- Page 1 CP-5OO warewash dispenser...
- Page 2 (This page was intentionally left blank.)
-
Page 3: Table Of Contents
index 1.OO overview page 1.01 Package Contents 1.02 Operation 1.03 General Specifications 1.04 Model Numbers and Features 2.OO installation 2.01 Site Survey & Installation Requirements 2.02 Wall Mount 2.03 Mechanical Installation 2.04 Electrical Installation and Programming 3.OO operation 3.01 Description of Controls 4.OO service parts 5.OO... -
Page 4: Package Contents
(depending on the model). The unit has the reliability and accuracy you expect from Hydro Systems Co. at an economic price point. NOTE! The CP-500 is intended for use in industrial applications. It is not suitable for domestic use, and it must not be used outside of its intended use. -
Page 5: Model Numbers And Features
1.OO overview (continued) 1.O4 Model Numbers and Features Pump Build Options: Pump Type: D = Detergent Pressure: 1 = 1 bar (14.5 psi) R = Rinse 3 = 3 bar (43.5 psi) Adjustment: 1T = Time Tube Material: SA = Santoprene Combo 1TT = Time Time SI = Silicon... -
Page 6: Oo Installation
2.OO installation 2.O1 Site Survey & Installation Requirements WARNING! This product is intended to be installed by experienced installers, in accordance with all applicable electrical and plumbing codes. • Unit must not be installed near areas that suffer excess temperature changes, direct sunlight, frost or moisture of any kind. -
Page 7: Mechanical Installation
2.OO installation (continued) 2.O3 Mechanical Installation Chemical Installing the Rinse Injection Fitting Pickup Tubing 1) Install the rinse injection fitting to conform to local plumbing codes. 2) The injection fitting is designed to fit global needs. It should thread Compression directly into a 1/8”... -
Page 8: Electrical Installation And Programming
2.OO installation (continued) 2.O3 Mechanical Installation (continued) Installing the Rinse and Detergent Supply and Discharge Tubes 1) Install the included PVC pump supply tube (4mm ID, 6mm OD) into the chemical container using the foot filter with screen and weight to position the tube at the bottom of the container. 2) Route the other end of the included PVC pump supply tubes from supply containers to the inlet sides (left) of each respective pump. - Page 9 Fixed orange means the pump is in Priming Mode. Flashing You should not see the LED flashing orange, unless you are in Custom Programming Mode. (If you do see the LED flashing orange, please contact Technical Support at Hydro Systems Co.) Fixed Fixed red indicates the signal is active, but the pump switch is on the standby/OFF position.
- Page 10 Fixed You should not see the LED display as fixed orange. (If you do see the LED fixed orange, please contact Technical Support at Hydro Systems Co.) Flashing Flashing orange quickly (1 second on, 1 second off) is an Alarm, indicating the pump motor is jammed or that the unit is turned off.
- Page 11 Fixed orange means the pump is in Priming Mode. Flashing You should not see the LED flashing orange, unless you are in Custom Programming Mode (If you do See the LED flashing orange, please contact Technical Support at Hydro Systems Co.) Fixed Fixed red indicates the signal is active, but the pump switch is to the standby/OFF position.
- Page 12 Fixed You should not see the LED display as fixed green. (If you do see the LED display as fixed green, please contact Technical Support at Hydro Systems Co.) Flashing Flashing green indicates the pump is dosing the, and the frequency of the flashing is proportional to the user-defined pump speed.
-
Page 13: Oo Operation
3.OO operation 3.O1 Description of Controls Overview The CP-500 makes use of 1 or 2 potentiometers for setting run times and/ or speed, a power/prime switch, and a multi-color LED for indicating the dispenser status. The power/prime switch and LED status indications are described below. -
Page 14: Oo Maintenance
5.OO maintenance 5.O1 Maintenance (Required} The CP-500 is designed to require minimal setup and ongoing maintenance. The routine maintenance tasks include: • Check the pump tube’s condition and replace as needed to maintain delivery performance • Clean the unit cabinet with a damp cloth •... -
Page 15: Oo Troubleshooting
6.OO troubleshooting 6.O1 Troubleshooting Table Problem Cause Solution • Check wiring from dish machine. 1. Dead unit - No LEDs illuminated a. No incoming main electrical power • Check for power at dish machine connection. b. Bad PC board • If board has failed, replace the CP-500 unit. •... -
Page 16: Oo Warranty
Hydro Systems Phone 513.271.88OO...
