Page 1: Operating Instructions
BL.16 Operating Instructions 580 Mayer Street, Building #7, Bridgeville, PA 15017 ‡ phone 412.206.0106 ‡ fax 412.206.0146 www.brightlines.com 2018 Brightline, L.P... -
Page 2: Owner's Record
Model No.________________________ Serial No.________________________ Date of Purchase__________________ Product Description ‡ The Brightline BL.16 is a 42-watt, energy-efficient light fixture. This fixture combines high-frequency electronics with a state-of-the-art optical system to produce a soft, full-spectrum, flicker-free light source. -
Page 3: 3. Repeat Steps #1 And #2 For Remaining
Installing the Yoke 1. Assemble palm handle, yoke, and washers as shown (Fig. 1). 2. Screw palm handle into place (Fig. 2). Figure 1 3. Repeat Steps #1 and #2 for remaining palm handle. Figure 2 Adjusting the Yoke 1. While firmly grasping fixture, loosen palm handles (Fig. -
Page 4: Exploded Assembly
Exploded Assembly BL.16X1 - Baffle - Display D - Yoke Palm Handle Q - Power Bracket - Lens? F - Power Inlet Module with Fuse S - Reflector c t i Light Engine H - Male 5 Pin XLR Receptacle U - 6-32 Nut I - Female 5 Pin XLR Receptacle V - Nylon Spacer... - Page 5 Installing Adapters (C-Clamp/Spud) 1. Thread mounting screw through yoke and 2. Tightly fasten mounting screw in place (Fig. 7). into adapter (Fig. 6). C-Clamp 1/2” Lock Washer 1/2-13 UNC Hex Bolt Figure 6 Figure 7 Notes...
- Page 6 "twofers" is not appropriate. 2. You can use up to 32 Brightline DMX fixtures on a single DMX data line. If there are more than 32 units, the use of a DMX repeater amplifier or splitter amplifier is required. A repeater amplifier is an electronic device that boosts the DMX signal.
-
Page 7: Installing Accessories
Installing Accessories 1. Swing latch open (Fig.8). Latch Figure 8 2. Insert accessory into the track and slide it forward until it stops (Fig. 9). Figure 9 3. Swing latch closed and fasten in place (Fig. 10). Figure 10... -
Page 8: Disconnecting Cables
Installing DMX Control Cables 1. Turn power “OFF” on all devices. 4. To add additional fixtures, line up the locking key on the male plug end of the jumper cable (Figure 1) with the Note: If the fixture power is not turned “OFF” before female receptacle labeled “DMX THRU”... -
Page 9: Replacing Fuse
Replacing Fuse 1. Pull fuse holder out of power inlet module. 2. Remove fuse holder and check for wear (Fig. 11). If fuse is blown, replace with a new fuse or the on-board spare (Fig. 12). 3. Return fuse holder to a closed position. Active Fuse On-board Spare Figure 12... - Page 10 Reading the LED Display Channel Indicator Fixture Status Indicator DMX Signal Indicator Adjustment Buttons Figure 7 1. The channel indicator is used to determine the setting of the fixture in the following modes: a) Emergency On Mode: Fixture is manually operating at 100% b) Manual Dimming Mode: Fixture is manually dimmed at LED display without the use of a lighting control console.
-
Page 11: Troubleshooting Guide
Troubleshooting Guide LED’s are flashing or Wrong voltage for driver Verify that the driver's voltage is strobing. installed. correct. Identify location of buzz and replace Driver buzzes or hums. Defective driver. driver if necessary. Light fixture does not turn Defective or missing fuse. Install fuse into power entry module. -
Page 12: Setting The Dmx Address
Setting the DMX Address 1. Program DMX addresses by gently pressing in the adjustment buttons with a pointed object such as a pen (Figure 8). Channel Indicator Fixture Status Indicator DMX Signal Indicator Adjustment Buttons Figure 8 2. Use Channels 001 thru 512 to program the DMX addresses for the lighting control console. -
Page 13: Specifications
Specifications Mounting: 10-gauge (.125) extruded-aluminum Housing: 14-gauge (.060) formed, yoke, welded construction (standard). aluminum sheet-metal construction. 2” O.D. pipe clamp or TVMP adapter provided. See finish note. °K Power Entry Module: 8-amp fuse LED : 16 CREE XP.E 3200°K or 5600 (with on-board spare) and IEC connector 50,000-hour-rated lamp life. -
Page 14: Warranty
WARRANTY guarantees all its products to be free from defects in materials and Brightline workmanship for a period of three (3) years from the date of shipment. PROCEDURES If any product is found to be unsatisfactory under this warranty, the buyer must notify Brightline immediately. - Page 15 Notes...
