Summary of Contents for Lutron Electronics RadioRA Chronos RA-SBT-CHR
- Page 1 RA-SBT-CHR, RB-SBT-CHR Timeclock Programming Guide For a RadioRA Chronos System Bridge and ® Timeclock A Step-by-Step Guide for Programming Timeclock Functions of the Lutron RadioRA Chronos System Bridge and Timeclock...
-
Page 2: Table Of Contents
Table of Contents Time Clock Programming Astronomical Time Clock Programming Setting the Chronos Date Time ................3 Creating Time Clock Scenes ................5 Testing Time Clock Scenes .................. 9 Erasing Time Clock Scenes.................. 9 Creating Time Clock Events ................10 Viewing and Modifying Time Clock Events ............12 Deleting a Time Clock Event ................12 Setting the Time Clock Home / Away Mode ............13 Setup Guide for the RadioRA... -
Page 3: Astronomical Time Clock Programming
Astronomical Time Clock Programming Setting the Chronos Date and Time Step 4 Step 1 Go to Location Go to Time / Date Settings From Time / Date Settings, select Location. Main Menu Time Clock Setup Step 5 Time / Date Settings Choose Set Location Method The location can be set by State and City or by Step 2... - Page 4 Astronomical Time Clock Programming Step 6a Step 7 Set Location by State and City Set Time Zone to select correct Time Zone. Press to highlight the correct state. Press button) to accept the selection. “Next” ( button) to accept the selection. “Next”...
-
Page 5: Creating Time Clock Scenes
Astronomical Time Clock Programming Creating Time Clock Scenes Up to 13 scenes can be programmed for activation by the Astronomical Time Clock. Step 1 Step 3 Go to Manage Scenes Assign Zones Main Menu From Manage Scenes, select Assign Zones. The list Time Clock Setup of Time Clock scenes is displayed: Manage Scenes... - Page 6 Astronomical Time Clock Programming Step 4 Step 5 Assign Zones Complete Zone Assignment Assign Dimmers or Switches to the selected button) to display the list of Press “Continue” ( Time Clock Scene by turning the Controls Time Clock scenes: ON. Assign all Dimmers and Switches to be affected by the Scene, including Dimmers and Assign Zones Switches which are to be turned OFF by the...
- Page 7 Astronomical Time Clock Programming Step 6 Step 7 Enter Level Set Mode Set light levels and GRAFIK Scenes ® From Manage Scenes, select Set Zone Levels. The Use the dimming rocker to adjust the light list of Time Clock Scenes is displayed: level of any Dimmer(s) assigned to the Time Select Scene to Set Levels Clock Scene OR use the toggle button to turn...
- Page 8 Astronomical Time Clock Programming Step 8 Complete Setting Levels button) to display the list of Press “Continue” ( Time Clock scenes: Set Zone Levels 1. Morning 2. Scene 2 3. Scene 3 4. Scene 4 Exit Select Note: The system is still in Level Set Mode, as indi- cated by the icon in the upper right hand corner of the screen.
-
Page 9: Testing Time Clock Scenes
Astronomical Time Clock Programming Testing Time Clock Scenes Erasing Time Clock Scenes Testing Time Clock Scenes: Erasing Time Clock Scenes: Step 1 Step 1 Go to Test Scenes Go to Erase a Scene Main Menu Main Menu Time Clock Setup Time Clock Setup Manage Scenes Manage Scenes... -
Page 10: Creating Time Clock Events
Astronomical Time Clock Programming Creating Time Clock Events Up to 100 Time Clock Events may be programmed to each activate one of 13 programmed Time Clock Scenes. For details on programming Time Clock Scenes, refer to pages 5 through 8. Step 1 Step 3b Go to Add Event... - Page 11 Astronomical Time Clock Programming Step 5 Select Scene to Activate If the system contains Dimmers that were manufactured prior to January 1, 2001, the Legacy setting MUST be used. Select Scene to Activate 1. Morning Switches determines whether any switches in the 2.
-
Page 12: Viewing And Modifying Time Clock Events
Astronomical Time Clock Programming Viewing and Modifying Time Clock Events Deleting a Time Clock Event Viewing/Modifying Time Clock Events: Deleting a Time Clock Event: Step 1 Note: Deleting a Time Clock Event will only delete Go to View / Modify Event the event. -
Page 13: Setting The Time Clock Home / Away Mode
Astronomical Time Clock Programming Setting the Time Clock Home / Away Mode The time clock built into Chronos has two modes – Home and Away. These allow the timeclock to run certain ® events only while the homeowner is out, so that it appears someone is in the house. Convenience events, such as a morning scene, can be set to only run while someone is there. - Page 14 (800) 523-9466 (U.S.A., Canada, after purchase. For warranty service, return unit to TOLL FREE: place of purchase or mail to Lutron Electronics Co., and the Caribbean) Inc. at 7200 Suter Rd., Coopersburg, PA 18036-1299, Tel: (610) 282-3800 postage pre-paid.
