controller offset will be removed. Identifying the Tool in the chuck will read the (UAO,01) command and clicking Apply ORI will enter the values again. and apply Origin 1. 32 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...

  • Page 33: Preparing A G-Code File

    HDS Series 3.4: Preparing a G-Code File The G-code file must be copied into the programs folder on the PLC directory. There is a shortcut to this on the main desktop. - Drag your files from the USB to the desktop icon or copy and paste. - Files must be no more than 8 characters in length. Files can be copied in to the programs folder, but make sure the file G600 is in the same folder as your file. This data must be in the G-code file. If the correct post to Techno Osai HDS machine is used in the CAM package, then it will be entered automatically. Data For a Techno Osai G-code File. Start of File: G70 (Programming in Inches) G90 (Absolute Programing) G40 (Disables Cutter Diameter compensation) G80 (Disable Can Cycles) G17 (Circular interpolation on XY plane) G27 (Continuous sequence operation with automatic speed reduction on corners) M143 Edge Pop Up Pins Down) M49 (Dust shroud down) G600 (Loads a set of parameters into controllers amplifiers. This is a txt file that needs to be in the directory of the G-code file.) (UAO,01) (Applies Origin 1 to machine coordinates. Ideally user will have an option to select Origin number 1-5)
  • Page 34 HDS Series 3.4: Preparing a G-Code File (Continued) End of File: M05 (Spindle Off) M48 (Dust shroud up) M30 (File end) So the start of a typical file will look like this. M143 G600 (UAO,01) T1 M6 M3 S18000 (DLY,05) Then the customers G-code. 34 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...

  • Page 35: Running A G-Code File

    HDS Series 3.5 Running a G-Code File Click on G-CODE File to access the file menu. Locate the File you want to load. Left click on the file. When loading a new file click Deactivate to remove the old - Click Activate to load it to the machine. file, before you click activate. - Close the window by clicking X. (Continued on next page) 35 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 36 HDS Series 3.5 Running a G-Code File (Continued) The file name will now appear on the top right of The file will now run. the screen. You are now ready to run the file. - Pressing HOLD will pause the machine. - Pressing CYCLE START will continue the file. To run the file. -Ensure that the Origin and the Tool offsets are set. DO NOT JOG OFF THE PART WHILE IN HOLD. If -Check AUTO to run in Continuous mode. you do, you will need to use the return to profile -Click CYCLE START to run the file. function to return to continue the file. The cut speed and spindle speed can be adjusted See advanced tutorials to learn how to do this. by pressing the (+) or (-) blue box under cut speed. RESET will stop the file and reset offsets and the origins. To Override speeds, click on Setup and select Feedrate Bypass. The Cut speed will now be determined by the Percentage of the maximum jog speed. 36 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 37 HDS Series 3.6 Machine Origin, Working Origin and Offsets Machine Origin: When the machine goes to the home position, the coordinate system is set to zero. This is the machine origin. Machine origin is a reference position from which Tool locations, lengths and saved offsets can be recalled. Machine origin is always located in the bottom left corner of the machine. Once the machine has been homed, machine origin is no longer a concern for the user. Working Origin: Working origin, also called Origin, or XYZ zero position, is the coordinate system the part to be cut exists in. Working origin can be saved by the user anywhere on the table. If the working origin is set too close to the gantry, and the G-code file has positions beyond the size of the table, an error message will be produced stating that an over travel limit has been reached. Use the Save Origin button to save an origin. Offsets: Offsets are just another name for a saved Working Origin. Different offsets can be saved using the Save Origin function, but instead of naming the offset 1, pick a different number. Offsets can be activated in the interface by clicking ACTIVATE ORIGIN in the Offset Menu and in the G-code by using the function : (UAO,0#) Where # is the offset number.

