Further, ViewSonic reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of ViewSonic to notify any person of such revision or changes.
CFL Reflector edge softly. Otherwise the TFT Module may be damaged. (10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate or tilt the Interface Connector of the TFT Module. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 5
(14) The LCD module is designed so that the CCFL in it is supplied by a Limited Current Circuit (IEC60950 or UL1950). Do not connect the CCFL to a Hazardous Voltage Circuit. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Green = ON Contrast adjustment control Orange = Power Saving screen. Also a shortcut to Auto Image Adjust. Displays the Main Menu Power or exits the control screen On/Off and saves adjustments. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 9
• If necessary, make small adjustments using H. POSITION and V. POSITION until the screen image is completely visible . (The black border around the edge of the screen should barely touch the illuminated “active area” of the LCD dislay.) Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 10
6500K — Adds red to the screen image for warmer white and richer red. 5400K — Adds green to the screen image for a darker color. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 11
Vertical moves the screen image up and down. (Horizontal Size) adjusts the width of the screen image. H. Size Vertical size is automatic with your LCD dislay. NOTE: Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 12
OSD Timeout screen is displayed. For example, with a “15 second” setting, if a control is not pushed within 15 seconds, the display screen disappears. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 13
[1] + [▼ ▼ ▼ ▼ ] + [▲ ▲ ▲ ▲ ] White Balance. (Push and hold for 5 sec [1] + [▼ ▼ ▼ ▼ ] Power Lock [1] + [▲ ▲ ▲ ▲ ] OSD Lock Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
APLL VDD Power for multi-phase PLL (3.3V) PLL TEST1 Test Pin 1 / IRQ# 3.3V tolerance PLL TEST2 Test Pin 2/Power-on-latch for crystal out Frequency APLL GND Ground for multi-phase PLL Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
In a 3.3V power system, VDD and VDD3 are connected to the 3.3V source, and all output pins swing from 0~3.3V. HSYNC, VSYNC and open drain pins can accept an input range of 0~5V, but all other pins must be kept below 3.3V. Also, the ADC conversion range is 3.3V. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 19
There are two signals to control the inverter which come from system. Logic “high” level which send to I901 is turn on the inverter. BRI signal control brightness by DC level which was integral from PWM signal. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
(2) Press “ ▲ ” key move cursor to “White Balance”, Press key do white balance adjustment. (3) Press “ ▼ ” key move cursor to “Color Temerature Adjust”, Press key, Then OSD will display Fig.2 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 21
(b). Change to each mode in turn and wait for the monitor finish auto-alignment and save process before change to next mode. (c). Until all of modes are agjusted, exit OSD menu and press PWR OFF to exit factory mode. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 22
When examining a monitor, please check whether the firmware version is the latest. If not, please follow the procedure below to upgrade to the latest version. 1. Equipment needed : VA721/VE510s-2/VE710b-2 PC ( Personal computer ) LPT cable Fixture (LM5ISP) Firmware upgrade program Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 23
Software: If OS was Win2000 or WinXP , please install “PORT95NT.exe” In order to ensure that the system can execute the ISP program, please adjust the BIOS settings in the PC or notebook as shown in Fig 0.0. Fig 0.0 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 24
2. Double-click the "PORT95NT.exe" icon in Windows and install the program; see Fig 0.1. Fig 0.1 3. Continue through the installation process by pressing "Next" four times; see Fig. 0.2. Fig. 0.2 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 25
4. Choose "Typical" then press "Next;" see Fig. 0.3. Fig. 0.3 5. Continue through the installation process by pressing "Next" four times; see Fig. 0.4. Fig. 0.4 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 26
1. The user may download the ISP driver and PORT95NT installation package from the Myson Century website (www.myson.com.) 2. The files extracted from the ZIP file are listed in Fig 1.0. Double-click setup.exe to install. Fig 1.0 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 27
3. Press “ Next “ button to continue., see Fig 1.1 Fig 1.1 4. Press the "Change" button to change the install path if desired, and then press the "Next" button to continue; see Fig 1.2. Fig 1.2 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 28
5. Press the "Install" button to continue; see Fig 1.3. Fig. 1.3 6. When installation has finished, press the "Finish" button; see Fig 1.4. Fig. 1.4 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 29
