Summary of Contents for Creative XP TRAIL CAM PRO 3
- Page 1 3G Scouting Trail Camera Instruction Manual TRAIL CAM PRO 3 CREATIVE XP Page 1 Creative XP 3G Scouting Trail Camera PRO3...
- Page 2 Google Play Store Get the APP for remote control of the 3G model Apple App Store Page 2 Creative XP 3G Scouting Trail Camera PRO3...
- Page 3 If your problem continues after trying the solutions in the Troubleshooting section, please e-mail us at support@creative-xp.com and we will take care of it as soon as possible. Page 3 Creative XP 3G Scouting Trail Camera PRO3...
-
Page 4: Table Of Contents
2.4 Function Keys & Other Details 3. Introduction 3.1 Functionality Introduction 3.2 Application 3.3 Power Supply 3.4 SD Card Selection 3.5 USB Connection 3.6 Things to Keep in mind & Warnings 3.7 Key Features Page 4 Creative XP 3G Scouting Trail Camera PRO3... - Page 5 6.1 Photos Do Not Capture Subject of Interest 6.2 Camera Stops Taking Images or Won’t Take Images 6.3 Night Vision Flash Range Doesn’t Meet Expectation 7. Warranty & Contact Warranty Contact Information Page 5 Creative XP 3G Scouting Trail Camera PRO3...
-
Page 6: Quick Start
Quick Start > What’s in the box 1.1 What’s in the box? 1* Trail camera 1* Instruction manual 1* Tree strap 1* Antenna 1* USB cable 1* SIM Card Adapter 1* TV cable 1* Camera Tree Mount Page 6 Creative XP 3G Scouting Trail Camera PRO3... -
Page 7: Quick Start
Step 1: Fix the antenna Step 2: Inserting the batteries Open the latches on camera two sides slightly Note: Please set battery type to the one (Alkaline or Ni-MH) you’re using for longer battery life. Page 7 Creative XP 3G Scouting Trail Camera PRO3... - Page 8 (negative or “flat” end against the long spring of each battery slot). For the second set of batteries, please open the battery case and insert as shown in the pictures below. Page 8 Creative XP 3G Scouting Trail Camera PRO3...
- Page 9 3G & MMS functions. We recommend testing the SIM card first on your mobile phone to make sure it’s activated. Make sure the SD Card is Unlocked before inserting Push the SIM Card in Page 9 Creative XP 3G Scouting Trail Camera PRO3...
- Page 10 In Motion Detection mode, the camera will take photos and video clips automatically and send photos to your cell phone or email upon each motion trigger (if you added the info in the “Send to” section). Page 10 Creative XP 3G Scouting Trail Camera PRO3...
-
Page 11: Camera Default Settings
Quick Start > Setup > Camera 1.3 Camera Default Settings (shown in Red) Page 11 Creative XP 3G Scouting Trail Camera PRO3... - Page 12 Views and Details | Front 2.1 Front View Page 12 Creative XP 3G Scouting Trail Camera PRO3...
- Page 13 Views and Details | Bottom & Back 2.2 Bottom View 2.3 Internal Back View Page 13 Creative XP 3G Scouting Trail Camera PRO3...
- Page 14 Views and Details > Function Keys 2.4 Function Keys & Other Details 1. Buttons [OK] Multi Function: Photo & Video Record / Setup Mode 2a. Switches Page 14 Creative XP 3G Scouting Trail Camera PRO3...
-
Page 15: Function Keys & Other Details
Switch down: Off - GPRS function disabled. NETWORK Note: When you want to configure the camera settings, we Switch suggest disabling GPRS function to quickly wake up LCD screen without waiting for the signal. Page 15 Creative XP 3G Scouting Trail Camera PRO3... -
Page 16: Functionality Introduction
Both alkaline or high-quality NiMH rechargeable batteries can be used. But we suggest running the camera with NiMH batteries only, as the performance of alkaline batteries Page 16 Creative XP 3G Scouting Trail Camera PRO3... - Page 17 10” Balanced 100 pics 31Days 10 Clips 37 Days video clips Min. Blur 100 pics 21 Days IR LEDs OFF Photo 100 pics 89 Days 10” Videos 10 Clips 179 Days Page 17 Creative XP 3G Scouting Trail Camera PRO3...
-
Page 18: Sd Card Selection
The chart below will show you the approximate capacity of different size SD cards. Please check to see which size card can fit your needs best. Page 18 Creative XP 3G Scouting Trail Camera PRO3... - Page 19 6 GB 32 GB Capacity Photos 5 MP 7492 15307 30936 8 MP 4798 9794 19795 12 MP 3371 6887 13919 Videos 640x480 00:46:57 01:35:56 03:13:52 00:33:53 01:35:56 02:19:56 00:17:48 00:36:20 01:13:21 Page 19 Creative XP 3G Scouting Trail Camera PRO3...
-
Page 20: Usb Connection
“OK” as if you want to do further settings configuration or do a Manual SIM card match. 5. Don’t interrupt power supply during a system upgrade. Page 20 Creative XP 3G Scouting Trail Camera PRO3... - Page 21 56pcs 60° IR LEDs are used on this camera. Please ensure that highly qualified AA batteries are used accordingly to deliver enough amperage to power the illuminator consistently in dark environments. Page 21 Creative XP 3G Scouting Trail Camera PRO3...
