Benedini TBS Mini V2 Operation Manual

High power exhaust smoker for Benedini Soundunits
Full speed operation
System of operation
This high power electronic smoke generator module is intended to be used in any land vehicle
or boat. It is designed to be combined with the Benedini TBS Mini V1 and V2 sound unit
(NOT TBS5!). It provides for exhaust smoke to be generated both proportionally and
synchronised to the speed of the vehicle and the engine sound emitted by the Sound Unit. The
smoke controller has galvanic isolation from the sound module and the receiver.
Oilbased smoke unit, Version II
Operation manual
(Smoke oil based, Version II)
(smoke oil and syringe are NOT scope of delivery!)
Features
- High power oil based smoke generator
- 40W heating power for excessive smoke
generation
- smoke volume and speed is adjusted according to the
model state
- controlled from external Benedini soundunit
(TBS Mini V1 and V2, NOT TBS5 → see last page)
- Metal box housing
- two box sizes available (see below)
- 12 or 24V version
- 1 or 2 smoke exits
Horizontally or vertically orientated.
- Delivered as a mechanical kit, including all
necessary components for self construction