3. The warning shown in Fig. 2.3 is used to remind the user that a CPU rate that differs from IIC protocol may cause the ISP functions to fail; press the "OK" button. Fig. 2.3 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 30
4. As shown in Fig. 2.4, press the "Create Security File" button to key in a security code, and use the slider bar to adjust the speed of the IIC bus. Speed of IIC bus Security code Fig. 2.4 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 31
7C, 4C, 77. The command numbers and commands must be set by the user while coding. For more details, please refer to section 6 boot code of ISP. Fig. 2.5 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 32
1. As shown in Fig. 3.1, select the MTV type first, load the binary or intel hex file to be programmed into the MCU, click "OK," then press the "RUN" button. Step 2 Step 1 Step 3 Step 4 Fig. 3.1 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 33
3. CRC (cyclic redundancy check): the host can check the result in the CRC register instead of reading every byte in flash. The Check MCU CRC OK message indicates that the host has verified the program's CRC; see Fig.3.2. Fig. 3.2 Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
MAIN PCB CHECK 3.3V OK? POWER PCB CHECK CHECK I107 I101,I104 2.5V OK? SUROUND CAP SUROUND CAP BEAD OK? CHECK CHECK I106 I101 SUROUND CAP SUROUND CAP BEAD OK? BEAD OK? Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 35
24.576MHz(CMO Panel) Change X102 is working ? Check I101 Change I101 LCD Pin#73,74 data bus controller IC have signal Check panel Powers VLCD_3V3 (CPT Panel) VLCD_5V (CMO Panel) correct Change LCD panel Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 52
8. Exploded Diagram And Spare Parts List FIG.1 15 X2 20 X4 NOTE.1 13-1 13-2 MAIN PCB ASS'Y 11 X3 POWER PCB ASS'Y 16 X4 NOTE.1 22 X2 FIG.1 KEYPAD PCB ASS'Y Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 53
LCD PANEL (CMO) P902 P901 P106 P802 P105 MAIN PCB (Realtek scaler) POWER PCB P104 P101 P903 P701 P904 KEYPAD PCB I/O CABLE Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 54
EXPLODED PARTS LIST (VA721, VE710b-2 & VE710s-2) ViewSonic Model Number: VS10047 Rev: 1c Item ViewSonic P/N Ref. P/N Description Location Q'ty Remark C-FP-0301-0980 2603307568 FRONT BEZEL VE710 ABS94HB PS7604B 1F01 VE710s-2 C-FP-0301-0978 2603307569 FRONT BEZEL VE710B-2 ABS94HB PANTONE 432C 1F01...
Page 55
Procedure of Disassembly (VE710s-2/VE710b-2/VA721) This section provides disassembly procedures for VE710s-2/VE710b-2/VA721 LCD Monitor. Before you begin any of these procedures, be sure to turn off the power, computer system, and other attached devices; then disconnect the power cable from the electronically outlet. Moreover, when you disassemble the monitor, be sure to put the screws in a safe place and separate them according to grouping.
Page 56
Stand unit 3. Detach Stand unit from the monitor. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 57
Detach Front Cover from the monitor. Unscrew two screws that secure Hinge Metal Fitting. Unscrew two screws that secure Keypad Board. Rear Cover Detach Rear Cover from the LCD Panel module. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 58
Unscrew one screw that secure Inverter top Shielding Plate and detach Inverter top Shielding Plate. Unscrew one screw that secure Inverter down Shielding Plate and detach Inverter down Shielding Plate. Disconnect three connectors to remove Inverter connector and LCD Panel FFC cable. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 59
LCD Panel 2080002200 Unscrew four screws that secure Metal Fitting and remove LCD Panel from Metal Fitting. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 60
1. Unscrew four screws that secure Main Board and disconnect the wires which are connected to Main Board and remove Main Board. " 2081430062 2. Unscrew four screws that secure Power Board to remove Power Board. Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 61
9. Block Diagram (VE710s-2/VE710b-2/VA721 Realtek Scaler CMO Panel) SWITCHING AC 110~220V POWER SUPPLY INPUT 3V3/5V I901 OZ9RR 3V3/5V I106、I107 INVERTER ONBACKLITE DC / DC PANEL POWER 3V3/5V ADJBACKLITE I101 RXE ﹝0、9﹞ RTD2023 SXGA RXO ﹝0、9﹞ LVDS H-Sync LCD PANEL(CMO) SCALAR...
11. PCB Layout Diagrams 11.1. MAIN PCB TOP VIEW (Realtek Scaler CMO Panel) Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 69
11.2. MAIN PCB BOTTOM VIEW (Realtek Scaler CMO Panel) Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 70
11.3. CON PCB TOP VIEW 11.4. CON PCB BOTTOM VIEW Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 71
11.5. POWER PCB TOP VIEW (CMO Panel) 11.6. POWER PCB BOTTOM VIEW (CMO Panel) Confidential - Do Not Copy ViewSonic Corporation VE710s/b-2 VA721...
Page 72
Add.: Fax: Tel: E-mail: After completing this form, please return it to ViewSonic Quality Assurance in the USA at facsimile 1-909-839-7943. You may also e-mail any suggestions to the Director, Quality Systems & Processes (marc.maupin@viewsonic.com) Confidential - Do Not Copy...
