UPS OCTANS 10/20kVA 3:1
USER MANUAL
UNI EN ISO 9001-2015 n° 9115.BRMO
VIA LUDWING VAN BEETHOVEN N.24
20090 CINISELLO BALSAMO (MI)
Tel.: +39 0251672201
Fax: +39 0251672213
Mail:
sales@bragamoro.com
www.bragamoro.com
USER MANUAL
OCTANS PLUS 15/20kVA 3:1
File name
Date
Page
Code PUV9E010/15/20-AK
DF19010A
10/04/2019
1 di 28
MD03006C
All rights are reserved according to the law. Reproducing or distributing this document to third parties without permission is prohibited.
Advertisement
Table of Contents
Related Manuals for Braga Moro OCTANS PLUS 10k
Summary of Contents for Braga Moro OCTANS PLUS 10k
- Page 1 UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO VIA LUDWING VAN BEETHOVEN N.24 20090 CINISELLO BALSAMO (MI) Tel.: +39 0251672201 Fax: +39 0251672213 Mail: sales@bragamoro.com www.bragamoro.com USER MANUAL OCTANS PLUS 15/20kVA 3:1 File name Date Page Code PUV9E010/15/20-AK DF19010A 10/04/2019...
-
Page 2: Table Of Contents
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO INDEX DOCUMENT CHECK SECTION ....................... 3 Safety instructions ............................. 5 Prohibitions ..........................5 Safety tips ..............................5 Production Introduction ..........................6 Application ..........................6 1.2 Product range ........................6 1.3 System principle diagram .................... -
Page 3: Document Check Section
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO DOCUMENT CHECK SECTION Drawing Written by Role Date David Alessandri Technical Staff 10/04/2019 Control Controlled by Role Date David Alessandri Technical Staff 10/04/2019 Approved Approved by Role Date Adelio Abbondio Technical Staff 10/04/2019... - Page 4 UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO SAFETY AND RESPONSIBILITY THIS MANUAL IS PART OF THE RELEASED DEVICE. THE KNOWLEDGE OF THIS DOCUMENT IS COMPULSORY TO HANDLE OR USE THE UNIT. THE MANUAL COMPLIES WITH THE TECHNICAL REVISION OF THE UNIT AT THE DATE OF PRINTING.
-
Page 5: Safety Instructions
2.1 Prohibitions There is a risk of electric shock inside the UPS. DO NOT REMOVE the external panels of the appliance without first contacting the technical assistance of BRAGA MORO SpA. Contact the distributor before using the UPS to power on: ... -
Page 6: Production Introduction
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO Production Introduction 4.1 Application This series UPS, providing reliable AC power to various equipment, can be used for computer center, network management center, auto control system, telecom systems, etc. 4.2 Product range This series contains many capacities of UPS products. -
Page 7: Features
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO 4.4 Features This series is newly introduced. It is an intelligent online sine wave UPS. High frequency, double conversion, high input power factor, wide input voltage range, the output will not be disturbed by power network, suitable for area with poor power supply condition ... -
Page 8: Rear Panel Instruction
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO 4.5.2 Rear panel instruction 4.5.2.1 10/15/20k(H) Rear panel Fig.4-5 2a 10/15/20 k (H) Rear Instruction Intelligent slot EPO (External Power Off) Parallel port 1 Parallel port 2 Input & output breaker Maintenance bypass switch (covered) 9）... -
Page 9: Installation
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO Installation 5.1 Unpack checking Don’t lean the UPS when moving it out from the packaging. Check the appearance to see if the UPS is damaged during transportation, do not switch on the UPS if any damaged is found and please contact the dealer. -
Page 10: Installation
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO 5.2.2 Installation 5.2.2.1 External battery connection (for extended model only ) Make sure battery quantity complies with the specs（16 to 20 pieces of 12V battery in series）. Measure the voltage of battery bank after finishing connection. CAUTION! Don’t mix batteries with different capacity &... - Page 11 UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO B ATN BA T Positive(+) (8/9/ 10) Negative(-) (8/9/10) Fig.5-3b 10k/15k/20k(H) External battery connection 5.2.2.2 UPS input and output connection Minimum 8AWG or 10 mm copper wires for input/output & battery cables are required for the ups. ...
