PBS900G
920W/3" BELT SANDER
ORIGINAL INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PBS900G and is the answer not in the manual?

Questions and answers

Related Manuals for BAUKER PBS900G

Summary of Contents for BAUKER PBS900G

  • Page 1 PBS900G 920W/3" BELT SANDER ORIGINAL INSTRUCTION MANUAL...

  • Page 2: Safety Information

    SAFETY INFORMATION WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions Important - Please read these instructions fully before starting assembly may result in electric shock, fire and/or serious injury. General Power Tool Safety Warnings Save all warnings and instructions for future reference.
  • Page 3 suitable for outdoor use reduces the risk of electric shock. f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) Important - Please read these instructions fully before starting assembly protected supply. Use of an RCD reduces the risk of electric General Power Tool Safety Warnings shock.
  • Page 4 b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools.
  • Page 5 EN-5...
  • Page 6 EN-6...
  • Page 7 EN-7...
  • Page 8 SYMBOLS To reduce the risk of injury, user must read instruction manual Wear eye protection Wear ear protection Wear dust mask Warning Double insulation Waste electrical products must not be disposed of with household waste. Please recycle where facilities exist. Check with your local authorities or retailer for recycling advice. EN-8...

  • Page 9: Component List

    10. VARIABLE SPEED CONTROL DIAL 11. SANDING BELT LEVER 12. SANDING PLATE(SEE FIG. F). Not all the accessories illustrated or described are included in standard delivery. TECHNICAL DATA Type PBS900G (PBS-designation of machinery, representative of Belt Sander) Voltage 230-240V~ 50Hz Power Input 920W...

  • Page 10: Noise Data

    NOISE DATA A weighted sound pressure =90.3dB(A) = 3.0dB(A) A weighted sound power =101.3dB(A) : 3.0dB(A) Wear ear protection. Vibration Information Vibration total values (triax vector sum) determined according to EN 62841: Vibration emission value: = 2.5 m/s Uncertainty K = 1.5m/s² The declared vibration total value and the declared noise emission value have been measured in accordance with a standard test method and may be used for comparing one tool with another.

  • Page 11: Operating Instructions

    OPERATING INSTRUCTIONS NOTE: Before using the tool, read the instruction book carefully. Intended Use The machine is intended for dry sanding–with high removal capacity of wood, plastic, metal, filler as well as varnished surfaces. 1. ON/OFF SWITCH (See Fig. A) Depress to start and release to stop your tool.

  • Page 12: Troubleshooting

    6. BELT CENTERING CONTROL(See Fig. F) WARNING! Wear eye protection before carrying out a belt centering adjustment. Turn the machine upside down, hold it firmly with one hand, start the motor and release the switch immediately after observing tracking of sanding belt. If abrasive belt runs outward, turn belt centering control knob(7) counter-clockwise and clockwise if belt runs inward.

  • Page 13: Maintenance

    sanding finish. Start your sander before sanding and turn off only after stopping sanding. For best results sand wood in the direction of the grain. Do not start sanding without the sanding belt fitted. Empty the dust bag every 5 minutes or sooner to ensure efficient dust collection. MAINTENANCE Remove the plug from the socket before carrying out any adjustment, servicing or maintenance.
  • Page 14 PLUG REPLACEMENT (ONLY FOR REWIRABLE PLUG OF UK & IRELAND) If you need to replace the fitted plug then follow the instructions below. IMPORTANT The wires in the mains lead are colored in accordance with the following code: BLUE – NEUTRAL BROWN –...

  • Page 15: Declaration Of Conformity

    PO Box 6242, Newbury, RG14 9LT, UK Declare that the product Electric Sanders and Polishers other than disk-type Description PBS900G (PBS-designation of machinery, representative of Belt Sander) Type Remove surface material with an endless abrasive belt Function Complies with the following Directives:...
