- Page 1 Air Pump Foam Brush System - Demand DUFB_A-D Owner’s Manual #0838 122915 Customer Number: Serial Number: Model Number: Installation Date:...
-
Page 2: Table Of Contents
When unpacking, check to make sure all the parts shown on the Parts Breakdown near the end of this manual are included. If any parts are missing or broken, please call Dultmeier Sales as soon as possible. Consumers should notice that this manual may differ slightly from the actual product as more improvements are made to our products. -
Page 3: Safety Information | 1
Safety Information | 1 To avoid serious or fatal personal injury or major property damage, read and follow all safety and operation instructions in the manual. This is a Safety Alert Symbol - When you see this symbol in the manual, look for the following signal words & be alert to the potential for personal injury or property damage. -
Page 4: Specifications | 2
Specifications | 2 DUFB_A-D Specifications Model(s) ................DUFB_A-D Style ................Air Driven Diaphragm Pump Pump ................FJ5100-040 Capacity ................2.5 GPM Max. Pressure ..............80 PSI Dimensions ..............Approx. 12” x 28” Shipping Weight ............... Approx. 40 lbs. System Features... -
Page 5: Installation & Operating Instructions | 3
Installation & Operating Instructions | 3 Equipment Placement 1. Select a mounting location on a wall at a height where the unit can be easily serviced. Hold the board level and mark spots on the wall for each mounting hole on the board. 2. - Page 6 Installation & Operating Instructions | 4 Plumbing 1. Run a 3/4” soft water city pressure line to female garden hose connector on the Hydrominder. (Fig. 5-A) IMPORTANT Do not turn on the water at this time. It is recommended that soft IMPORTANT water supply is used if available.
- Page 7 Installation & Operating Instructions | 5 Chemical Set Up 1. Select proper mix tip (provided) for soap and set aside for future installation. Eductor Chemical Inlet Port Consult Hydrominder instructions and chemical Suction product label for further dilution information. Tube 2.
-
Page 8: Installation & Operating Instructions
Installation & Operating Instructions | 6 Testing & Operation 1. With the chemical tank 2/3 full, turn on the air compressor. Make certain that your compressor IMPORTANT comes up to final pressure. 2. The Foam Brush System is factory tested and set. -
Page 9: Parts Breakdown | 7
Parts Breakdown | 7 Parts Breakdown: DUFB_A-D Item Part Number Description ..FJ5100-040 ..... Air Driven Diaphragm Pump ..AH1DP100 ....100# Dry Gauge ..GC9_-000-21M .._-Bank Brass Manifold w/ Metering Screws¹ ..PA14R113FC ... 1/4” Mini Air Regualtor .. - Page 10 Parts Breakdown | 8 Parts Breakdown: DUFB_A-D Item Part Number Description ..DD27234 ....Stainless Steel Wall Boom with Bracket ..DU4B-7 ....Low Pressure Boom Hose, 3/8” x 10’ ..DDA8401 ....Wall Boom Bumper, Grey ..TE20145 ....
-
Page 11: Warranty Information | 9
Warranty Information | 9 Notice Regarding Manufacturer’s Limited Warranty Dultmeier Sales Limited Liability Company (hereinafter Dultmeier), notifies you that component part(s) carry a manufacturer’s limited warranty provided by the manufacturer of said component part(s). These warranties do not pertain to normal wear of component part(s) that may occur within any specified period. -
Page 12: Checklist | 10
Accessories Included Shipping Container Arrived In Good Shape Overall Condition If you have any questions or concerns about condition of this unit, please contact us before operating. Dultmeier Sales, LLC Omaha, NE 1.800.228.9666 • Davenport, IA 1.800.553.6975 http://www.dultmeier.com • dultmeier@dultmeier.com...
