Technical
Handbook
DCE80-100E
This Handbook deals with the design
and maintenance of Kalmar empty
container trucks, type DCE.
In addition, it gives details of
troubleshooting and the most common
corrective maintenance.
Operation and other matters that are
primarily of interest to the operator are
included in the Instruction Manual.
Kalmar Industries AB
We reserve the right to modify
our design and material speci-
fications without prior notice.
TDCE01.04GB
00
General
10
Chassis and cab
20
Electrical system
30
Engine
40
Transmission,
drive axle, brakes
50
60
Steered axle
70
Hydraulic system
80
Lifting mast, carriage
and side lift attachment
Periodic supervision
90
