- Page 1 Instruction manual the team to trust SmartDate X60 Colour User Interface Safety instructions Printer overview User Interface overview Start / Stop the printer Select a job Menu structure Printhead maintenance Consumables for parts & service call QLC (800) 837-1309 Troubleshooting...
-
Page 2: Safety Instructions
Safety instructions EC DECLARATION OF CONFORMITY DECLARATION DE CONFORMITE CE Markem-Imaje Ltd. Markem-Imaje Ltd. Nottingham Science Park Nottingham Science Park University Boulevard University Boulevard Nottingham NG72QN United Kingdom Nottingham NG72QN United Kingdom certifie que l’équipement neuf, ensures that the new equipment désigné... - Page 3 Safety instructions Before using this printer, please read and fully comply with these instructions, the material safety data sheet (MSDS) for consumables used, and safety labels affixed to the printer. Servicing must be performed only by qualified people who are appropriately trained.
- Page 4 Safety instructions Because Markem-Imaje equipment is tested with Markem-Imaje consumables and spare parts for conformity with certain regulations and safety standards, use of non-Markem-Imaje consumables and spare parts also may be inconsistent with testing conditions and affect compliance of the equipment with certain standards. The user shall bear all risks associated with use of unsuitable consumables and spare parts.
-
Page 5: Installation Requirements
Safety instructions ■ Health / Hygiene / Environment Solvent-resistant gloves and safety goggles are recommended during cleaning operations. Please read the Isopropanol Safety Data Information prior to using Isopropanol with any Markem-Imaje product. Noise levels: Test Standard BS EN ISO 3746:1996 SmartDate X60 Intermittent Mode 199 ppm with a 10 mm Image (700 mm/s) <70 dB (A) SmartDate X60 Continuous Mode 299 ppm with a 10 mm Image... - Page 6 Safety instructions ■ Installation First time Installations will normally be carried out by qualified Markem.Imaje service technicians. For experienced customers who have existing SmartDate units and wish to carry out installation themselves, please first check with Markem.Imaje to ensure that this is advisable. ■...
- Page 7 Safety instructions Batteries There is a non-replaceable lithium battery mounted on the control board assembly. Under no circumstances should this be replaced (it should last for several years). In the event of failure, please return the whole control board assembly to Markem-Imaje for repair.
- Page 8 SmartDate X60 Combined Printer User Interface Printer Ribbon Cassette Printhead Module Ribbon Webbing Diagrams for parts & service call QLC (800) 837-1309 Instruction manual...
- Page 9 SmartDate X60 Shuttle Printer User Interface Printer Ribbon Cassette Printhead Module Ribbon Webbing Diagrams for parts & service call QLC (800) 837-1309 Instruction manual...
-
Page 10: Interface Overview
Interface overview Button Function Stop producing Registration Select job Start producing for parts & service call QLC (800) 837-1309 Instruction manual... -
Page 11: Description Of Icons
Description of icons Home This option will return you to the Home screen. Print preview This option allows you to preview the selected job. This indicates that there are no faults or warnings Folder OK active. Folder This indicates that there is one or more warnings warning active. -
Page 12: Start The Printer
Start the printer Ready Default job Producing Default job for parts & service call QLC (800) 837-1309 Instruction manual... -
Page 13: Stop The Printer
Stop the printer Producing Default job Ready Default job for parts & service call QLC (800) 837-1309 Instruction manual... - Page 14 Select a Job - Local Database Home Select job Job 1 Job 2 Job 3 Home Job 1 Field 1 [1/4] Field 1 for parts & service call QLC (800) 837-1309 Instruction manual...
- Page 15 Select a Job - Local Database ABCD Confirm Job Job 1 ABCD 12345 20/10/10 for parts & service call QLC (800) 837-1309 Instruction manual...
- Page 16 Select a Job - Remote Database Home Select Job from Host Please enter the Job name Job 1 for parts & service call QLC (800) 837-1309 Instruction manual...
- Page 17 Select a Job - Remote Database Home Job 1 Field 1 [1/4] Field 1 Confirm Job Job 1 ABCD 12345 20/10/10 for parts & service call QLC (800) 837-1309 Instruction manual...
-
Page 18: Menu Structure
Menu structure Settings Diagnostics Statistics Files Service Status Version Menus Information Home Select job screen Counts Information Supplies Print adjust Health Printhead Information Job History Darkness Offset Registration Test print Rotation for parts & service call QLC (800) 837-1309 Instruction manual... - Page 19 Menu structure Settings Machine settings Diagnostics Display settings Statistics Adjust RTC Files Language Service Enable security Version Custom Codes Information Flex IO map Diagnostics Manual control Digital I/O control Select printhead test pattern Speed profile graph Setup wizards Installation setup Copy files Service login Delete files...
-
Page 20: Print Head Maintenance
Printhead maintenance Print line (corner edge) for parts & service call QLC (800) 837-1309 Instruction manual... - Page 21 Printhead maintenance The printhead should be cleaned at regular intervals. These depend on machine use, operating environment, and choice of thermal ribbon. Turn off the power to the controller and remove the ribbon cassette. Allow the printhead to cool to normal room temperature before proceeding in order to prevent the possibility of thermal shock damage.
-
Page 22: Changing The Ribbon
Changing the Ribbon When removing the cassette, if the latch does not turn, please call an Engineer. Do not use force or tools. Use the plate below the waste ribbon to lift it off the ribbon rewind reel. If the ribbon is still difficult to remove, please call an Engineer. - Page 23 Ribbon Web Paths ■ Webbing Diagrams SmartDate X60 Combined Printer Left Hand Right Hand SmartDate X60 Shuttle Printer Left Hand Right Hand Ensure that the ink side of the ribbon is facing away from the printhead. Scratch the ribbon with a fingernail to test; the ink should scratch off.
-
Page 24: Control Messages
Control messages In the case of a Warning the SmartDate X60 will continue printing if in Producing mode. The Warning does not stop the print cycle. An example of a Warning might be “Low Ribbon” Warning 2109 Low Ribbon A new ribbon will be required soon Fault 1300 Cassette open... -
Page 25: Troubleshooting Information
Troubleshooting - Information LOW RIBBON The Ribbon has almost run out. CASSETTE OPEN Check cassette is firmly in place with latch closed. Ensure handle is in the CLOSED position. CASSETTE LOAD ERROR Ensure the shuttle or printhead is in the HOME position. CALIBRATION FAILED Check ribbon for breaks or slackness RIBBON BREAK DETECT... - Page 26 Notes for parts & service call QLC (800) 837-1309 Instruction manual...
