Seating Matters Bariatric Sorrento Operation Manual & Product Specification

Hide thumbs Also See for Bariatric Sorrento:

Advertisement

Quick Links

Download this manual See also: Operating Manual
BARIATRIC
SORRENTO
™
Operation Manual &
Product Specification

Advertisement

loading
Need help?

Need help?

Do you have a question about the Bariatric Sorrento and is the answer not in the manual?

Questions and answers

Related Manuals for Seating Matters Bariatric Sorrento

Summary of Contents for Seating Matters Bariatric Sorrento

  • Page 1 BARIATRIC SORRENTO ™ Operation Manual & Product Specification...
  • Page 2 WANT TO GO STRAIGHT? Ensure to engage directional lock castor at front left of chair June 2019...

  • Page 3: Table Of Contents

    CONTENTS Safety Instructions Technical Specification User Guide and Operating Instructions Drive Assist™ Working Environment Seating Matters Recycling Policy Intellectual Property Maintenance and Servicing BARIATRIC SORRENTO™ Instruction Manual...

  • Page 4: Safety Instructions

    2. The User must ensure that the product is in good condition before use (check all nuts and bolts are fastened, fabric in good condition etc). If there are any problems, these must be reported to your Seating Matters provider and corrected before the chair is put into use.
  • Page 5 9. Ensure there is more than one competent person there when making adjustments to ensure they are correct and safe for the Patient. 10. If in doubt as to any the adjustments, feel free to contact Seating Matters direct at technical@seatingmatters.com.

  • Page 6: Technical Specification

    BARIATRIC SORRENTO Basic dimensions TECHNICAL SPECIFICATION Overall height 1300mm/51in Back height 750mm/30in Seat height 600mm/24in Overall Length 1300mm/51in Seat to footplate height adjustments High 310mm/12in from seat 520mm/20.5in from seat Available seat and overall widths G (Seat width) H (Overall width)

  • Page 7: User Guide And Operating Instructions

    This includes lateral supports, arm adjustments, seat adjustment and foot plate. Please call your Seating Matters provider if you have any questions on these points. This product should not be lifted at any time unless by competent persons trained in such manual handling.
  • Page 8 Tilt in Space Wing Knob for Laterals adjustment Seat Belt Loops (fig.2) • Back angle adjustment: To recline the back of the chair exercise care in case of injury to the Patient or damage to the surrounding environment. Adjustments are performed according to the buttons on the handset (see page 11).
  • Page 9 (fig.3 & fig.3b). Adjust the seat to the required depth by carefully pulling the seat out. Tighten the screws again to ensure the seat depth does not unintentionally change (fig.3b). Seat belt loop Arm removal (fig.3a) BARIATRIC SORRENTO™ Instruction Manual...
  • Page 10 • Arm removal: To remove the arms, Arm removal loosen the thumb screws behind and in front of the arm (fig.3a,b & d) and carefully pull the arm out, leaving it in a safe place to avoid tripping hazards or other injuries.
  • Page 11 Ensure that only the weight of the Foot Plate height adjustment (fig.4a) Patient's legs are placed on this leg rest. BARIATRIC SORRENTO™ Instruction Manual...
  • Page 12 • Foot plate height: The foot plate can be adjusted in height by pulling out the spring plungers and sliding it up and down on the glide rail (fig.4a). When the spring plungers are released, they will catch into the nearest hole immediately below the pins.
  • Page 13 • Seat cushion: The seat cushion on the BARIATRIC SORRENTO™ is a waterproof, pressure redistributing, medium foam cushion providing pressure management and comfort. The seat cushion will have non-slip material on one face and a zip closure on one side.
  • Page 14 • Charging your chair: Your chair will arrive fully charged, ready for use. Please charge your chair daily. Charger Assembly Guide Slide plug adapter into charger body as shown. Ensure the plug is clicked Your charger is ready to use. To charge your chair, plug the charger into a wall socket and plug the connector end of the charger into the charging socket on the side of the handset (fig.5).

  • Page 15: Drive Assist

    (2). 3. Place hands firmly on the handle (3) and use your right thumb to gently press the drive switch (4) forward or backwards depending on direction you wish for the chair to travel in. BARIATRIC SORRENTO™ Instruction Manual...
  • Page 16 HOW TO CHARGE Charging • When the battery light is green, this means three is at least 80% charge. • When the battery light is red this means there is only 20% charge left. How to Charge 1. Remove the control box connection (6) at the back of the chair on the bottom left. 2.
  • Page 17 Rechargeable Battery Charge Level Battery lights up Yellow is less than 80% Rechargeable Battery Charge Level Battery lights up Red is less than 60% Rechargeable Battery Charge Level Intermittent Battery flashes Red is less than 50% BARIATRIC SORRENTO™ Instruction Manual...

  • Page 18: Working Environment

    Failure to do this may result in damage to the polyurethane coating, react with the chair frame, or negate the biocompatibility results of the fabric. It is essential that articles be thoroughly dried after all cleaning procedures and before storage. BARIATRIC SORRENTO™ Instruction Manual...

  • Page 19: Seating Matters Recycling Policy

    • Contact your local authority or governmental agency for the regulations that apply in your area. • If you wish to have Seating Matters recycle your product and your behalf, you are welcome to return the product to our company.

  • Page 20: Intellectual Property

    Parts can only be changed by service persons trained in Seating Matters products and use only Seating Matters parts. We recommend that your chair is serviced every year by a Seating Matters approved provider for any running repairs and maintenance.
  • Page 21 Check that all nuts and bolts are present. Check that all nuts and bolts are secure. Note: If nuts or bolts need attention, contact your Seating Matters approved provider IMMEDIATELY DO NOT USE the chair until it has been serviced.
  • Page 23 WE ARE HERE TO HELP For any questions or queries regarding your Seating Matters chair please contact: contact@seatingmatters.com...
  • Page 24 VIEW OUR FULL RANGE OF CHAIRS & ACCESSORIES ONLINE WWW.SEATINGMATTERS.COM...
  • Page 26 Australia Canada N.Ireland & ROI 2/6 St James Place 269 Maplegrove Rd 131 Carnamuff Road Seven Hills, Colborne Limavady NSW 2147 ON, Canada Northern Ireland Australia K0K 1S0 BT49 9JG Tel: +61 1300 001 050 Tel: +1 (905) 507 9007 Tel: +44 (0) 28 777 666 24 australia@seatingmatters.com...
