• Read Image and target Properties and Status
The GUI application provides the following Advanced features for all Cyclones:
• Add/Remove/Update many images in the Cyclone
• Remote Display Access and the ability to "touch" the screen
These features require an Advanced license only when using the SDK or Console (see below).
The SDK and Console application provide the following Advanced features for all Cyclone FX units
and any Cyclone upgraded with a resident Cyclone Control Advanced Automation License:
• Add/Remove/Update many images in the Cyclone
• Simultaneously (Gang) Control multiple Cyclones via the USB, Serial, or Ethernet
connections
• Program (and Read) Dynamic Data in addition to fixed image data
• Remote Display Access
8.1.3

PEmicro Compatible Hardware

The following lists the PEmicro hardware that is compatible with the Cyclone Control Suite. To
ensure proper operations, PEmicro recommends upgrading all Cyclone units to the latest
firmware.
• Cyclone FX Universa
• Cyclone LC Universal
• Cyclone FX ARM
• Cyclone LC ARM
• Cyclone PRO (Standard features only)
• Cyclone MAX (Standard features only)
• Cyclone for ARM (Standard features only)
• Cyclone for Renesas (Standard features only)
• Cyclone for STMicro (Standard features only)
8.2

Cyclone Control SDK

The Cyclone Control SDK allows the user to interact with the Cyclone via a .DLL.
8.2.1

Introduction

The Cyclone Control SDK is one of the three components that comprise the Cyclone Control Suite.
Its dynamic link library (.DLL) allows you to create an application on the PC that can directly control
one or more PEmicro Cyclone units. These interface routines are designed to be compiled into
visual and non visual applications running on Windows operating systems
The actual interface routines are located in the "CycloneControlSDK.dll" 32 bit DLL file. The DLL
is callable from almost any 32-bit / 64-bit Windows development environment. Since the way the
DLL is called varies depending on the compiler used, you are provided with the DLL interface code
and sample applications for each of the following compilers. Compilers in bold link to a PEmicro
blog post about using that environment with the SDK:
Borland Delphi 2.0+ (Pascal)
GCC
Microsoft Visual C
Microsoft Visual C#
NI LabVIEW 2018