  • Page 38: Using Block To Block Function

    HDS Series SECTION IV: Advanced Tutorials 4.1 Using Block to Block Functions Block to block function will allow a particular section of a G-code file to be run. For this function to operate, the G-code file must have line numbers in the following manner: N100 G0X35Y10 N101 G1X35Y0 etc When Block to Block is clicked, the user will be asked to enter the Starting block Number and the ending block number. Once the blocks are selected, click OK Pressing CYCLE START will run the section of G-code file selected. NOTE: Running a file from block to block will ignore all other parts of the file. This means a spindle on command, Tool change and origin must be called at the start of the block if a part is to be cut. This information can be manually entered in a text editor. 38 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...

  • Page 39: Mem Search

    HDS Series 4.2 Mem Search Mem search will allow you to find the last reset point in the file currently activated. If you press RESET while running a file, you can continue from that point by pressing MEM S. The G-code will be searched for the last break point, and once it has been found, pressing CYCLE START will continue from that point. 4.3 Return to Profile. If the user presses HOLD while a file is running and jogs off the part, when they try to restart, a “Not on part profile error” will appear. To return to the part profile: - Press Return to Profile. - Press the Y axis arrow, the Y axis will move to the position it was in when hold was pressed. - Press the X axis arrow, the X-axis will move to the position it was in when hold was pressed. - Press the Z axis arrow, the Z-axis will move to the position it was in when hold was pressed. - “Spindle on Part Profile” message will appear on the screen. - Deactivate hold, by clicking HOLD. - Select AUTO. - Click CYCLE START to continue the file. 39 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...

  • Page 40: Setup Parameters

    HDS Series 4.4. Setup Parameters Certain parameters for a G-code file can be changed from the Setup window in the interface. Any changes here are cleared when RESET Click on Setup and the drop down menu will appear. Manual Setup will allow the user to change the Jog step size. Checking Auto will mean the machine will jog the full step size when the jog arrow is pressed once. Checking Manual will mean the machine will only jog while the arrow is held down. When it reaches the step size, it will stop and the user will have to release the button and press again. All the other options on this window are disabled. 40 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 41 HDS Series Dynamic Parameters will allow adjustment in canned drilling cycles. See the Osai G-code manual for more details on canned cycles. Dynamic Limits will effect the smoothness of the machine. See the Osai Amp manual for more details on these values. Program Setup will allow adjustments to the G-code file. - Block delete will delete a highlighted part of a G-code file. - Feedrate bypass will override the programmed feedrates and use the percentage feed on the main screen. - Disable program scroll will stop every line of G-code appearing on the screen. - Optional stop will disable any M01 commands in the G-code file. - Rapid override control will allow speed to be overridden when the file is running. 41 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 42 HDS Series Probe Setup controls the way the tool offsets are learned and should not be Set Accuracy will adjust the arc tolerance for circles and curves in the file. See the Osai Amp and Osai G-code manual for more information 42 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...

  • Page 43: Backing Up Parameters

    HDS Series 4.5 Backing Up Parameters. The parameters of the Amp and PLC should be backed up before any adjustments are made to them. Restart the controller in Setup Mode. Select Boot, then Restart, then pick Setup from the Mode menu. Once in Setup Mode, click on the Security Icon to enter the security window. 43 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 44 HDS Series Click on Backup to select the backup option Click on Browse and pick / create a suitable folder to save the backup, enter a suitable file name for the backup and click Save. 44 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 45 HDS Series Once complete, close the Security Check the box beside All the control window, and reboot the controller in and click Start to begin the backup. Normal mode. To Restore a saved backup, just reboot in setup mode again, and select Restore to load the saved settings. 45 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 46 HDS Series V. Machine Lubrication 5.1 Lubricating the X-Y Rack and Pinion. Lubrication is important with rack and pinion gearing systems. A thin film of grease should always be present on the contacting tooth flanks to minimize metal to metal contact. Lithium grease lubrication is recommended over oil, as the oil lubrication will flow away from tooth flanks. The racks should be cleaned with a degreasing agent Y axis and fresh clean grease should be applied at regular intervals depending on the usage of the machine. It is recommended that this is done every 80 hours of machine usage. Use a small brush to coat both racks on the side of the Y axis and the single rack across the X axis. 5.2 Lubricating the X-Y-Z Rails The rail carriage bearings are sealed and protected with wipers. The rails should be lightly oiled to allow smooth operation. Avoid a build up of debris on the rails by blowing them off with air or wiping them down with a rag. The rails do not need to be lubricated as often as the rack. Once a month should be sufficient. X axis Recommended Lubricants. *Lubrication gun is not provided with the mahine!! * Some machines have zero fitting for rail carriage bearings, while some machines do not! Lithium Based Grease: • Alvania Grease No. 2(Shell) or Equivalent. • Techno Part No. H90Z00-8670T8 Z axis Oil: • Vactra No. 2s(mobile) • Tonner Oil or Equivalent. •...
  • Page 47 HDS Series Section VI: Appendix (Diagram 2. The current HSD Aggregate Tool aggregate angle.) Please follow these instructions carefully to properly install the HSD aggregate on your machine. (Diagram 1. The pin must be in this position in the tool holder.) Diagrams 2 and 3 illustrate how to adjust the angle of the aggregate cutting tools.
  • Page 48 HDS Series How to Set Up Tool Offsets with Aggregate Tools Click “Utility.” Click “Table Editor.” Click here Click here for tool for English lengths. units. In the offset screen, you will enter the following values for the aggregate offset.

