Operating Instructions
Radio Transmitter eco
AOEM1G30 [PMTS/DOKUS]
HBC-radiomatic GmbH • 74564 Crailsheim • Germany
Information and specifications subject to change without notice.
HBC
– Radio Control
R
a
d
i
o
T
R
a
d
i
o
T
r
a
n
s
m
i
t
t
e
r
a
n
s
m
i
t
t
e
Page 1 / 24
r
e
c
o
r
e
c
o
Radio Control System
2007-06-18
Advertisement
Table of Contents
Related Manuals for HBC eco
Summary of Contents for HBC eco
- Page 1 Operating Instructions Radio Transmitter eco AOEM1G30 [PMTS/DOKUS] Page 1 / 24 – Radio Control Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany Information and specifications subject to change without notice. 2007-06-18...
- Page 2 Tel. +49 ( 0 ) 79 51 – 3 93 – 0 Fax +49 ( 0 ) 79 51 – 3 93 – 50 E-mail: info@radiomatic.com http://www.hbc-radiomatic.com HBC radiomatic GmbH is not liable for any misprints or errors! – All rights reserved. ™ radiomatic and radiobus are registered German trademarks. ©...
-
Page 3: Table Of Contents
Dimensions ..................21 EC Declaration of the Manufacturer and of Conformity ....22 Appendix: – Frequency List for Europe – Return Delivery Note Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany Information and specifications subject to change without notice. 2007-06-18... -
Page 4: Safety Instructions
Pay attention to the comments and instructions given. Ignoring the information provided may permanently impair the reliability and operability of the equipment. Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany 2007-06-18 Information and specifications subject to change without notice. -
Page 5: General Safety Instructions
A defective transmitter may only be repaired by qualified and competent personnel. Use only original HBC spare parts. The device security cannot be guaranteed with the use of spare parts other than HBC originals, and this voids our extended warranty. Only the legal warranty regulations are then applicable. -
Page 6: Operator Safety Instructions
If the crane is equipped with a Main Contactor you must press the button before the crane can react again to control commands! Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany 2007-06-18 Information and specifications subject to change without notice. -
Page 7: Operation
Replace the battery when the display in the transmitter flashes red and an acoustic signal sounds. Otherwise, the transmitter will switch off in a few minutes. Recharge the empty battery in the respective charger. Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany Information and specifications subject to change without notice. 2007-06-18... -
Page 8: Automatic Switch-Off (Apo Function)
® The radiomatic AFS option also includes the manual frequency switching function for changing the frequency channel during radio operation. Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany 2007-06-18 Information and specifications subject to change without notice. -
Page 9: Battery And Battery Charger
Protect the battery from short circuits and always store it in the protective cover provided. Ø Charge the battery fully before storing it for a prolonged period. Otherwise total discharge may occur. Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany Information and specifications subject to change without notice. 2007-06-18... -
Page 10: Ac Battery Charger For Ba2250_0
AC Battery Charger for BA2250_0 The charger consists of the battery charger QA101600 with 4 interchangeable standard adapters and the battery compartment QC005A00. Ø Use this charger for HBC batteries type BA2250_0 only. Ø Use this charger with the included battery compartment only. Ø... -
Page 11: Dc Battery Charger For Ba2250_0
DC Battery Charger for BA2250_0 The charger consists of the battery charger QD112300 and the battery compartment QC005A00. Ø Use this charger for HBC batteries type BA2250_0 only. Ø Use this charger with the included battery compartment only. Ø The charger may not be used in hazardous areas. -
Page 12: Options
If the connection cable between the transmitter and the receiver is removed, the radio system switches off automatically. Press the button to switch back to radio operation. Illustration exemplarily Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany 2007-06-18 Information and specifications subject to change without notice. -
Page 13: Radiomatic Infrakey Option
The range of the infrared beam is max. approx. 20 meters (66 feet) and the angle of radiation is 34°. ® To activate radiomatic infrakey, press the button on the transmitter. Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany Information and specifications subject to change without notice. 2007-06-18... -
Page 14: Catch - Release Option
The starting condition described above can only be resumed by deactivating the operating voltage at the receiver. Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany 2007-06-18 Information and specifications subject to change without notice. -
Page 15: Catch - Release - Tandem Option
The starting condition described above can only be resumed by deactivating the operating voltage at the receiver. Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany Information and specifications subject to change without notice. 2007-06-18... -
Page 16: Tandem Operation Option
Switch the rotary switch of transmitter 1 to A + B. Unlock the STOP switch of transmitter 1 by turning, and press button The radio system now operates in tandem mode. Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany 2007-06-18 Information and specifications subject to change without notice. - Page 17 Switch the rotary switch of master transmitter to A + B. Unlock the STOP switch of master transmitter by turning, and press button The radio system now operates in tandem mode. Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany Information and specifications subject to change without notice. 2007-06-18...
-
Page 18: Fault Correction
− There is an interruption junctions are tight. in the connecting cable − Contact a service to the crane or machine. technician if necessary. Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany 2007-06-18 Information and specifications subject to change without notice. -
Page 19: Maintenance
HBC-radiomatic GmbH – Customer Services / Repair Service – Tel.: +49 ( 0 ) 79 51 – 3 93 – 800 Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany Information and specifications subject to change without notice. 2007-06-18... -
Page 20: Technical Data
6 V / 1500 mAh Operating time at 100% duty cycle ca. 20 hours W eight ca. 1,5 kg (3.3 lb.) Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany 2007-06-18 Information and specifications subject to change without notice. -
Page 21: Dimensions
Operating Instructions Radio Transmitter eco AOEM1G30 [PMTS/DOKUS] Page 21 / 24 Dimensions Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany Information and specifications subject to change without notice. 2007-06-18... -
Page 22: Ec Declaration Of The Manufacturer And Of Conformity
Operating Instructions Radio Transmitter eco Page 22 / 24 AOEM1G30 [PMTS/DOKUS] EC Declaration of the Manufacturer and of Conformity Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany 2007-06-18 Information and specifications subject to change without notice. - Page 23 Operating Instructions Radio Transmitter eco AOEM1G30 [PMTS/DOKUS] Page 23 / 24 Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany Information and specifications subject to change without notice. 2007-06-18...
- Page 24 Operating Instructions Radio Transmitter eco Page 24 / 24 AOEM1G30 [PMTS/DOKUS] Radio Control System HBC-radiomatic GmbH • 74564 Crailsheim • Germany 2007-06-18 Information and specifications subject to change without notice.
