9. Operation
9.1 Radio
1. Press the power button (16) to switch on the radio.
You can choose the source AM or FM by pressing on the MODE button.
2. Turn the volume adjustment knob (10) to adjust the volume. Turn
the tune adjustment knob (11) to set the frequency.
3. Press the SCAN/SET button to search for a station automatically.
The LCD screen (2) display will flash the scanning symbol until
it detects a station. To find another station, press the SCAN/SET
button again.
4. This radio can save up to 5 stations per frequency. Once the station
you require has been detected, press and hold one of the number
buttons 1 to 5 to save. Repeat on the next number button for
further stations.
5. Press the button 1/2/3/4/5 to listen to stations that you have saved.
6. If required, the FM frequency band can be set from 87.5 to 108
MHz, the AM frequency band can be set from 520 to 1710 kHz.
While radio is switched off and then in standby mode for 15
seconds, long pressing of the MODE button for more than 3
seconds will first show current FM frequency band.
Continue pressing MODE button for approx. another 5 seconds
until display FM and 50 kHz (frequency band) is flashing. By
rotating the TUNE control, you can adjust to 100 kHz.
After FM frequency band is reset, pressing MODE button again,
display will show AM and flash 9 kHz.
