- Page 1 JUNE 11, 2019 Ver0.95 USB3.0 InGaAs NIR CAMERA ARTCAM-131TNIR INSTRUCTION BOOKLET ARTRAY CO., LTD. - 1 -...
-
Page 2: Table Of Contents
6.4. Each Terminal Information on the Back of the Camera ........- 13 - 7. Dimensional Outline ................... - 14 - 7.1. ARTCAM-131TNIR ..................- 14 - 8. Spectral Sensitivity Characteristics (Reference Value) ..........- 16 - 8.1. ARTCAM-131TNIR ..................- 16 - 9. -
Page 3: Attention
1. Attention ■ About this manual 1．Before using the camera, please read this manual thoroughly. 2．Please keep this manual reachable and always refer to the contents when needed. 3．Please contact us if the manual is lost or damaged. We will provide a replacement. 4．We cannot guarantee the safety of improper uses of the camera. - Page 4 ■ For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own. Please stop using the product and turn off the power immediately when: ・The product becomes smoky or gets extremely hot on the surface, or makes unusual smells or sounds.
- Page 5 To save the environment, we do not issue warranty in printed format. Instead, all records of the warranty periods, delivery dates and the customer information are well kept in our system. For more details, please refer to the sites below: Hardware Warranty: http: //www.artray.us/download/artray_warranty.pdf - 5 -...
-
Page 6: Introduction
The InGaAs sensor can detect radiation invisible to human eyes and CCD/CMOS cameras in the wavelength range between 900 nm to 1700 nm bond. ●High Resolution, High Frame Rate ARTCAM-131TNIR uses a higher resolution sensor of 636 x 508 pixel and delivers image at 258 frame per second. ●USB3.0 Interface This camera adopts USB3.0 interface, so the data can be delivered to PC directly. -
Page 7: The Product
4. The Product 1) Camera 2) USB3.0 Cable Type A-micro B connector cable, 3m approx. 3) AC adapter (DC12V) 4) Introduction Booklet 5) Special viewer software/Device Driver CD 6) Software Development Kit, ARTCCM-SDK <Options> 1) NIR Lenses (C Mount Lens) - 7 -... -
Page 8: Connect The Camera
5. Connect the Camera 5.1. How to Connect a Camera Please connect the camera and the PC by using the attached USB3.0 cable. Camera’s power is supplied from USB Bus Power. - 8 -... -
Page 9: Specifications
6. Specifications 6.1. Sensor Specification ARTCAM-131TNIR MODEL InGaAs Image Sensor Sensor Type FPA0640P15F-17-C Sensor Model 636(H) × 508(V) Effective Pixel Array 9.6（H）×7.68（V）mm Image Size Progressive Scan Scan Mode 15(H)×15(V)μm Pixel Pitch 900nm~1700nm Spectral Range ≧99.5% Pixel Operability Global Shutter Shutter Type... -
Page 10: Camera Function
6.3. Camera Function 6.3.1. Shutter Speed Setting The exposure time (electronic shutter speed) of the camera can be set in one line time resolution. The exposure time can be calculated by the following formula: Exposure Time = Shutter Value * One Line Time / 1000 [µsec] (Setting Range 1～65533) The calculation formula for the one line time is different for every single mode. -
Page 11: Eternal Trigger Function
6.3.2. Eternal Trigger Function This camera has an external trigger electronic circuit, which is insulated by a photocoupler, and thus enables synchronized shooting by the input signal received from the external circuit. ※It is possible to change the pin connector and pin assignment. - 11 -... -
Page 12: Trigger Timing
6.3.3. Trigger Timing Item Items Required Time Effective Trigger Input Pulse >10μsec. Time required from the starting of the External Trigger to the starting of the <1μsec. Internal Trigger Signals (may be delay caused the photocoupler) Time required from the starting of the Internal Trigger Input to the Exposure 3CLK Time... -
Page 13: Each Terminal Information On The Back Of The Camera
6.4. Each Terminal Information on the Back of the Camera External I/O terminal HR10A-7R-6S(73) (HIROSE) USB3.0 microB Port Power Port DC12V - 13 -... -
Page 14: Dimensional Outline
7. Dimensional Outline 7.1. ARTCAM-131TNIR HR10A-7R-6S(73) (Made by HIROSE ELECTRIC) - 14 -... - Page 15 Position Relationship Diagram between the Sensor Package and the Light Receiving Surface H = 15[um] * 640 = 9600 [um] V = 15[um] * 512 = 7680 [um] Field of Vision: Lens versus Sensor（Reference Value） ※ The ratios of sensor size (diagonal) to lens size in the above illustrations are as follows: 1/2 inch = φ8mm, 2/3 inch = φ11mm, 1 inch = 15.8mm.
-
Page 16: Spectral Sensitivity Characteristics (Reference Value)
8. Spectral Sensitivity Characteristics (Reference Value) 8.1. ARTCAM-131TNIR - 16 -... -
Page 17: System Requirements
What may cause the problem is that the regulation of the power lines becomes not enough, and so causes impudence mismatch on data signals. *For the recommended extension cable, please contact our sales department. (TEL: +81-3389-5488) ARTRAY Co., LTD. Obtained ISO 9001: 2015 2018/9/17 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan TEL: +81-3-3389-5488 FAX: +81-3-3389-5486 Email: sales@artray.us...