  • Page 49: Service And Maintenance

    HDS Series P a g e Service and Maintenance Caution (1) Maintenance shall be performed by qualified personnel. (2) Switch off the main power supply before servicing. If power supply is needed, have qualified personnel operate it. (3) Use genuine replacement parts and components.
  • Page 50 P a g e HDS Series Electrical Cabinet Maintenance Caution: Switch off the main power supply before servicing. If power supply needed, qualified personnel shall operate it. (1) Clean the cabinet with dust collector once every week. Be careful not to damage or loosen any wire connections.
  • Page 51 P a g e HDS Series 9 months to Yearly or after 4,000 hours *Check Vanes for minimum width (41 mm). Replace if necessary. *Inspect vanes for improper wear (cupping). Replace if necessary. *Inspect teflon tube seals in end shield.
  • Page 52 P a g e HDS Series sensitiveness and may fail to give alarm when the machine over travels, which could lead to mechanical crash and damage to the machine. The way to check is to press the switch with hand and see if it gives off alarm. You can also check if the I/O port input signal changes.
  • Page 53 P a g e HDS Series Appendix I Daily Maintenance Sheet 29 Trade Zone Drive, Ronkonkoma NY 11779 Office: (631) 648-7481 www.technocnc.com 53 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 54 HDS Series 6.2 Common Problems | Error Messages | Solutions Problem Solution Machine freezes during tool This error can occur if the pneumatic sensor on the dust shroud is faulty. change, or when it tries to do To check this: • a tool change in a G-code file. Press dust Shroud UP on the main screen. • Look at the sensor on the piston; it should be red when the shroud is up. • If not, move the sensor around the cylinder until the light comes on. • If the light will not come on, it will need to be replaced. Syntax Error when loading a There is an unrecognized command in the G-code file. G-code file Use the correct Techno post in the CAM package and output the file again. Error Message Problem Solution 001 EMERGENCY STOP ACTIVE E-stop pushed in. Release E-stop, and click E-stop release on screen. 010 CAUTION! OVERTRAVEL LIMIT ACTIVE G-code file will go Adjust working origin. beyond the table size if Redo G-code file to correct size.
  • Page 55 P a g e HDS Series Appendix II Common Errors and Solutions Driver Error Codes 29 Trade Zone Drive, Ronkonkoma NY 11779 Office: (631) 648-7481 www.technocnc.com 55 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 56 P a g e HDS Series List of Alarms for VFD 29 Trade Zone Drive, Ronkonkoma NY 11779 Office: (631) 648-7481 www.technocnc.com 56 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 57 P a g e HDS Series 29 Trade Zone Drive, Ronkonkoma NY 11779 Office: (631) 648-7481 www.technocnc.com 57 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 58 P a g e HDS Series 29 Trade Zone Drive, Ronkonkoma NY 11779 Office: (631) 648-7481 www.technocnc.com 58 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 59 HDS Series VTLF 2.200 Driftsinstruks Betriebsanleitung Operating Instructions Driftsinstruktioner VTLF 2.250 Instructions de service Käyttöohje Istruzioni d’uso Driftsvejledning Handleiding Instrukcja obsługi Kezelési útmutató Instrucciones para el manejo Návod k obsluze Manual de instruções 98/37 EG Navodilo za uporabo Naudojimosi instrukcija Návod na obsluhu...