-
Page 12: Connection Of Parallel System
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO CAUTION！ Terminators are required so as to ensure the connections are firm Don’t reverse the input L and N Don’t connect the UPS input to a wall outlet or the outlet will get burnt. Connect the UPS output L, N, E to L, N, E of load via a PDU. -
Page 13: Operation
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO CAUTION！ Connect the A/B/C/N/L and E well Wire for requirement: For 10KVA UPS, select 10AWG or 6mm² I/O copper line. The total line length is N*6mm². For 15KVA UPS, select 8AWG or 10mm² I/O copper line. The total line length is N*10mm². For 20KVA UPS, select 6AWG or 16mm²... -
Page 14: Panel Display, Operation And Running
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO 6.2 Panel display, operation and running The operation is simple, operators only need to read the manual and follow the operation instructions listed in this manual, no need any special training. 6.2.1 Start up and turn off the UPS Start up operation... -
Page 15: Faceplate Display
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO 6.2.2 Faceplate display Faceplate display illumination O FF BYPASS F AULT RECT O UTPUT Fig.6.2.2° Overview of the operating panel of the UPS LCD Display Board Off button On button right or down Enter... - Page 16 UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO 2、LCD display content Running parameters Input voltage/frequency, output voltage/frequency/current, temperature inside, UPS, battery remaining capacity, battery charging/fully charged, battery voltage. Alarm information (priority from high to low ) It provides shutting down, auxiliary power fault, output short circuit, inverter fault, rectifier fault, over temperature, overload, charger fault, battery fault, battery capacity low, ready to shut down and output fault.
-
Page 17: Display Instruction
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO 3 Display instruction 1) The main interface below comes out when the power is connected or the system is cold start. see Fig1 10.0kVA Fig.1：Main interface 2) Press ESC/ ◀ or ▶ button, it will change to the basic status interface, see Fig2 below MODE: ONLINE Volt: AN BN CN Vin: 220 220 220... - Page 18 UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO Fig.6：Output info Fig.7：Output info FIGURE FIGURE FIGURE Invert P Battery N Battery 220.0V 50.0Hz 0.0A 0.0A 0min 0min Fig.8：Inverter info Fig.9：Battery info Fig.10 Battery info FIGURE FIGURE FIGURE Parallel Temperature℃...
- Page 19 UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO Fig.18：setting menu Fig.19：setting menu SETTING Parallel set P-amount P-Redund Fig.20：Parallel setting SETTING SETTING BatTest: Off BatTest: |10s Fig.21：Batter self-Test Off Fig.22：Batter self-Test ON ：to 10 seconds SETTING SETTING BatTest: |10m BatTest: |EOD Fig.23：Batter self-Test ON: to 10 minutes...
-
Page 20: Working Mode And Transferring
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO 6.3 Working Mode and transferring Usually, the UPS should be set to work in AC mode, so it will transfer to battery mode automatically without interruption when AC fails. When the UPS is overloaded, it will transfer to bypass mode without interruption. When the inverter is defective or over temperature occurred inside the UPS, the UPS will transfer to bypass mode if the bypass is normal. -
Page 21: Operational Status And Mode(S)
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO 6.5.1 Operational Status and Mode(s) Note： “X” shows that it will determined by other conditions. 6.5.2 Alarm Information Item UPS Alarm Warning Buzz Rectifier Fault Beep continuously Fault LED lit Inverter fault Beep continuously Fault LED lit... - Page 22 UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO Item UPS Alarm Warning Buzz Battery reverse Twice per second Fault LED lit Cable connection error Twice per second Fault LED lit CAN comm. Fault Twice per second Fault LED lit Parallel load sharing fault Twice per second...
-
Page 23: Specification
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO Specification Product Performance CAPACITY 10kVA/9kW、15kVA/13.5kW、20kVA/18kW PF:0.9 MODEL 10K(S/H)/15K(H)/20K(H) INPUT 3 phase 5 wires Input power factor ≥ 0.99 Rated voltage 220Vac/230/240Vac（self-adaption） Rated frequency 50Hz/60Hz（settable） Voltage range 208~478V Frequency range 45~55Hz（50 Hz）；55~65Hz（60 Hz）... -
Page 24: Mechanical Characteristics
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO ＞95%, cannot inverter-fed load capacity Load for a long time when rated output current under 125% Bypass load capacity is controlled by bypass circuit breaker, tripping when circuit breaker operating current. Crest factor 10K: ≥90% Efficiency at AC... -
Page 25: Maintenance
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO Maintenance Please follow 2.2.1 to install the UPS 8.1 Fan maintenance Continual working time of fan is 20000 to 40000 hours. It will be shorter as temperature raises. Please check the fan periodically, make sure there is wind blowing out from it. -
Page 26: Trouble Shooting
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO Trouble shooting When your UPS has the abnormal situation, please refer to the below table for checking and troubleshooting first. Please contact the distributor if problems cannot be solved by the trouble shooting below Problem description Probable causes Solution... -
Page 27: Appendix I Usb Communication Port Definition
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO 10 Appendix I USB communication port definition Definition of Male port: Pin 1 VCC, Pin 2 D- pin 3 D+, Pin 4 GND Application: use UPSilon2000 Power Management software Available functions of the USB ... -
Page 28: Appendix Ii Rs232 Communication Port Definition
UPS OCTANS 10/20kVA 3:1 USER MANUAL UNI EN ISO 9001-2015 n° 9115.BRMO 11 Appendix II RS232 communication port definition Definition of Male port: Connection between PC RS232 port and UPS RS232 port: PC RS232 port UPS RS232 port Pin 2 Pin 2 UPS send，PC receive Pin 3...
