Moore 500 Series Hardware Installation And Modification Manual

Process controller model 2

Advertisement

Installation
500 SERIES
Form M500 V7
Process Controllers
5 0 0
Hardware Installation
and Modification
Manual
for Electronic Products
Series 531, 532,
535, 545, 555
Model 2
1
Installation Guide
500 Series
M500 V 7, APRIL 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 500 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Moore 500 Series

  • Page 1 Installation 500 SERIES Form M500 V7 Process Controllers 5 0 0 Hardware Installation and Modification Manual for Electronic Products Series 531, 532, 535, 545, 555 Model 2 Installation Guide 500 Series M500 V 7, APRIL 2016...
  • Page 2: Installation

    (Digital Inputs, Slidewire Feedback, 093-128* ....Lithium Battery and RSP) * Universal Kit (can be used with all 500 Series Controllers) HOW TO USE THIS MANUAL: A. CAUTION: Static discharge will cause damage to equipment. Always ground yourself with a wrist grounding strap when handling electronics to prevent static discharge.
  • Page 3 Board, Option Board and Power Supply Board. a Phillips screwdriver. Remove the four screws. To Add or Change Output Modules The 500 Series units have provisions for four output modules. The units come factory configured with specified modules installed in appropriate locations.
  • Page 4 Output 4 Male 12-Pin Male 22-Pin Connector Connector Figure 2 Microntroller Board, 12-Pin Female 22-Pin Female Option Board, and Connector Connector Power Supply Board 5-Pin Connector Module Retention Plate over Outputs 1,2,3 Jumpers NO and NC 500 Series Installation Guide...
  • Page 5 20. To maintain NEMA 4X Rating, you may need new grounding strap when handling electronics mounting gaskets, order part #535-662. Refer to to prevent static discharge. your user’s manual. CAUTION Do not scratch the boards or bend the pins of the connectors. Installation Guide 500 Series...
  • Page 6: Return Procedures

    4. Ship the equipment to the Moore Industries location nearest you. The returned equipment will be inspected and tested at the factory. A Moore Industries representative will contact the person designated on your documentation if more information is needed. The repaired equipment, or its replacement, will be returned to you in accordance with the shipping instructions furnished in your documentation.
  • Page 7 Micro Controller Board that has a replaceable Lithium Battery slot. To replace battery in your 500 Series unit follow previous instructions found in M500 V6. Use a fl at head screwdriver to release battery and replace.
