- Page 1 SRM100 Soil pH and Resistivity Meter User Guide SRM100 Soil pH and Resistivity Meter User Guide Proven compliance solutions. Relentless service.
- Page 2 Information in this document is subject to change without notice. © 1999 - 2019 American Innovations, Ltd. All rights reserved. American Innovations | www.aiworldwide.com | 12211 Technology Blvd | Austin, TX 78727 Reproduction in any manner whatsoever without the written permission of American Innovations is strictly forbidden.
-
Page 3: Table Of Contents
Displaying Readings During Measurements Start Up Message Idle State Message Resistivity State Message pH State Message Chapter 3: Maintenance & Battery Probe Sensor Battery Life Battery Replacement Appendix A: SRM100 Meter Specifications SRM100 Soil pH and Resistivity Meter User Guide... -
Page 4: Chapter 1: Getting Started
LCD display. Soil pH measurements are shown in standard pH units, while resistivity measurements are shown in ohm-cm. The SRM100 meter incorporates both the measurement of soil pH and soil resistivity from sensors in one convenient and rugged probe. -
Page 5: Controls And Display
SRM100 Soil pH and Resistivity Meter User Guide Controls and Display The SRM100 Soil pH and Resistivity meter has a two-line LCD display, three control buttons, a battery compartment, and a probe connector. Figure 1-1. Meter Features Display – all readings are shown on a two-line liquid crystal display (LCD). Each line consists of 16 characters. -
Page 6: Probes
SRM100 Soil pH and Resistivity Meter User Guide Probes The SRM100 Soil pH and Resistivity meter can be used with either a bell hole probe or a subsurface probe. Each probe includes a measurement sensor that reads pH and resistivity when in contact with the soil, as well as a cable to connect it to the meter. - Page 7 SRM100 Soil pH and Resistivity Meter User Guide Address: American Innovations, Ltd. Attn: AI Technical Support 12211 Technology Blvd. Austin, TX 78727 Chapter 1: Getting Started...
-
Page 8: Chapter 2: Using The Srm100 Meter
Chapter 2: Using the SRM100 Meter The SRM100 Soil pH and Resistivity meter was designed for easy operation and use. Before getting started with taking measurements, review the following best practices for using the meter and probes. Keep the SRM100 meter clean of any soils, corrosion, or scale. The soil probe sensor should be wiped clean with an oil-free cloth to remove any soil attached to the sensor. -
Page 9: Displaying Readings During Measurements
Displaying Readings During Measurements After the SRM100 meter has been powered on, the display will show the various states that the meter goes through during use. The SRM100 meter's states include start up, idle, resistivity, and pH. -
Page 10: Resistivity State Message
RDY FOR PH MEAS pH State Message In a pH state, the SRM100 meter is attempting to measure and stabilize the pH reading. If the pH reading finishes first, the top line will be blank, since no resistivity measurement has been taken. -
Page 11: Chapter 3: Maintenance & Battery
Chapter 3: Maintenance & Battery The SRM100 Soil pH and Resistivity meter requires very little maintenance. The probe sensor should always be cleared of any accumulated soils, rust, or corrosion prior to measurements. The probe cable and connector should be visually checked for cracks, frays, or other problems. -
Page 12: Battery Replacement
Replace the batteries, being careful to observe the correct polarity. 3. Replace the battery door when done. NOTE: If the SRM100 meter is to be stored for an extended period of time, the batteries should be removed to prevent acidic corrosion problems. Chapter 3: Maintenance & Battery... -
Page 13: Appendix A: Srm100 Meter Specifications
Appendix A: SRM100 Meter Specifications Specifications for the SRM100 Soil pH and Resistivity meter and each of the meter's accessories are listed below. SRM100 Dimensions: 7.5" long, 4.75" high, 2.25" deep Weight: 2.5 lbs without probe(s) Material: ABS high-impact plastic, corrosion proof, sealed to NEMA4 /IP64 ... - Page 14 SRM100 Soil pH and Resistivity Meter User Guide ¡ Shaft: Carbon steel ¡ Sensor Tip: Steel/copper/antimony Subsurface Probe: Type: T-Handle — Size: 40 inches — Weight: 5 lb. without SRM100 meter — Diameter: 5/8" shaft, 3/4" sensor tip —...
