CURB Quick Start Install Manual

Hide thumbs Also See for Curb:

Advertisement

Quick Links

Download this manual See also: Installer and User Manual
Quick Start Install Guide
Draft d0.1 (2018.03)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Curb and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CURB Curb

Summary of Contents for CURB Curb

  • Page 1 Quick Start Install Guide Draft d0.1 (2018.03)

  • Page 2: Safety Precautions

    Electrical equipment should be installed, operated, serviced, and maintained only by qualified electrical personnel. If the equipment is used in a manner not specified by Curb, the protection provided by the equipment may be impaired. No responsibility is assumed by Curb for any consequences arising out of the use of this manual.
  • Page 3 UNBOXING Check package for contents: 1 - CURB power hub 1 - HomePlug adapter 1 - Cat-5 Ethernet cable 3 - Voltage wires (red, orange, white) 1 - Voltage wire connecting block 2 - CT clamp connecting blocks 2 - Large (100A) CT clamps...

  • Page 4: Hardware Setup

    # stickers. 3. Identify and record all circuit phases • Remove cover from panel. • Label breaker that will power the CURB hub. • Label all circuits with an A sticker that match phase with the HomePlug circuit.
  • Page 5 Connect white neutral wire from neutral rail • to white “N” port. • T-connect red power wire from red CURB breaker to red “A” port. • T-connect orange power wire from any orange “B” breaker to orange “B” • port.
  • Page 6 • Attach the remaining 50amp and 30amp CT clamps to the other large loads in the home and the corresponding phase blocks. • See Curb Priority Circuit Guide on choosing the correct circuits to measure • Fill out the Curb Hub Configuration Matrix: •...
  • Page 7 Need to measure both legs Electric Clothes Dryer Need to measure both legs Furnace Washing machine Cooktop/Range/Oven Need to measure both legs Dishwasher Fridge / Freezer Whole House Fan © 2018 Curb, Inc. Quick Start Install Guide d0.1 (2018.03) Page 7...

  • Page 8: Software Configuration

    SOFTWARE CONFIGURATION On your phone, tablet or laptop, go to: connect.energycurb.com http:// Enter the serial number found on the back of the device: © 2018 Curb, Inc. Quick Start Install Guide d0.1 (2018.03) Page 8...
  • Page 9 (Smith - #345632) or other established naming convention Fill in the customer address Check the Solar, Wind, Battery boxes based on the home setup Click “Next: Clamp” at bottom of screen © 2018 Curb, Inc. Quick Start Install Guide d0.1 (2018.03) Page 9...
  • Page 10 Block 3 (Phase A/B) Scroll down to input information for CT clamps in ports A-F Click “Next: Handoff” when ready to transfer to customer (or add another hub) © 2018 Curb, Inc. Quick Start Install Guide d0.1 (2018.03) Page 10...
  • Page 11 • Label the circuit (visible to customer) • Multiplier: • If you are only measuring 1 leg of a two-pole balanced load, you need to double the output by selecting “Double pole” © 2018 Curb, Inc. Quick Start Install Guide d0.1 (2018.03) Page 11...
  • Page 12 Note: “Toggle +/-” is only available on mains. Consumption and Production circuits automatically Click “Next: Handoff” when ready to display dynamically. transfer to customer (or add another hub) © 2018 Curb, Inc. Quick Start Install Guide d0.1 (2018.03) Page 12...
  • Page 13 SOFTWARE CONFIGURATION 3. Handoff to Customer Add another hub to this location Input customer email address & press “Finish” © 2018 Curb, Inc. Quick Start Install Guide d0.1 (2018.03) Page 13...
  • Page 14 SOFTWARE CONFIGURATION Example: CURB Lite 6 with Solar Mains: • 100 Amp CT on both A and B • phases Circuit type: Main • +/- Toggle “checked” to read • positive when no solar production Solar: • • 50 Amp CT...

  • Page 15: Check Your Work

    COMPLETION Check Your Work • Double-check each clamp for secure closure. • Double-check each wire for secure connection to the CURB. Tidy Up • Before closing panel, organize and tidy up wires on each side of the breaker panel. • Take a high-res photo of the open panel and email it to sales@energycurb.com with the serial number and customer name as the subject line.
  • Page 16 APPENDIX A Hub Configuration Worksheet © 2018 Curb, Inc. Quick Start Install Guide d0.1 (2018.03) Page 16...
