Spinlock Deckware Series Manual

Automatic lifejacket with integral deck harness
Hide thumbs Also See for Deckware Series:

Advertisement

Quick Links

150N Automatic Lifejacket with
integral Deck Harness
approved to CE European & ISO International Standards
Includes essential Sprayhood, Thigh straps,
Emergency line cutter, and Water-activated
high intensity flashing Light
Unrestricted working at speed
Soft contoured to fit the body, the clean, cutaway
shape is strikingly comfortable to wear in all
weathers.
ESSENTIAL INFORMATION: DO NOT REMOVE
UNTIL SOLD.
It is essential you read these instructions before
using your Deckvest.
ISO 12402-3 - 150N Lifejacket
ISO 12401 - Deck Harness
DECKVEST AUTOMATIC GAS INFLATION
This device is designed to inflate automatically upon immersion. Pulling the manual inflation handle will
also activate the inflation mechanism or it can be inflated by blowing into the oral inflation tube. It can
be converted to non-automatic operation using a Spinlock Deckware Series Manual Conversion Kit.
www.spinlock.co.uk
WARNING:
WHEN NOT CORRECTLY FITTED, THIS PRODUCT
MAY NOT PERFORM AS A LIFEJACKET OR HARNESS
RISKING SERIOUS DANGER TO THE USER.
50kg+
Automatic inflation
Latest UML Pro Sensor
®
designed to inflate when submerged. Visual
indicator shows the 'armed' status of the cylinder
and the firing head.
Instantly fitted
The high tensile 2T front fastener provides instant
access. Twin adjuster buckles ensure a snug and
secure fit when tightened.
For users aged above 16 years and weighing
not less than 50 kg.
Do not use for white water paddling or with
personal watercraft.
Do not use as a cushion.
Gas cylinders are dangerous goods. They
should be kept out of reach of children and
not be misused.
automatic firing head

Advertisement

loading
Need help?

Need help?

Do you have a question about the Deckware Series and is the answer not in the manual?

Questions and answers

Related Manuals for Spinlock Deckware Series

Summary of Contents for Spinlock Deckware Series

  • Page 1 This device is designed to inflate automatically upon immersion. Pulling the manual inflation handle will also activate the inflation mechanism or it can be inflated by blowing into the oral inflation tube. It can be converted to non-automatic operation using a Spinlock Deckware Series Manual Conversion Kit. www.spinlock.co.uk...
  • Page 2 Product features Inf lated: Ultra-compact personal deck safety wear.
  • Page 3 QBZ split zip. Instant access to oral inflator tube. Ensures rapid inflation and easy repacking. Emergency safety line cutter. Stowed in snag-free pouch for instant access. ‘Through Life Support Program’ for registered owners including extended 5 year guarantee. Please register within 30 days of purchase at www.spinlock.co.uk...
  • Page 4 Fitting and adjusting B C D E C D E A B C...
  • Page 5 Tightening / loosening Threading buckles A B C D Fitting thigh straps Back of harness...
  • Page 6 How to use Safety line attachment point - Only use marked loop for attachment. Guidance Jackstays / Fixed eyes Anchorage points must be able to withstand forces more than 1 tonne. (Safety line for illustration only)
  • Page 7 Lifejacket inflation: UML Pro Sensor ® Manual / Auto Auto Oral inflation Firing head Green...
  • Page 8 Lifejacket repacking See video at www.spinlock.co.uk B C D Remove all air. Open zips. Run right hand slider round to left hand side. Insert firing-head A B C into mesh pocket RE-attach zips on side on the cover. with Firing head.
  • Page 9 Concertina bladder onto itself ensuring a smooth flow for the manual lanyard. Run zip round to close and fasten flap across Concertina top in. breakout point and ensure firing head is aligned in the window Sprayhood...

