Micromax Instruments SRM100 Quick Reference Manual

Soil ph and resistivity meter
Hide thumbs Also See for SRM100:
1
2

Advertisement

Table of Contents

MicroMax GPS350
Installation and Configuration

Quick Start

Refer to the SMR100 Soil pH and Resistivity Meter
User Guide (part number 122221-000) for complete
instructions.
A typical measurement session may include the following steps:
1
Remove the meter and probes from the carrying case.
2
Select measurement probe; connect probe to the meter.
3
Turn the SRM100 on by pressing and holding the POWER button for 5 seconds. The SRM100
will perform an auto-check and then display SRM RDY, select RES or pH Mode when ready
to take measurements.
4
Push probe into the soil to the depth of the desired measurement (the measurement sensors
are located at the tip of the probe).
5
Press the OHM-CM measurement button for the resistivity measurement. The soil resistivity
displays in about 20 seconds. Record measurement.
6
Press the pH measurement button for pH measurement (do not move probe). The soil pH
measurement displays in about one minute. Record measurement.
7
Remove the probe, and wipe the sensor array clean. See reverse side of this guide for
maintenance guidelines.
© 2017 American Innovations, Ltd.
SRM100 Soil pH and Resistivit y Meter
Quick Reference Guide
1 of 2
OHM-
pH
POWER
CM
SRM100
Soil pH and Resistivity Meter
Part No. 122220-000, Rev. 0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRM100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Micromax Instruments SRM100

Summary of Contents for Micromax Instruments SRM100

  • Page 1: Quick Start

    Select measurement probe; connect probe to the meter. Turn the SRM100 on by pressing and holding the POWER button for 5 seconds. The SRM100 will perform an auto-check and then display SRM RDY, select RES or pH Mode when ready to take measurements.

  • Page 2: Probe Maintenance

    Probe Maintenance Bell Hole Probe Measurement Sensor (enlarged view) Measurement Sensor Subsurface Probe To ensure accurate and repeatable soil pH and soil resistivity measurements, ensure that the probe is properly maintained. Clean the probe sensor of any accumulated soils, corrosion, and scale build-up. Wipe the sensor array with a clean cloth to remove any accumulated and/or attached soils from ...