-
Page 22: Key Features
56pcs invisible IR LEDs - offer 20 meters (65 feet) real night vision distance and 75 feet daytime AT&T SIM CARD COMPATIBLE Crystal clear day & night photo/ video quality 1 photo burst per second to get full TIME LAPSE moving track of object Page 22 Creative XP 3G Scouting Trail Camera PRO3... - Page 23 Supports AT&T 2G and 3G Sim Cards IP54 WEATHERPROOF Optional small size (640*480) and large size (1920*1440) Email/FTP photos App available in IOS & Android APP store WIDE LENS PIR ANGLE Page 23 Creative XP 3G Scouting Trail Camera PRO3...
-
Page 24: Operation List
“No” to exit to the previous page. Delete All. 4.3 Format SD Card Yes: to format SD card via camera. Press “←” and “→” for selection, “Yes” to confirm, “No” to exit to the previous page. Page 24 Creative XP 3G Scouting Trail Camera PRO3... -
Page 25: Auto Power Off
Note: For some settings, the user needs to press “OK” to save & press “M” to exit the configuration after pressing “OK” to confirm (Cam ID, Delay, Time Lapse, Timer, Password). [CAM] - CAMERA MENU Page 25 Creative XP 3G Scouting Trail Camera PRO3... - Page 26 5. Max. Range: Longer exposure time to extend IR flash range for better night vision; lower image quality; 6. Balanced: a combination of the above 2 options; Multi-shot Programmable 1~5 photos per trigger Video Size 1280*720, 640*480, 1920*1080, Video length 05~59 Secs Page 26 Creative XP 3G Scouting Trail Camera PRO3...
- Page 27 IMPORTANT: In a high-temperature environment, the body heat of the subjects and environment temperature are harder to be detected by the camera. That is why we suggest setting the sensitivity on “High”. Page 27 Creative XP 3G Scouting Trail Camera PRO3...
- Page 28 (hour/minute); the camera will only work during this time period set by the user. I.e.: 15:00 – 18:00 (3:00 – 6:00 pm); camera only works during 15:00 – 18:00(3:00 – 6:00 pm) Page 28 Creative XP 3G Scouting Trail Camera PRO3...
- Page 29 AT&T Sim Card can’t be automatically matched by the camera itself. Always, turn OFF the camera and turn it back ON to update the info after manual setup. Page 29 Creative XP 3G Scouting Trail Camera PRO3...
- Page 30 3. MMS Proxy – 216.155.165.50 4. MMS Port – 8080 ON/OFF You can simply choose to allow pics to be sent to your phone number via MMS by switching ON / OFF MMS function here. Page 30 Creative XP 3G Scouting Trail Camera PRO3...
- Page 31 3. Enter your FTP server password access. Note: FTP only upload photos to preset FTP account; if FTP has the wrong information entered, then FTP account will not be able to receive photos from the camera. Page 31 Creative XP 3G Scouting Trail Camera PRO3...
- Page 32 PIN code before you try again. • Please insert SIM card into your phone to unlock it by using its PUK code after 3 times trial of activation based on steps above. Page 32 Creative XP 3G Scouting Trail Camera PRO3...
- Page 33 The information contained in Daily Report: Device IMEI Number, CSQ (Signal Strength): 0 up to 31, Camera ID, Temperature, Date & Time, Battery Left, Volume, SD Card Info, Total Pics Taken by Cam, Pics Sent by Cam. Page 33 Creative XP 3G Scouting Trail Camera PRO3...
- Page 34 This will help the camera to perform better. Frequency 50HZ, 60HZ * Improper setting may cause camera screen to flicker. The default setting is 50 HZ. Page 34 Creative XP 3G Scouting Trail Camera PRO3...
- Page 35 Select “Yes” to reset the camera back to factory default settings. Password Select “On”, then press “OK”, to enable password protection for your camera; supports a total of 6 digits/letters password. About Firmware version in camera (Version / IMEI / MCU) Page 35 Creative XP 3G Scouting Trail Camera PRO3...
-
Page 36: Technical Specifications
1080P (1920x1080): 15FPS, 720P (1280x720), 640x480 Video Format Video Length 5-59secs. Programmable Shooting Numbers Trigger Time 0.35~0.45s Trigger Interval 4s-7s Camera + Video Device Serial No. Time Lapse SD Card cycle ON/OFF Page 36 Creative XP 3G Scouting Trail Camera PRO3... - Page 37 Operating Temperature -30°C to 60°C Storage temperature -30 °C to 70°C Operation Humidity 5% - 90% Waterproof spec IP54 Dimensions 131.42 x98.72 x77.44mm Weight 404g Certification CE FCC RoHs IOS & Android Page 37 Creative XP 3G Scouting Trail Camera PRO3...
-
Page 38: Troubleshooting
Check batteries to make sure that alkaline or NiMH AA batteries have enough power for the camera to work. Make sure that the camera power switch is in the “On” position and not in the “Off” or “Setup” modes. Page 38 Creative XP 3G Scouting Trail Camera PRO3... -
Page 39: Night Vision Flash Range Doesn't Meet Expectation
IR flash range to reflect the flash back; it’s like shining a flashlight into the sky at night - you just can’t see anything - same goes for the trail camera. Page 39 Creative XP 3G Scouting Trail Camera PRO3... -
Page 40: Warranty
This warranty only covers fail- ures due to defects in materials or workmanship under normal usage. Page 40 Creative XP 3G Scouting Trail Camera PRO3... -
Page 41: Contact Information
Contact Should you have any questions or comments regarding this manual, please do not hesitate to contact us. CreativeXP 30 North Gould Street Sheridan 82801 Wyoming, USA E. support@creative-xp.com W. www.creative-xp.com Page 41 Creative XP 3G Scouting Trail Camera PRO3... - Page 42 O n e S t e p A h e a d Page 42 Creative XP 3G Scouting Trail Camera PRO3...