  • Page 10: Table Of Contents

    Instructions for use 15-17 Inspection record sheet Spinlock Deckvest This Deckvest is an integrated lifejacket and harness approved to ISO 12402-3 (150N). It is important to get into the habit of wearing Deckvest. It is comfortable, safe and a pleasure to wear.

  • Page 11: Inflating And Deflating Your Lifejacket

    Inflating your lifejacket It is recommended that the following inflation procedures are followed: 1. MANUAL INFLATION To manually inflate the lifejacket, sharply pull the rubber handle downwards. The CO2 gas cylinder should inflate the bladder within seconds. 2. ORAL INFLATION To inflate the lifejacket by mouth, locate the oral inflation tube by opening the zip at the yellow breakout point on the front panel of the lifejacket.

  • Page 12: Maintaining Your Deckvest

    (For details of your nearest service centre see www.spinlock.co.uk). Any modification or repair to any part of the Deckvest is expressly forbidden unless carried out by Spinlock Ltd.

  • Page 13: Testing Your Lifejacket

    5. Let the Deckvest dry thoroughly. Do not expose to direct heat. REMEMBER: RE-ARM AND RE-PACK THE LIFEJACKET IN ACCORDANCE WITH THESE INSTRUCTIONS - See video at www.spinlock.co.uk WE RECOMMEND THAT THE AUTOMATIC CAPSULE IS REPLACED ANNUALLY. ALSO UNSCREW AND INSPECT THE THREADED END OF THE CO2 CYLINDER...

  • Page 14: Re-Arming And Re-Packing Your Lifejacket

    Re-arming and re-packing your lifejacket after inflation 1 33 g CO2 cylinder 2 Automatic firing capsule 3 United Moulders Pro Sensor inflator ® 4 Valve retaining nut 5 Manual firing lanyard 6 Activation indicator window All Green - ready to go Red - needs rearming Examine the automatic capsule.
  • Page 15 Fig. 2 2. Make sure the manual lever is in the up and ready position. Install the CO2 cylinder into the inflator by screwing it until hand-tight (Fig.2). Check that the automatic capsule has not been fired by ensuring that the bottom indicator is showing green.

  • Page 16: Instructions For Use

    In case of doubt or and its margin of safety. Do not hesitate to contact any problem of understanding, contact Spinlock. Spinlock in case of doubt. Water sports are dangerous activities which may CLEANING, MAINTENANCE, STORAGE lead to severe injuries or even death.
  • Page 17 If your Deckvest comes in contact with date of manufacture. This guarantee is extended to chemicals, please notify Spinlock, stating the precise five years conditional on registration of ownership chemicals concerned. We will investigate and give by the first owner.
  • Page 18 (EN)Temperature (FR) Température (DE) Temperatur (IT) Temperatura (ES) Temperatura (NL) Temperatuur (DK) Temperatur (S) Temperatur (EN) Storage (FR) Stockage (DE) Lagerung (IT) Conservazione (ES) Almacenamiento (NL) Berging (DK) Opbevares (S) Förvaring (EN) Dangerous products (ES) Productos peligrosos (FR) Produits dangereux (NL) Gevaarlijke producten (DE) Gefährliche Produkte (DK) Farlige væsker...

  • Page 19: Inspection Record Sheet

    (EN) Model : (EN) Purchase date : (F) Modèle : (F) Date de l’achat : (D) Modell : (D) Kaufdatum : (IT) Modello : (IT) Data di acquisto : (ES) Modelo : (ES) Fecha de compra : (NL) Model : (NL) Aankoop datum : (DK) Model : (DK) Købs dato :...
  • Page 20 Deckvest Serial number Spinlock supports the Royal National Lifeboat Institution (RNLI) ‘Sea Safety Lifejacket Campaign’ Please register your Deckvest serial number now at www.spinlock.co.uk Spinlock Ltd The Spinlock Deckvest is extensively protected under various National, European and International Patents and 41 Birmingham Road Design Rights owned by Spinlock Ltd.