  • Page 60 HDS Series Mat.Nr. XXXXXX ENXXXX 3 Mot. XXXXXXXX NoUD XXXXXX 50 Hz 60 Hz XXKW XXKW XXX-XXX / XXX-XXX XXX-XXX / XXX-XXX XX-XX / XX-XX XX-XX / XX-XX 0.XX-0,XX 0.XX-0,XX XXXX-XXXX /min XXXX-XXXX /min XX kg MAX. 6x /h =OFF L2 L1 L3 I >...
  • Page 61 HDS Series “ < 2m 2m...3m “ / 3“ > 3m...10m VACUUM 5 Min =OFF 40 - 200 h www.beckerpumps.com 61 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 62 HDS Series VTLF 2.200 VTLF 2.250 VTLF 2.200 VTLF 2.250 x x x F2 (VTLF - SK) D: 218 mm D: 64 mm H: 122 mm H: 120 mm No.: 909512 No.: (2x) 909510 3000 h www.beckerpumps.com 62 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 63 HDS Series MAX. MIN. > 41mm < 41mm � → No. 90136701005 (SET) No. 743303 Amblygon TA 15/2 3000 h 2x 10g 63 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481 www.beckerpumps.com...
  • Page 64 HDS Series TLF 2.250-2.500 Internal Filter Inspection -Tools required- Flashlight ATTENTION Author: Mike Ruff Becker Pumps Corp. VISUAL CLUES REGARDING VTLF 2.250 FILTER MAINTENANCE SHOULD NOT ALWAYS BE THE SOLE INDICATOR OF WHETHER A FILTER IS “CLEAN”. THOUGH THE FILTER HAS TREMENDOUS SURFACE AREA, THE DEEP PLEATING OF THE FILTER MAY DISGUISE WHETHER THE FILTER IS CLOGGED.
  • Page 65 HDS Series -Remove the internal filter and look for debris- -Check for large debris deposits. This is an indicator that the filter caught the smaller particles- Author: Mike Ruff Becker Pumps Corp. -Use a flashlight on the outside of the filter- Author: Mike Ruff Becker Pumps Corp.
  • Page 66 HDS Series If light cannot be seen on the inside, the filter is clogged and needs replaced. Author: Mike Ruff Becker Pumps Corp. -If you can see light, then blow out the filter using compressed air and replace- • This needs to be a modest amount of light.
  • Page 67 HDS Series Greasing TLF 2.200-2.360 -Tools required- X1 – 7433050000 (50 gram grease gun) Author: Mike Ruff Becker Pumps Corp. Greasing instructions The greasing instructions can be found on step “P.” in the operation manual sent with each pump. Or they can be found at www.Beckerpumps.com...
  • Page 68 HDS Series All new units come with new grease guns. (Found in either of the two places below) Author: Mike Ruff Becker Pumps Corp. GREASING PROCEDURE Author: Mike Ruff Becker Pumps Corp. 68 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481...
  • Page 69 HDS Series Remove the filter cover by loosening the black hand knobs. Author: Mike Ruff Becker Pumps Corp. Remove the internal filter and replace if needed. Grease fittings are found next to the filter. (Remove the red caps.) Author: Mike Ruff Becker Pumps Corp.
  • Page 70 HDS Series Remove the black cap from the grease gun Author: Mike Ruff Becker Pumps Corp. Prime all new grease guns by placing them at an angle against a hard surface. Pump a few times until the grease is visible at the tip.
  • Page 71 HDS Series Place the grease gun against the push fitting Pump 10x into each bearing (New or dry bearings = 25 times per bearing) Author: Mike Ruff Becker Pumps Corp. Once the pump is ran, the grease will evenly distribute between the rollers and ball bearings.
