- Page 1 Instruction ManualInstruction Manual L-861SE Clamp Band ERTE Airfield Lighting Incandescent Elevated Runway Threshold/End Light, Medium-Intensity, Clamp Band Product Solutions Catalog 96A0193, Rev. i, www.adb-air.com...
-
Page 2: Disclaimer / Standard Warranty
Storage precautions that must be followed. ADB reserves the right to examine goods upon which a claim is made. Said goods must be presented in the same condition as when the defect therein was discovered. ADB Airfield Solutions furthers reserves the right to require the return of such goods to establish any claim. -
Page 3: Liability
Use this equipment only as described in the manual. ADB cannot be held responsible for injuries or damages resulting from non-standard, unintended uses of its equipment. The equipment is designed and intended only for the purpose described in the manual. -
Page 4: Adb Bvba
This manual could contain technical inaccuracies or typographical errors. ADB BVBA reserves the right to revise this manual from time to time in the contents thereof without obligation of ADB BVBA to notify any person of such revision or change. Details and values given in this manual are average values and have been compiled with care. -
Page 5: Table Of Contents
A.3 LED Product Guarantee ......................ii A.4 Standard Product Guarantee ..................... ii A.5 All Products ......................... ii A.6 Liability ..........................iii A.7 © ADB BVBA ......................... iv Safety ..................................1 1.1 HAZARD Icons used in the manual ....................1 1.1.1 Qualified Personnel ......................1 1.2 To use this equipment safely: .................... - Page 6 L-861SE Clamp Band ERTE 96A0193 Rev. i 3.1 Order Codes ........................19 3.1.1 Product Major Components ....................19 3.1.2 Illustrated Parts List or Exploded View Diagram ..............20 © ADB bvba All Rights Reserved...
-
Page 7: Safety
1.0 Safety This section contains general safety instructions for installing and using ADB Airfield Solutions equipment. Some safety instructions may not apply to the equipment in this manual. Task- and equipment-specific warnings are included in other sections of this manual where appropriate. -
Page 8: To Use This Equipment Safely
• Obey the instructions of the adhesives necessary for the fasteners. Failure to follow these warnings may cause the fasteners to loosen, damage the equipment, potentially to loosen the equipment. This can lead to a highly dangerous situation of FOD, with potential lethal consequences. © ADB bvba All Rights Reserved... -
Page 9: Operation
• Verify that the moving equipment is rated to handle the weight. • When removing equipment from a shipping pallet, carefully balance and secure it using a safety strap. Failure to follow these instructions can result in death, serious injury, or equipment damage. © ADB bvba All Rights Reserved... -
Page 10: Action In The Event Of A System Or Component Malfunction
ARC FLASH AND ELECTRIC SHOCK HAZARD Allow only qualified personnel to perform maintenance, troubleshooting, and repair tasks. • Only persons who are properly trained and familiar with ADB Airfield Solutions equipment are permitted to service this equipment. • An open airfield current circuit is capable of generating >5000 Vac and may appear OFF to a meter. -
Page 11: L-861Se Clamp Band Erte
(63B0415-2) and clear (63B0415-1) inner lenses; clear-obscure outer globe (63B0580); and 2-in. coupling (63A0281). Changed to new title page. Changed ADB to ADB Airfield 5/16/01 Solutions’. Added 115 W lamp to specifications, parts list, and ordering code. -
Page 12: Product Introduction
L-861SE Clamp Band ERTE 96A0193 Rev. i Product Introduction 2.2 Product This section describes the L-861SE threshold/end light. The L-861SE threshold/end light is Introduction used to delineate the threshold/end of non-precision IFR runways. The L-861SE light fixture consists of the following: —... -
Page 13: Electrical Supply
Lamp: 115 W/120 W/6.6 A, GE EVV or Sylvania 115 W Rated Lamp Life: 500 hours (minimum) 2.2.4 Operating Conditions The L-861SE threshold/end light fixture is designed to operate under the conditions presented below for temperature and wind. Temperature: -40 °C to + 55 °C (-40 °F to +131 °F) Wind: Velocities up to 300 mph (480 kph) 2.2.5 Equipment... -
Page 14: Equipment And Accessories Supplied
Table 3: Required Equipment Supplied Description Quantity L-861SE light fixture (includes lamp, frangible coupling, and L-823 cordset) Instruction manual 1 per order 2.2.7 Equipment Required Refer to Table 4 for required equipment that is not supplied. Refer to the Parts section for But Not Supplied part numbers. -
Page 15: Installation Introduction
Introduction Refer to the airport project plans and specifications for the specific installation instructions. 2.3.1 Inspection on Arrival Inspect each light on arrival, note any damage and report to the carrier and your ADB representative. 2.3.2 Storage The proper storage of the ERTE on a shelf is to leave it in the box it arrived in or place in a bin with a protective wrap to protect the glass from damage. -
Page 16: Installation
This subsection provides installation instructions for the L-861SE light fixture. 2.4.1 Placement The L-861SE light fixtures are located 2 to 10 feet (0.6 to 3 m) from the edge of the full strength pavement runway and in a straight line on each side of the runway. The fixtures are spaced longitudinally not more than 200 feet (61 m) apart on a line such that the light units on opposite sides of the runway are perpendicular to the runway centerline. -
Page 17: Light Fixture Mounting
NOTE: Apply anti-seize compound to the coupling threads to improve coupling removal and prevent thread corrosion. 8. Install the column with light fixture attached on the frangible coupling and tighten the coupling screw. Refer to Assembly Instructions in this section. © ADB bvba All Rights Reserved... - Page 18 3 1/2° TOE arrows should point to the imaginary extension of the runway centerline. Always make LH OBSCURED RH OBSCURED sure that the colored lens location is in compliance with the airport project plans and specifications. © ADB bvba All Rights Reserved...
