DS2/DS4 Hardware Manual
5.8.4

I/O Connection using Ribbon Cabling

This drawing shows the termination pinout from the AIM104-HBI board via a 10-way ribbon cable. See
section 5.8.5, HART Wiring Diagrams, for specific examples of HART circuits to external devices.
+24F Vref
1K
FGND
+
-
FGND
100
100K .
FGND
Vref
1K
FGND
+
-
FGND
100
100K .
FGND
1k
1k
AIM104-HBI Circuit
FGND
Pin
10
9
FGND
8
7
6
5
4
3
2
1
10-way Header
Function
+24F
n/c
IOUT 2
IOUT 1
FGND
CH2 -
CH2 +
CH1 -
CH1 +
FGND
Page 40
