MP187EK 1.0.0 05/2019. 0.3
Positioners with Electric Motors
to 320 V
Short Instructions
L-412 / L-417
User Information
These short instructions contain an overview of the most important safety and handling instruc-
tions for installing high-load linear stages with electric motor to 320 V (hereinafter referred to as
"positioner") with the product numbers specified above.
Subject to change. These short instructions are superseded by any new release. The latest respec-
tive release is available for download on our website.
Downloading and Reading the Manual
The actions during installation, startup, operation, and maintenance require additional information
from the manuals of the positioner and/or the electronics.
Manuals may be titled as follows: "User Manual", "Technical Note".
Downloading the Manuals from the Website:
1. Note the product number on the product (e.g., L-412.099025E1).
2. Open the website www.pi.ws.
3. If the product was shipped with a data storage device: Log into the website:
a. Click Login.
b. Enter the login data. The login data is in the [...]_Releasenews_[...].pdf file in the Manuals
directory on the product's data storage device.
c. Click Login or press the Enter key.
4. Click Search.
5. Enter the product number up to the period (e.g., L-412) into the search field.
6. Click Start search or press the Enter key.
7. Click the corresponding product in the list of search results.
8. Click the Downloads tab.
The manuals are shown under Documentation.
9. Click the desired manual and save it.
If you cannot find the manual you are looking for or if you have any questions: Contact our custo-
mer service department via service@pi.de.
PI miCos GmbH, Freiburger Strasse 30, 79427 Eschbach, Germany
Phone +49 7634 5057-0, Fax +49 7634 5057-99, Email info@pimicos.de, www.pi.ws