-
Page 19: Stake Mounting
7. Cable Connector Support 7. L-830 Transformer 5. Metal Stake 6. Optional Bare Copper Counterpoise Wire 2. Connectors 3. 5 KV, L-824 Cable 5. Concrete Anchor (Recommended 6 x 6 x 12-in.) 4. Metal Stake (30 in.) © ADB bvba All Rights Reserved... -
Page 20: Stake Installation
When fixtures are located at the end of the runway, the arrows should point to the imaginary extension of the runway centerline. Always make sure that the colored lens location is in compliance with the airport project plans and specifications. © ADB bvba All Rights Reserved... -
Page 21: Maintenance
2.5 Maintenance 2.5.1 Periodic To keep L-861SE threshold/end light fixtures operating efficiently, follow a preventive Maintenance Schedule maintenance schedule. Refer to Table 7. Refer to FAA AC 150/5340-26 for more detailed information. Table 5: L-861SE Threshold/End Light Fixture Maintenance Interval... -
Page 22: Maintenance Procedures
L-861SE Clamp Band ERTE 96A0193 Rev. i Maintenance 2.5.2 Maintenance This section provides instructions for replacing lamps for the L-861SE threshold/end light Procedures fixture. WARNING De-energize the circuit and lock out the circuit or regulator so that the circuit cannot be energized by remote means before attempting to service the fixture. -
Page 23: Troubleshooting
Event of a System or common problems that you may encounter. If you cannot solve the problem with the Component Malfunction information given here, contact your local ADB Airfield Solutions’ representative for help. Product ERTE Troubleshooting Guide Table Table 6:... - Page 24 L-861SE Clamp Band ERTE 96A0193 Rev. i Troubleshooting © ADB bvba All Rights Reserved...
-
Page 25: Parts
Lens, inner - 180° segment, green 63B0415-4 Outer lens, white bidirectional 63B0480 Socket mounting plate assembly (includes socket, mounting plate and 44A2089 inner lens clip) Slot across threaded end allows easy replacement of broken frangible coupling © ADB bvba All Rights Reserved... -
Page 26: Illustrated Parts List Or Exploded View Diagram
Clamp Band L861QSE HEAD ASSY STEEL COLUMN FOR 2" COUPLING SEE DETAIL "B" COUPLING INNER LENS BRKT 61A0146 INNER LENS INNER LENS INNER SPRING CLIP COUPLING DETAIL "B" (FOR 2" COUPLING ONLY) INNER LENS ASSEMBLY © ADB bvba All Rights Reserved... - Page 27 14" OAH, 1-1/2" Coupling 44A2090/XX2X 62B0073 24" OAH, 1-1/2" Coupling 44A2090/XX3X 62B0073 30" OAH, 1-1/2" Coupling 44A2090/XX5X 61A0281 14" OAH, 2" Coupling 44A2090/XX6X 61A0281 24" OAH, 2" Coupling 44A2090/XX7X 61A0281 30" OAH, 2" Coupling © ADB bvba All Rights Reserved...
- Page 28 L-861SE Clamp Band ERTE 96A0193 Rev. i Order Codes Table 12: Stake Mounting and Hardware Item Description Part Number Quantity Note Stake assembly 44B0348 Stake hardware only 44A2158 Stake only 62B0284 © ADB bvba All Rights Reserved...
- Page 29 ADB Airfield Solutions Email: info@adb-air.com Suite 4 2820 Argentia Rd., Unit #2 110 High Street Mississauga, Ontario L5N 8G4 ADB Airfield Technologies Ltd. China Maidenhead Canada Room 901, 9F, Fang Heng Intl. Plaza Berkshire Tel: +1 (905) 331 6887 Building C, No. 6 Futong East Road,...
- Page 30 ADB Airfield Solutions LLC Leuvensesteenweg 585 977 Gahanna Parkway Columbus, OH 43230 B-1930 Zaventem Belgium Phone: +32 (2) 722.17.11 Tel: +1 (614) 861 1304 info.adb@adb-air.com Fax: +1 (614) 864 2069 www.adb-air.com Web: www.adb-air.com Email: adb-sales.us@adb-air.com © ADB bvba All Rights Reserved www.adb-air.com...
