Liko™ Ultra LiftPants™, Mod. 920
Sling
Instruction Guide
Lifting very heavy patients requires special techniques and
specially designed lift equipment. Liko has developed the
Ultra product series to help lift such patients in a safe and
comfortable manner.
The Liko Ultra LiftPants sling also give very heavy patients
the chance to practice standing and gait training without
risk of falling. They also reduce the risk of injuries to
caregivers.
The Liko Ultra LiftPants sling aid in safe standing and
gait training for patients with poor balance and poor leg
function. It is essential that the patient is able to bear
weight on their legs. The LiftPants allow the patient to
move while relieving him/her of a greater or lesser degree
of body weight.
The Liko Ultra LiftPants sling are equipped with two hip
straps on either side for more even weight distribution.
There are two different sizes.
In this document, the person being lifted is referred to as the patient and the person helping them is referred to as the
caregiver.
Symbol description
is a warning triangle used for situations which require extra care and attention.
reference to read instruction guide for detailed information
7EN160181 Rev. 6
ENGLISH
Product Description
Selecting a suitable lift
It is recommended that at least two caregivers be present
when transferring a patient.
The Liko Ultra LiftPants sling can be used along with Liko's
overhead or mobile lifts. An overhead lift can be used by the
patient for unrestricted movement within the lift's lifting
area. You can choose between:
- Liko's UltraTwin system with two lift units. The maximum
load is 500 kg (1100 lbs.), depending on which individual
products are included in the assembled lift system.
The UltraTwin system is available for both stationary
installation and for freestanding installation in the
UltraTwin FreeSpan™.
- LikoGuard
or LikoGuard
(800 lbs.).
- Viking
May be equipped with arm rest to give extra support
during standing- and gait training
L overhead lift for lifting up to 272 kg (600 lbs.)
XL overhead lift for lifting up to 363 kg
XL mobile lift for lifting up to 300 kg (660 lbs.).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra LiftPants 920 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Liko Ultra LiftPants 920

  • Page 1 Ultra product series to help lift such patients in a safe and when transferring a patient. comfortable manner. The Liko Ultra LiftPants sling can be used along with Liko’s The Liko Ultra LiftPants sling also give very heavy patients overhead or mobile lifts. An overhead lift can be used by the the chance to practice standing and gait training without patient for unrestricted movement within the lift’s lifting...
  • Page 2: Table Of Contents

    Adjustment of Loop Straps ......................8 Removing the LiftPants sling ......................8 Choosing the Right Size ........................9 Accessories ............................9 Overview, Liko Ultra LiftPants sling, Mod. 920 ................10 Recommended Combinations ......................10 Liko™ Ultra LiftPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com...
  • Page 3: Safety Instructions

    • Check that the lifting accessory hangs vertically and can move freely. • Although the Liko sling bars are equipped with latches, special caution must be exercised: before the patient is lifted from the underlying surface, but when the straps are fully extended, make sure the straps are correctly connected to the sling bar hooks.
  • Page 4: Care And Maintenance

    If the sling is used for bath or shower: After use in bath and shower situations, the sling should be placed so that it dries as soon as possible. Washing instructions: Please see the sling’s product label and the attached appendix ”Care and Maintenance of Liko Slings”. Expected Life Time The product has an expected life time of 1-3 years during normal use.
  • Page 5: How To Attach A Sling To Different Sling Bars

    How to Attach a Sling to Different Sling Bars Sling bar Sling loops to sling bar hooks Correct SlingGuard ™ Universal ™ SlingGuard Twin Universal Twin Cross-bar Wrong! Liko™ Ultra LiftPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com...
  • Page 6: How To Attach An Ultra Liftpants Sling To A Sling Bar With 4 Hooks (Twin Bars And Cross Bars)

    Alternative application of the Liko Ultra LiftPants sling: The patient can be lifted in a normal sling and then lowered onto the LiftPants sling placed on a chair or at the edge of the bed. The sling used can be e.g. the Liko UltraSling Mod. 06, Liko Original HighBack Sling Mod.
  • Page 7 During the lifting operation: Pull the lift forward in the direction of movement so that weight transfer takes place properly until the patient is upright and well-balanced. Liko™ Ultra LiftPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com...
  • Page 8: Adjustment Of Loop Straps

    LiftPants sling. Now fold the LiftPants straps. sling in under itself and pull it away. Liko™ Ultra LiftPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com...
  • Page 9: Choosing The Right Size

    Choosing the Right Size Choosing the right size is important for a safe and secure lift and for reaching the required lift height. Liko Ultra LiftPants sling should reach above waist height but not so high that the loop straps cut into the armpits. Refer to the measurement table below for guidance.
  • Page 10: Overview, Liko Ultra Liftpants Sling, Mod. 920

    Explanation: 1 = Recommended, 2 = May work, 3 = Not advised, 4 = Inappropriate Other Combinations Combinations of accessories/products other than those recommended by Liko can result in risks for the safety of the patient. www.hill-rom.com I www.liko.com Liko AB Nedre vägen 100...
